  • Page 1 MIDI OVEN SERVICE MANUAL 2018 DECEMBER...

  • Page 2: Table Of Contents

    CONTENTS 1. WARNINGS 1.1. General Safety Warnings 1.2. Safety For Montage 1.3. Information For Consumers 2. MIDI OVEN MODELS 2.1. 34 Liter 2.1.1. Technical Specifications 2.1.2. Technical Tables 2.1.3. Description Of Oven And Control Panel 2.1.4. Component Disassembly/Assembly 2.1.5. Circuit Diagrams 2.2.

  • Page 3: Warnings

    1. WARNINGS This product is manufactured in accordance with the safety regulations. Throughout this user manual the following symbols are used. Important information or useful hints about usage. Warning of hazardous situations with regard to life and property. Warning of electric shock. Warning of risk of fire.

  • Page 4: Information For Consumers

    1.3. Information For Consumers  Product may be hot when it is in use. Never touch the hot burners, inner sections of the oven, heaters and etc. Do not place flammable substances near the product while working.  Never wash the product by spraying or pouring water onto it. There is danger of electric shock! ...

  • Page 5: Midi Oven Models

    2.MIDI OVEN MODELS 2.1. 34 Liter 2.1.1. Technical Specifications: SPECIFICATIONS 34 LTR Outer Width 480 mm Outer Depth 356 mm Outer Height 300 mm Inner Width 364 mm Innet Depth 315 mm Inner Height 240 mm Thermostat 40-240 ◦C Timer 0-90 min.

  • Page 6: Technical Tables

    2.1.2. Technical Tables: *All models are included.
  • Page 7 H / W / D (mm)

  • Page 8: Description Of Oven And Control Panel

    2.1.3. Description Of Oven And Control Panel: 1. Control Panel 7. Glass Oven Door 2. Oven Frame 8. Control Knobs 3. Handle 9. Round Tray 4. Vessel 10. Square Tray 5. Heaters 11. Rack Grill 6. Oven Feet  Timer: Set the timer according to the recommended cooking time at the desired thermostat value.

  • Page 9: Component Disassembly/Assembly

    2.1.4. Component Disassembly/Assembly: 1) Knobs Photo 2 Photo 1 Pull back standard knobs on panel and take them out.
  • Page 10 2) Cover Glass Photo 1 Photo 2 Photo 3 Photo 4 Separate the metal from glass carefully with the help of a screwdriver, without damaging to the glass and take out glass by paying attention to the hole on right.
  • Page 11 3) Handle Photo 1 Photo 2 Remove two screws that connect handle to glass and take out it. 4) Frame Photo 1: Rear View Photo 2: Sub-View...
  • Page 12 Photo 3: Final Situation Remove the screws on rear surface and sub-surface to take out frame. 5) Mechanic Timer Timer Thermostat Switch Photo 1 Photo 2 Remove screws to take out the mechanic timer and disconnect cables carefully.
  • Page 13 6) Thermostat Timer Thermostat Switch Photo 2 Photo 1 Remove screws to take out the thermostat and disconnect cables carefully. 7) Switch(Commutator) Timer Thermostat Switch Photo 2 Photo 1 Remove screws to take out the switch and disconnect cables carefully.
  • Page 14 8) Metal Spring Photo 1 Photo 2 Take out the metal spring to disassemble front panel. 9) Front Panel Photo 1 Photo 2 Remove 4 screws to take out front panel. When take out panel, please pay attention to tabs.
  • Page 15 10) Thermostat Stick(Capillary Thermostat) Photo 1 Photo 2 Follow steps to take out stick according to photographs. 11) Bottom And Top Resistance Photo 1 Photo 2 Disconnect cable connections for resistances.
  • Page 16 Photo 3: Sub-surface Photo 4 Press clips with pliers from outside for bottom resistance and get out from inside clips that connect the resistance to the inside of body. Remove resistance pulling back from the hole on side. Photo 5:Top Surface Photo 6 Press clips with pliers from outside for top resistance and get clips out from inside that connect the resistance to the inside of body.
  • Page 17 12) Plug Photo 1 Photo 2 Cut the heat shrink and disconnect cables carefully. Finally remove nut to replace plug. 13) Oven Lamp (If you don’t have oven lamp in your product, please skip this step.) Photo 1 Turn the lamp glass and oven lamp to replace and flex slot to take out lamp holder after disconnecting cables.
  • Page 18 14) Turbo Fan (If you don’t have turbo fan in your product, please skip this step.) Photo 1 Remove screws and disconnect cable connections to get turbo fan out.

