- Page 1 BUILT-IN GAS OVEN INSTALLATION, USE AND MAINTENANCE MANUAL MODEL FN2K66G3X/1-FN2K66G3W/1-FN2K66G3B/1 FN2K66M4X/1-FN2K66M4W/1-FN2K66M4B/1-...
- Page 2 Important This appliance is designed and manufactured for home cooking only, and it is not for any application outside the house and thus should not be used in commercial environments. In case the appliance is used somewhere outside a house; meaning being used semi- commercially, commercially or in public space, it's warranty will be void.
- Page 3 Manufacturer cannot be held responsible for any damage caused by inappropriate, wrong or unreasonable use of the appliance. Using The Oven For The First Time We recommend you do the following: -- Install the inner part of the oven as described under "Cleaning and Maintenance". -- Operate the oven empty for maximum temperature for two hours to remove the oil stains and smell from the parts.
- Page 4 Introduction to Controls 1. Oven fan control knob 2. Digital timer control panel 3. Upper and lower gas burner control knob FN2K66G3X/1-FN2K66G3W/1-FN2K66G3B/1 FN2K66M4X/1-FN2K66M4W/1-FN2K66M4B/1 Note: - Electrical ignition is integrated to thermostat control knob. - Appliance is equipped with a safety valve system. Gas flow will be cut off if flame is extinguished by accident.
- Page 5 OFF FUNCTION : The product won’t work in this position. LIGHTING: Only lamp is used. ROTISSERIE: Grill element will be activated with the rotisserie function. Used mainly for big meat portions. It is advised to place meat directly on the rotisserie grate with a tray under.
-
Page 6: Manual Operation
USING DIGITAL TIMER SETTING THE TIME OF DAY (24 H CLOCK) After plugging in or reconnecting to a power source after current decay, “0.00”, and “AUTO” flashes. Press button M approximately 2 sec., dot icon starts flashing. Set the current time using buttons (-) and (+). -
Page 7: Cooking Timer
minute minder icon starts to flash again. Press any buttons to turn the signal off; the minute minder icon disappears, and the display indicates the current time. CHANGE THE TIMER BEEPS The tone of the timer beeps may be changed as follows: Press buttons (-) and (+) simultaneously, Press button M to see actual tone “ton.1”... -
Page 8: Safety Lock
Set the turn-off (cooking end) time using buttons (+) and (-), which is limited up to 23 hours 59 minutes. (for example 19:30). Turn the thermostat and function control knobs to the required settings. Cooking icon is disappeared on the display. Oven will not be switched on until cooking start time (for example 18:30), that is the difference between the cooking end time and the cooking time. - Page 9 CAUTION: When the burner goes off by accident, turn off the gas from the control knob and wait at least for one (1) minute before trying to light it again. CAUTION: Gas appliances cause heat and humidity in their environment. Ensure that the cooking area is ventilated well, by opening the natural ventilation grids or mounting an aspirator to the exit channel.
-
Page 10: How To Use The Oven
HOW TO USE THE OVEN IMPORTANT INFORMATION: - Do not use the appliance if there is an electrical malfunction or if the cooling fan motor is damaged. The appliance may overheat and be damaged due to cooling fan motor not operating. - In case the cooling fan motor is damaged during gas oven or gas grill operation, oven or grill burner automatically shuts down after approximately 20 minutes. - Page 11 Igniting the Oven Burner IMPORTANT: The oven door will be open during this operation. To ignite the oven burner: Completely open the oven door. Do not continue igniting the oven unless you do this. 2. Press the thermostat knob to start electrical ignition and while keeping the knob pressed, turn it counter-clockwise (Figure 4) until it reaches the Maximum position (Figure 3).
- Page 12 Igniting The Grill Burner IMPORTANT: The oven door must be open after this operation. To ignite the burner: Completely open the oven door. Do not continue igniting the oven unless you do this. 2. Press the thermostat knob to start electrical ignition and while keeping the knob pressed, turn it clockwise (Figure 4) until it reaches the GRILL position (Figure 3).
- Page 13 Traditional Grill Warning: Grill burner is used only when the door is closed. Leave it to heat up for approximately 5 minutes when the door is half-open. Place the food on the grill, while the rack is as close to the grill as possible. Place the tray on the suitable rack to collect the juice dripping from the food during grilling.
