SmartWitness CRX User Manual

8ch ahd mobile digital video recorder
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CRX
8CH AHD Mobile Digital
Video Recorder
USER GUIDE
v1.3
WARNING: SmartWitness installations should be performed by a qualified individual or installation professional
only. Working with a vehicle's power system can be dangerous to both you and your vehicle. This installation is
intended only to be a guide since vehicle designs and power/input sources can vary significantly
from vehicle to vehicle.
If you need to schedule a professional installation service in the USA for your
SmartWitness device(s), please visit
http://smartwitness.com/scheduleinstall
and submit the online form.
All cellular-enabled CRX devices must use the installation wizard for proper onboarding and activation,
please visit
http://install.smartwitness.com
to register, login, and use the SmartInstall wizard.
1 |
P a g e