  • Page 19: Circuit Diagrams

    2.1.5. Circuit Diagrams: *If you have another product except these options, please ask an expert or contact with us. Midi oven 0+3 without oven lamp Midi oven 0+3 turnspit option without oven lamp...

  • Page 20: Liter

    2.2. 35 Liter 2.2.1. Technical Specifications: SPECIFICATIONS 35 LTR Outer Width 495 mm Outer Depth 380 mm Outer Height 300 mm Inner Width 350 mm Innet Depth 310 mm Inner Height 240 mm Thermostat 40-240 ◦C Timer 0-90 min. Bottom Heater 600 W Top Heater 600 W...

  • Page 21: Technical Tables

    2.2.2. Technical Tables: *All models are included.

  • Page 24: Description Of Oven And Control Panel

    2.2.3. Description Of Oven And Control Panel: 1. Control Panel 8. Control Knobs 2. Oven Frame 9. Round Tray 3. Handle 10. Square Tray 4. Vessel 11. Rack Grill 5. Heaters 12. Hotplate(Option) 6. Oven Feet 13. Turnspit(Option) 7. Glass Oven Door 14.

  • Page 25: Component Disassembly/Assembly

    2.2.4. Component Disassembly/Assembly: 1) Knobs Photo 1 Photo 2 Pull back standard knobs on panel and take them out.
  • Page 26 2) Control Panel Photo 1 Photo 2 Photo 3:Final Situation Remove 2 screws to take out control panel and lift it up little bit from the bottom side to take out signal lamps for switch, disconnect cables for turnspit button if you have. After that slide panel down and take out it.
  • Page 27 3) Frame Photo 1: Rear View Photo 2: Sub-View Photo 3: Front View Remove the screws on rear surface, sub-surface and front surface to take out frame.
  • Page 28 4) Oven Door Photo 2 Photo 1 Photo 3: Final Situation Take out spring metal and remove screws on right to take out oven door.
  • Page 29 5) Mechanic Timer Thermostat Timer Switch Photo 1 Photo 2 Remove screws that connect timer to panel and take out the mechanic timer. Disconnect cables carefully.
  • Page 30 6) Thermostat Thermostat Timer Switch Photo 1 Photo 2 Remove screws that connect thermostat to control panel and take out it. Disconnect cables carefully.
  • Page 31 7) Switch(Commutator) Thermostat Timer Switch Photo 2 Photo 1 Remove screws that connect switch to panel and take out the switch. Disconnect cables carefully.
  • Page 32 8) Bottom And Top Resistance Photo 2: Left View Photo 1: Left View Photo 4: Right View Photo 3: Right View Disconnect all cable connections for bottom and top resistances.
  • Page 33 Photo 5: Inside Of Oven Photo 6 Remove screws that connect the resistances to body and pull back them to take out. 9) Plug Photo 2 Photo 1 Cut the heat shrink and disconnect cables carefully. Finally remove nut to replace plug.
  • Page 34 10) Oven Lamp (If you don’t have oven lamp in your product, please skip this step.) Photo 1 Photo 2: External View Turn the lamp glass and lamp to replace oven lamp and flex slot to take out lamp holder and push it. 11) Turbo Fan (If you don’t have turbo fan in your product, please skip this step.) Photo 1 Remove screws to take out turbo fan and disconnect cables.
  • Page 35 12) Turnspit (If you don’t have turnspit in your product, please skip this step.) Photo 1 Remove screws to take out turbo fan and disconnect cable connections. Photo 2: Inter View Photo 3: External View Flex tabs and push to take out metal on the other side of turnspit.

  • Page 36: Circuit Diagrams

    2.2.5. Circuit Diagrams: *If you have another product except these options, please ask an expert or contact with us. Midi oven 0+3 with grill and oven lamp Midi oven 0+5 with grill, turnspit and oven lamp...

  • Page 37: Liter

    2.3. 40 Liter 2.3.1. Technical Specifications: SPECIFICATIONS 40 LTR Outer Width 575 mm Outer Depth 380 mm Outer Height 300 mm Inner Width 430 mm Innet Depth 310 mm Inner Height 240 mm Thermostat 40-240 ◦C Timer 0-90 min. Bottom Heater 700 W Top Heater 600 W...

  • Page 38: Technical Tables

    2.3.2. Technical Tables: *All models are included.

  • Page 41: Description Of Oven And Control Panel

    2.3.3. Description Of Oven And Control Panel: 1. Control Panel 8. Control Knobs 2. Oven Frame 9. Round Tray 3. Handle 10. Square Tray 4. Vessel 11. Rack Grill 5. Heaters 12. Hotplate(Option) 6. Oven Feet 13. Turnspit(Option) 7. Glass Oven Door 14.

