Summary of Contents for Philips Assembleon AX-201

  • Page 1 2nd Trolley Interface AX-201...
  • Page 2 FEEDBACK CHANNEL: Send comments on this document to: documentation.feedback@philips.com Add the order number and revision code of this document with your comments. This information is visible at the bottom of each page. © A s s e m b l é o n N e t h e r l a n d s B V All rights reserved.
  • Page 3 Chapter 1 CHAPTER 1 Second trolley interface PA 2455/01, installing Estimated time te complete [min.]: Required special tools..Panel key from the setup tooling kit Required part(s) ... . . Second trolley interface PA 2455/01 This second trolley interface is applicable for PA 2410/01 and newer.
  • Page 4 Chapter 1 1.1 Touch screen rear, installing 1. Install power supply for rear screen • This power unit must be installed at the rear. • Fix the power unit with tie wraps to the cable duct. Note: The power cable is pre-installed. 2.
  • Page 5 Chapter 1 4. Mount cabling Note: The cables for VGA, USB and earth for the touch screen are already pre-installed in the machine. Those cables are placed on the right side rear, inside the machine. • Install those cables together with the power supply cable to the touch screen.
  • Page 6 Chapter 1 6. Connect VGA splitter • Connect the VGA cables to the VGA splitter according picture. • Power socket is available. 2nd Trolley Interface 4022 593 52261 AX-201 08.01...
  • Page 7 Chapter 1 1.2 Enabling switch, installing 1. Enabling switch • Lead the cable through the holder and place the enabling switch. 2. Remove panel at the right side of the base • Release both catches (1). Use the panel key from the setup tooling kit, or use a 6 mm Allen key.
  • Page 8 Chapter 1 3. Connecting enabling switch • Pull out the control supply unit. • Lead the cable through the machine. • Connect the enabling switch IBB.X58 on the interconnection board base. • Replace panel at the right side of the base. IBB.X58 2nd Trolley Interface 4022 593 52261...
  • Page 9 Chapter 1 1.3 Trolley lifts rear, installing HEAVY OBJECT Weight: CAUTION CAUTION Improper lifting method may cause injury. 25 kg Use proper tools to lift the object. 1. Remove covers • Remove cover (1). • Remove cover (2), and place back the chims (L,R).
  • Page 10 Chapter 1 2nd Trolley Interface 4022 593 52261 AX-201 08.01...