- Page 14 Heat Guide SIGN OVEN HEAT FOOD TO BE COOKED Meringue cakes, foods ½th Region Very cold oven cooked in low temperature Rice pudding, cakes with lots 1. Region Cold oven of fruit, i.e. Christmas Stew, casserole, foods cooked 2. Region Cold or slow oven in low fire, rich fruit cakes, i.e.
- Page 15 WARNING When installed correctly, your product meets all the safety conditions foreseen for this product category. But special care should be given to the rear and bottom sides of the appliance, since it can have sharp or hard corners that can cause injuries and these areas should not be touched.
- Page 16 Replacing the Oven Lamp WARNING: To prevent electric shock, make sure the appliance is turned off before replacing the lamp. - Leave the oven gap and heating elements to cool down. - Cut off the power connection. - Remove the protective cover "A" (Figure 10). - Remove the bulb "B"...
- Page 17 Removing the Oven Door Be careful, oven door is heavy. When in doubt, do not try to remove the door. Oven door can be removed as follows: - Open the door to the end (Figure 13) - Completely open the A arm on the left and right hinges (Figure 14). - Hold the door as shown in Figure 12.
- Page 18 Placing the Oven Door Back - Hold the door fast (Figure 17). - Place the hinge latches in the gaps and make sure that the gap is fitted into place as in figure 18. - Open the door to the end. - As seen in Figure 19, completely close the "A"...
- Page 19 Removing the Inner Glass Pane The oven door has two panes: - 1 glass outer - 1 glass inner To clean all panes from both sides, the inner pane must be removed as specified below: 1. Open the door Fig.-20 - Open the door to the end (Figure 20) - Completely open the A arm on the left and right hinges (Figure 21).
- Page 20 Replacing the Inner Glass Pane After Cleaning When replacing the inner glass pane: - make sure you replaced the pane correctly as shown. Pane must be in the position specified below to fit in the door and to ensure oven's safe and correct operation.
- Page 21 What Should / Shouldn't Be Done - Always grill with the door half-open. - Read the user instructions carefully before using the oven for the first time. - Before using the oven for the first time, operate the oven empty for two hours to remove the odors caused by new oven insulation.
- Page 22 Recommendations for the Installer The installation and maintenance of the appliance shall be performed only by AUTHORIZED TECHNICIANS and in accordance with local safety standards. - Warranty becomes void unless this is conformed to. - Cut off the power connection of the appliance when performing any maintenance or repair operation.
- Page 23 The case should not stand free. It should be fixed to the wall and/or adjacent fixtures. Fig.-28 Fixing the Oven Place the oven to the gap in the cabinet and fix with 4 screws, as shown in Figure 29. As the purpose of the fixing with screws is only complementary, make sure the oven stands on a surface that supports its weight.
- Page 24 IMPORTANT: To prevent the lower rail from being damaged, follow the instructions below. Lower rail is designed to ensure better ventilation and correct opening of the oven door. To make sure that the rail is not damaged due to the appliances mounted on the floor, the appliance should be supported as shown here.
- Page 25 Application Law, Gas Safety Regulation and the Building Standards (Scotland) (Assembly) issued by Scotland Office of Development. Connection to Natural Gas Connection to natural gas shall be compliant with Application Act etc. Natural gas supply pressure is 20 mbar. Fixture shall be compliant with relevant British standards. Connection to LPG 28-30 mbar supply pressure is required when opened by butane gas.
- Page 26 Maintenance and Natural gas or LPG conversion Injector Selection Table Category:II2H3+ BURNERS Nominal Reduced Natural Gas Power [kW] Power G30 (28-30 mbar) G20 (20 mbar) [kW] G31 (37 mbar) Injecto Ring gap Injector Ring [mm] diameter diamet [1/100 mm] [mm] [1/100 Oven Completely...
- Page 27 - Remove the screws of the injector using 7 mm box strainer (shown with an arrow in Figure 32) and replace with a new injector selected according to the "Injector Selection Chart". - Adjust the air supply to the oven burner as specified in the "Oven and Grill Burners Air Supply Adjustment"...
- Page 28 Fig.-34 Fig.-33 Primer Air Correct Air Primer Air Too Much Insufficient spread, yellow and light insides blue cone short and sharp too blue inner flickering cone, prone to separation Primer Primer Air Too Much Correct Air Insufficient CAUSE Air adjustment bottle Bottle in correct Air adjustment bottle open too closed too much...