  • Page 42: Component Disassembly/Assembly

    2.3.4. Component Disassembly/Assembly: 1) Panel Function Knobs Photo 1 Photo 2 Pull back standard knobs on panel and take them out. 2) Control Panel Photo 1 Photo 2...
  • Page 43 Photo 3 Photo 4 Remove 2 screws and take out panel. When take out panel attention to tab (look at the third photograph). Lift up panel little bit and slide down carefully. There is a signal lamp, take out it. 3) Sheet Metal of Body Photo 1: Front Surface Photo 2: Sub-surface...
  • Page 44 Photo 4: Final Situation Photo 3: Rear Surface Take out sheet metal removing screws on the front surface after opening oven door, on sub-surface and on rear surface respectively. 4) Oven Door Photo 1 Photo 2 First take out the metal spring. Remove 2 screws under the oven and 1 screw on the corner left side.
  • Page 45 Photo 3 Photo 4: Final Situation Remove 2 screws on right side of oven door. 5) Handle Photo 1 Remove 2 screws to take out handle.
  • Page 46 6) Mechanic Timer Thermostat Timer Switch Photo 1: Front View Photo 2: Back View Photo 4: Final Situation Photo 3 Pull mechanic timer back after removing two screws that connect the mechanic timer to panel. Please pay attention to alignment for mechanic timer, thermostat and switch. Follow the cable connections and disconnect it.
  • Page 47 7) Thermostat Photo 1 Photo 2 Remove two screws that connect the mechanic thermostat to the knob and take out thermostat. Follow the cable connections and disconnect it. 8) Switch(Commutator) Photo 1 Photo 2 Remove 2 screws that connect commutator to panel and take out it pulling back. Follow the cable connections and disconnect it.
  • Page 48 9) Bottom Sheet Metal Photo 2 Photo 1 Remove the screws and separate sheet metal as you see in second photograph. 10) Bottom Resistance Photo 2: Clips Photo 1 Photo 3: Clips (View From Inside) Disconnect cable connections out of body for bottom resistance. Press clips with pliers from outside and get it out from inside that connect the resistance to the inside of body.
  • Page 49 11) Top Resistance Photo 1 Photo 2 Photo 3: Sub-surface Disconnect cable connections out of body for top resistance. First remove the screw. Press clips with pliers from outside and get it out from inside that connect the resistance to the inside of body.
  • Page 50 12) Plug Photo 1 Photo 2 Cut the heat shrink and disconnect cables carefully. Finally remove nut to replace plug. 13) Turbo Fan (If you don’t have turbo fan in your product, skip this step.) Photo 1 Remove screws to take out turbo fan and disconnect cable connections.
  • Page 51 14) Oven Lamp (If you don’t have oven lamp in your product, please skip this step.) Photo 1 Turn the lamp to replace oven lamp and flex slot to take out lamp holder after disconnecting cables. 15) Turnspit (If you don’t have turnspit in your product, please skip this step.) Photo 1 Remove screws to take out turnspit and disconnect cable connection.

  • Page 52: Circuit Diagrams

    2.3.5. Circuit Diagrams: *If you have another product except these options, please ask an expert or contact with us. Midi oven (0+3) with oven lamp Midi oven (0+5) with turnspit and oven lamp...

  • Page 53: Liter

    2.4. 42 Liter 2.4.1. Technical Specifications: SPECIFICATIONS 42 LTR Outer Width 520 mm Outer Depth 440 mm Outer Height 330 mm Inner Width 397 mm Innet Depth 385 mm Inner Height 240 mm Thermostat 40-240 ◦C Timer 0-90 min. Bottom Heater 650 W Top Heater 650 W...

  • Page 54: Technical Tables

    2.4.2. Technical Tables: *All models are included.

  • Page 57: Description Of Oven And Control Panel

    2.4.3. Description Of Oven And Control Panel: 1. Control Panel 8. Control Knobs 2. Oven Frame 9. Round Tray 3. Handle 10. Square Tray 4. Vessel 11. Rack Grill 5. Heaters 12. Hotplate (Option) 6. Oven Feet 13. Turnspit (Option) 7.

