Built-in Oven
Instruction Manual
Model: TEO6040BL
NOTE
: This User Instruction Manual contains important information,
including safety & installation points, which will enable you to get the
most out of your appliance. Please keep it in a safe place so that it is
easily available for future reference; for you or any person not familiar
with the operation of the appliance.
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the TEO6040BL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Tecnogas TEO6040BL

Summary of Contents for Tecnogas TEO6040BL

  • Page 1 Built-in Oven Instruction Manual Model: TEO6040BL NOTE : This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference;...

  • Page 2: Table Of Contents

    Contents Environmental note Important safety information 4 – 6 Specifications Control panel Oven programmer/timer display Setting and using the oven programmer/timer Selecting an oven function Selecting a cooking function and temperature The thermostat control knob Warnings Accessories Cleaning and maintenance 12-13 Replacing the oven bulb Installation...

  • Page 3: Environmental Note

    Environmental note o The packaging materials that company environmentally friendly and can be recycled. o Please discard all packaging material with due regard for the environment.

  • Page 4: Important Safety Information

    IMPORTANT SAFETY INFORMATION Your safety is of the utmost importance to our company. Please make sure that you read this instruction booklet before attempting to install or use the appliance. If you are unsure of any of the information contained in this booklet, please contact our company's Technical Department.

  • Page 5: Child Safety

    Child Safety o We strongly recommend that babies and young children are prevented from being near to the appliance and not allowed to touch the appliance at any time. o If it is necessary for younger family members to be in the kitchen, please ensure that they are kept under close supervision at all times.
  • Page 6 Installation This appliance must be correctly installed by a suitably qualified person, strictly in accordance with the manufacturer’s instructions. o We decline any responsibility for injury or damage, to person or property, as a result of improper use or installation of this appliance.

  • Page 7: Specifications

    Electrical details Rated Voltage: 220-240 Vac 60 Hz Max Rated Inputs: MAX RATED INPUT MODEL Voltage：220V Voltage：230V Voltage：240V TEO6040BL 2150W 2350W 2550W Mains Supply Lead: 3 x 1.5mm² Oven Light Bulb: 25 W/300°C screw type pigmy...

  • Page 8: Control Panel

    1.Control panel and using 4-function control panel with mechanical timer 1. function select 2. power indicator light 3. knob for timer 4. oven operating light 5. knob for temperature control 1.If the timer is not needed, press”ON”to switch on. 2.If the timer is needed, turn around the knob clockwise to the time from 0 to 120 minutes.The power will cut off automatically when the time finishes.

  • Page 9: Selecting An Oven Function

    Selecting a cooking function and temperature 1,After the oven is connected to the main electricity supply,the indicator of power flashes.Set the temperature after selecting the cooking function.Set the cooking time when the indicator of cooking function flashes.(The cooking time can be set from 0 to 120 minutes.Turn around the knob clockwise to the corresponded time.

  • Page 10: The Thermostat Control Knob

    Thermostat control knob The oven thermostat control knob sets the required temperature of the oven. It is possible to regulate the temperature within a range of 50 - 250°C. Turn the control knob clockwise. Oven operating light This light will come on to indicate that the oven’s heating elements are in operation.

  • Page 11: Warnings

    o Before cooking, check that any accessories that are not required are removed from the oven. o Place cooking trays in the centre of the oven and leave gaps between the trays to allow air to circulate. o Try to open the door as little as possible to view the dishes. o The oven light will remain on during cooking.

  • Page 12: Accessories

    Accessories Your oven will come supplied with the following oven furniture: (A)oven rack 、 2、(B)bake tray The numbers 1 – 4, indicate the different shelf positions that you can utilise within the oven. It is optional and can be matched freely according to the customer themselves.

  • Page 13: Replacing The Oven Bulb

    o If you use any form of oven cleaner on your appliance, then you must check with the manufacturer of the cleaner that it is suitable for use on your appliance. o Any damage that is caused to the appliance by a cleaning product will not be fixed free of charge, even if the appliance is within the guarantee period.

  • Page 14: Electrical Connections

    WARNING: THIS APPLIANCE MUST BE EARTHED. o This appliance should be wired into a 13 A double pole switched fused spur outlet, having 3 mm contact separation and placed in an easily accessible position adjacent to the appliance. The spur outlet must still be accessible even when your oven is located in its housing to enable the appliance to be disconnected from the mains supply.

  • Page 15: Ventilation Requirements

    Positioning the appliance o Ensure that the aperture that you will be fitting the oven into is of the size given in the above diagram. o The oven must be fitted into an oven housing with the ventilation cut-outs shown in the “Ventilation requirements” section on the next page.

  • Page 16: My Appliance Isn'tworking Correctly

    Ensure that the oven has been securely fixed into the housing unit. The fixing of the oven into the housing is made by using four screws. These should be screwed through the oven cabinet and into the housing unit. My appliance isn’tworking correctly o The oven isn’t coming on.
  • Page 17 o My food is not cooking evenly * Check that the oven has been installed correctly and is level. * Check that the correct temperatures and shelf positions are being used. o The oven light is not working * Refer to page 20 and follow the “Replacing the oven bulb” section. o I am getting condensation in my oven * Steam and condensation is a natural by product of cooking any food with high water content, such as frozen food, chicken etc.

  • Page 18: Cooking Guidelines Of Main Functions

    COOKING GUIDE FOR MAIN FUNCTIONS conventional oven:using top heating element+bottom heating element placement of setting food weight preheat finish time tray temperature The second 40-50 220℃ beef 15 minutes layer minutes The second 70-80 220℃ pork 1 kg 15 minutes layer minutes The second...
