ASSEMBLY AND OPERATING INSTRUCTIONS
1. Connect the handle to either end of the axle which doubles as a fluid
path, use a suitable thread sealant and tighten accordingly.
2. Connect the swivel on the opposite end of the axle as the handle, use a
suitable thread sealant and tighten accordingly.
* See parts list image for orientation of swivel*
3. Attach outlet hose to the outlet fitting located in the hub, use a suitable
thread sealant and tighten accordingly.
4. Attach supply hose to the hose reel swivel, use a suitable thread
sealant and tighten accordingly.
5. Use 1/2" or 13 mm bolts when securing the hose reel to ceiling or wall.
6. The hose reel is ready for operation.
NOTE: THREAD SEALANT NOT INCLUDED
CAUTION: When using hardened NPT fittings DO NOT over tighten,
over-tightening can result in a cracked swivel or fitting.
SAFETY PRECAUTIONS
1. Make sure incoming pressure does not exceed
the rated pressure.
2. Use proper eye protection when assembling and
using the hose reel.
3. Assemble the hose reel on a clean workbench
free of debris and moisture.
4. Use soap and water when checking for air leaks.
5. Keep children away from work area.
WARNING!
Exposure of skin directly to
pressurized air or fluids could
result in severe bodily injury!
Warning. Only trained and qualified personnel should install or
replace the device.
Warning. De-pressurize prior to servicing.
General Pump
1174 Northland Drive • Mendota Heights, MN 55120
Phone: 651.686.2199 • Fax: 800.535.1745
www.generalpump.com • email: sales@gpcompanies.com
• Friction Brake
• Direct hand-crank rewind
• Solid steel construction
• Durable powder-coat finish
• Full flow swivel Stainless swivel
Ref 300946 Rev. N
09-23
DHRA50300
with folding mechanism and
drum locking pin
with internal bearing
Operator's manual
Ref 300946 Rev. N
09-23
General Pump
is a member of
the Interpump Group
INDUSTRIAL
Hose
Reels
From General Pump
DHRA50150
DHRA50300
DHRA50450