  • Page 58: Component Disassembly/Assembly

    2.4.4. Component Disassembly/Assembly: 1) Knobs Photo 1 Photo 2 Pull back standard knobs on panel and take out.
  • Page 59 2) Cover Glass Photo 1 Photo 2 Photo 3 Photo 4 Separate the metal from glass carefully with the help of a screwdriver, without damaging to the glass and take out glass by paying attention to the hole on right.
  • Page 60 3) Handle Photo 1 Remove two screws to take out handle. 4) Frame Photo 2: Sub-View Photo 1: Rear View Remove the screws on rear surface and sub-surface to take out frame.
  • Page 61 5) Mechanic Timer, Thermostat And Switch Timer Thermostat Switch Photo 1 Photo 2: Timer Remove screws that connect timer, thermostat and switch to control panel and take out them. Photo 3: Thermostat Photo 4: Switch...
  • Page 62 6) Panel And Signal Lamp Photo 1 Separate the tabs and take out panel carefully. Take out signal lamp pulling back.
  • Page 63 7) Front Panel Photo 1 Photo 2 Photo 4 Photo 3 Take out the metal spring. Remove 6 screws to take out front panel. When take out panel attention to tabs.
  • Page 64 8) Bottom And Top Resistance Photo 2 Photo 1 Disconnect cable connection for resistances. Photo 3: Sub-surface Photo 4 Press clips with pliers from outside for bottom resistance and get out from inside clips that connect the resistance to the inside of body. Remove resistance pulling back from the hole on side.
  • Page 65 Photo 5:Top Surface Photo 6 Press clips with pliers from outside for top resistance and get clips out from inside that connect the resistance to the inside of body. Remove resistance pulling back from the hole on side. Photo 7: Holes for resistance on side Photo 8: Holes for resistance on side...
  • Page 66 9) Plug Photo 2 Photo 1 Cut the heat shrink and disconnect cables carefully. Finally remove nut to replace plug. 10) Oven Lamp (If you don’t have oven lamp in your product, please skip this step.) Photo 2 Photo 1 Turn the lamp to replace oven lamp and flex slot to take out lamp holder after disconnecting cables.
  • Page 67 11) Turbo Fan (If you don’t have turbo fan in your product, please skip this step.) Photo 1 Remove screws to take out turbo fan. 12) Turnspit (If you don’t have turnspit in your turnspit, please skip this step.) Photo 1 Disconnect cables and remove screws to take out turnspit.

  • Page 68: Circuit Diagrams

    2.4.5. Circuit Diagrams: *If you have another product except these options, please ask an expert or contact with us. Midi oven (0+3) with lamp Midi oven (0+5) with lamp...
  • Page 69 Midi oven (0+6)
  • Page 70 Midi oven (0+3) with turnspit and without lamp...

  • Page 71: Liter

    2.5. 45 Liter 2.5.1. Technical Specifications: SPECIFICATIONS 45 LTR Outer Width 595 mm Outer Depth 470 mm Outer Height 330 mm Inner Width 440 mm Innet Depth 420 mm Inner Height 240 mm Thermostat 40-240 ◦C Timer 0-90 min. Bottom Heater 800 W Top Heater 600 W...

  • Page 72: Technical Tables

    2.5.2. Technical Tables:...

  • Page 76: Description Of Oven And Control Panel

    2.5.3. Description Of Oven And Control Panel: 1. Control Panel 7. Glass Oven Door 2. Oven Frame 8. Control Knobs 3. Handle 9. Round Tray 4. Vessel 10. Square Tray 5. Heaters 11. Rack Grill 6. Oven Feet  Timer: Set the timer according to the recommended cooking time at the desired thermostat value.

  • Page 77: Component Disassembly/Assembly

    2.5.4. Component Disassembly/Assembly: 1) Knobs Photo 1 Photo 2 Pull back standard knobs on panel and take out.
  • Page 78 2) Cover Glass Photo 1 Photo 2 Photo 3 Photo 4 Separate the metal from glass carefully with the help of a screwdriver, without damaging to the glass and take out glass by paying attention to the hole on right.
  • Page 79 3) Handle Photo 1 Remove two screws to take out handle. 4) Frame Photo 1: Rear View Photo 2: Sub-View Remove the screws on rear surface and sub-surface to take out frame.
  • Page 80 5) Mechanic Timer, Thermostat And Switch Timer Thermostat Switch Photo 1 Photo 2: Timer Photo 4: Switch Photo 3: Thermostat Remove screws that connect mechanic timer, thermostat and switch to control panel and take out them. Disconnect cables carefully.
  • Page 81 6) Panel And Signal Lamp Photo 1 Photo 2: Final Situation Separate the tabs and take out panel carefully. Take out lamp pulling back. 7) Metal Spring Photo 1 Take out the metal spring to disassemble front panel.
  • Page 82 8) Front Panel Photo 2 Photo 1 Photo 3 Photo 4 Remove screws to take out panel. When take out panel attention to tabs. After taking out panel, bottom sheet metal will be separated. Follow next step.
  • Page 83 9) Bottom And Top Resistance Photo 1 Disconnect cable connections for resistances. Photo 3: Sub-surface Photo 2 Press clips with pliers from outside for bottom resistance and get out from inside clips that connect the resistance to the inside of body. Remove resistance pulling back from the hole on side.
  • Page 84 Photo 4 Photo 5: Top Surface Press clips with pliers from outside for top resistance and get clips out from inside that connect the resistance to the inside of body. Remove resistance pulling back from the hole on side. 10) Plug Photo 1 Photo 2 Cut the heat shrink and disconnect cables carefully.
  • Page 85 11) Turbo Fan (If you don’t have turbo fan in your product, skip this step.) Photo 1 Remove screws that connect turbo fan to sheet metal to take out and disconnect cable connections. 12) Oven Lamp (If you don’t have oven lamp in your product, please skip this step.) Photo 2: External View Photo 1 Turn the lamp to replace lamp glass and oven lamp.
  • Page 86 13) Turnspit (If you don’t have turnspit in your product, please skip this step.) Photo 1 Disconnect cable connections and remove screws that connect turnspit to sheet metal. There is a metal opposite turn spit on other side, flex it carefully and push to take out.

