- Page 1 BF1N4T013 Built-in Oven user & installation manual imagine the possibilities Thank you for purchasing this Samsung product. BF1N4T013_FA_DG68-00671A-01_EN.indd 1 2016-01-06 9:32:52...
- Page 2 contents USING THIS MANUAL Using this manual SAFETY INSTRUCTIONS Bulb exchange Door removal Door glass removal Auto energy saving function INSTALLATION Installation OVEN CONTROLS 10 Oven controls ACCESSORIES 10 Accessories SETTINGS 11 Time setting 11 Set alarm 11 Child lock function 11 Using the fast preheating mode 12 Using the cooking mode 13 Test dishes...
- Page 3 Thank you for choosing SAMSUNG Built - In Oven. This user Manual contains important information on safety and instructions intended to assist you in the operation and maintenance of your appliance. Please take the time to read this Owner’s Manual before using your oven and keep this book for future reference.
- Page 4 During use the appliance becomes hot. Care should be taken to avoid touching heating elements inside the oven. WARNING: Accessible parts may become hot during use. Young children should be kept away. If this appliance has steam or self cleaning function, excess spillage must be removed before cleaning and all utensils should not be left in the oven during steam cleaning or self cleaning.
- Page 5 In the event of a fault or damage to the appliance, do not attempt to operate it. Repairs should be performed by a licensed technician only. Improper repair may result in considerable danger to you and others. If your oven needs repair, contact a SAMSUNG Service Centre or your dealer.
- Page 6 Frozen foods such as pizzas should be cooked on the Big grid. If the baking tray is used, it may become deformed due to the great variation in temperatures. Do not pour water into the oven bottom when it is hot. This could cause damage to the enamel surface.
- Page 7 • Disconnect the oven from the mains. • Protect the oven light bulb and the glass cap by laying a cloth on the bottom of the oven compartment. • Bulbs can be purchased from the SAMSUNG Service Centre. Rear oven light 1. Remove cap by turning anticlockwise and remove the metal ring, the sheet ring and clean the glass cap.
- Page 8 DOOR REMOVAL For normal use, the oven door must not be removed but if removal is necessary, for example, for cleaning purposes, follow these instructions. CAUTION: The oven door is heavy. 1. Open the door and flip 2. Close the door by 3.
- Page 9 With built-in furniture, plastic surfaces and adhesive for the oven should be resistant to 90 °C inside of the furniture and to 75 °C for adjacent furniture. Samsung will take no responsibility for damage of plastic surfaces or adhesive from the heat.
- Page 10 oven controls Alarm Time Control Buttons Function Select Knob Time Window Display Temp Control Knob Front design The front panel is available in various material and color options including stainless steel, white, black and glass. For purposes of quality improvement, the appearance may be subject to change.
- Page 11 settings TIME SETTING When connecting the power for the first time, please use the product after setting the time. Set hours | 01 Press Time button, hours figure will blink. Set minutes | 02 03 | Confirm time Press Time Control button, Press Time button again, to Press Time button, minutes set desired time.
- Page 12 USING THE COOKING MODE Set cooking mode | 01 02 | Set temperature Turn Function Select Select the desired Knob, set desired the temperature by turning the cooking mode. Temp Control Knob. Grill temperature 1: Low 2: Medium 3: High Set the temperature for all cooking other than grilling.
- Page 13 TEST DISHES According to standard EN 60350 1. Baking The recommendations for baking refer to preheated oven. Shelf Cooking Temp. Cooking time Type of Food Dish & Notes level mode (°C) (min.) Small Cake Baking Tray Conventional 170-190 15-25 Fatless Baking tin on Big grid Conventional 160-180...
- Page 14 cleaning and care CATALYTIC ENAMEL SURFACE (DEPENDING ON MODEL) The removable cover casing is coated with a dark gray catalytic enamel this can become coated with oil and fat distributed by circulating air during convection heating. These deposits will burn off at oven temperatures of 200 °C and higher.
- Page 15 DETACHING THE SIDE RUNNERS (DEPENDING ON MODEL) 1. Press central part of the 2. Rotate the side runner by 3. Pull and remove the side side runner top portion. approximately 45 º. runner from bottom two holes. The oven operates without the side runners and racks in position. CLEANING THE CEILING (DEPENDING ON MODEL) 1.
- Page 16 INFORMATION CODES All information codes are not from the fault of the oven. Please refer to below solution first, if the information codes still occur, please call your local SAMSUNG Customer Care Centre. CODE PROBLEM SOLUTION Safety Shutoff Turn oven off and remove food.
- Page 17 PRODUCT DATA SHEET SAMSUNG SAMSUNG Model identification BF1N4T013 Energy Efficiency Index per cavity (EEI 106.1 cavity Energy Efficiency Class per cavity Energy consumption required to heat a standardised load in a cavity of an electric heated oven during a cycle in conventional 0.89 kWh/cycle...
- Page 18 memo BF1N4T013_FA_DG68-00671A-01_EN.indd 18 2016-01-06 9:32:57...
- Page 19 memo BF1N4T013_FA_DG68-00671A-01_EN.indd 19 2016-01-06 9:32:57...
- Page 20 QUESTIONS OR COMMENTS? COUNTRY CALL OR VISIT US ONLINE AT U.A.E 800-SAMSUNG (800 - 726 7864) OMAN 800-SAMSUNG (800 - 726 7864) www.samsung.com/ae/support (English) KUWAIT 183-CALL (183-2255) www.samsung.com/ae_ar/support (Arabic) BAHRAIN 8000-GSAM (8000-4726) QATAR 800-CALL (800-2255) 08000-726786 EGYPT www.samsung.com/eg/support 16580 ALGERIA 3004 (Toll Free) www.samsung.com/n_africa/support...
