GENERAL PUMP
FEATURES / BENEFITS
•
Low pressure garden hose reel
•
Durable gray high-gloss powder coated finish
•
Can be set up for left- or right-hand orientation
•
Can be mounted parallel or perpendicular to a
wall
DIMENSIONS (in/mm)
General Pump
is a member of
the Interpump Group
A member of the Interpump Group
SPECIFICATIONS
PART NUMBER
3/8" Hose Capacity
Max Pressure Rating
Ship Weight
Inlet
Outlet
Materials
Aluminum, Steel, Brass, Rubber
•
Robust high flow brass swivel
•
HD pedestal stand - mount on wall, workbench
or pressure washer
•
Includes 6', 5/8" connection hose, brass fittings,
and mounting hardware.
•
One-piece welded drum
DHRGH150
Garden Hose Reel
DHRGH150
150 ft.
150 PSI
3/4" GH-F
3/4" GH-M
22.0 lbs.
Ref 301079 Rev A
01-22