  • Page 87: Circuit Diagrams

    2.5.5. Circuit Diagrams: *If you have another product except these options, please ask an expert or contact with us. Midi oven (0+3) with lamp...
  • Page 88 Midi oven 0+5 with lamp...
  • Page 89 Midi Oven with (0+5) with lamp and turnspit...
  • Page 90 Midi Oven (0+6) with grill and lamp...

  • Page 91: Liter

    2.6. 70 Liter 2.6.1. Technical Specifications: SPECIFICATIONS 70 LTR Outer Width 632 mm Outer Depth 485 mm Outer Height 477.5 mm Inner Width 466 mm Innet Depth 390 mm Inner Height 283 mm Thermostat 40-240 ◦C Timer 0-90 min. Bottom Heater 1000 W Top Heater 800 W...

  • Page 92: Technical Tables

    2.6.2. Technical Tables: *All models are included.

  • Page 94: Description Of Oven And Control Panel

    2.6.3. Description Of Oven And Control Panel: 1. Control Panel 7. Glass Oven Door 2. Oven Frame 8. Control Knobs 3. Handle 9. Round Tray 4. Vessel 10. Square Tray 5. Heaters 11. Rack Grill 6. Oven Feet  Timer: Set the timer according to the recommended cooking time at the desired thermostat value.

  • Page 95: Component Disassembly/Assembly

    2.6.4. Component Disassembly/Assembly: 1) Knobs Photo 1 Photo 2 Pull back standard knobs on panel and take out.
  • Page 96 2) Frame Photo 1: Rear Surface Photo 2: Sub-surface Photo 3: Final Situation Remove screws on rear surface and sub-surface to take out frame.
  • Page 97 3) Internal Glass Photo 2: Final Situation Photo 1 First take out plastics and pull the glass back carefully to take out. 4) Oven Door Photo 2: Sub-View Photo 1...
  • Page 98 Photo 4 Photo 3 Photo 6: Final Situation Photo 5 First remove 2 screws that appear at the first photograph. After this remove 2 screws under the oven (Follow second photograph). Put little shafts into the holes on sides of oven. Holes are being shown in third and fourth photograph. Press with the help of a screwdriver to the tabs that appear at the fifth photo and pull oven door back to take out.
  • Page 99 5) Control Panel And Signal Lamp Photo 1 Photo 2 Photo 3 Photo 4: Final Situation Disconnect cables for button of turbo fan and take out signal lamp, pulling back. Straighten the tabs that appear in photo and push it from left side, and pull back panel from front side.
  • Page 100 6) Mechanic Timer, Thermostat and Switch Timer Thermostat Switch Photo 1 Photo 2 Remove screws and disconnect cables to take out the mechanic timer, thermostat and switch.
  • Page 101 7) Handle Photo 1 Remove screws to take out and replace handle.
  • Page 102 8) Front Panel Photo 2 Photo 1 Photo 3 Photo 4 Photo 5 Photo 6 Remove screws to take out front panel on right, left, top, bottom internal side of panel and on bottom front surface.
  • Page 103 9) Bottom Resistance Hiding Sheet Metal Photo 2: Final Situation Photo 1 Remove 6 screws on bottom side inside of oven and separate side sheet metals. 10) Bottom And Top Resistance Photo 1 Photo 2 Disconnect cable connection for top and bottom resistances.
  • Page 104 Photo 3: Sub-surface Photo 4 Press clips with pliers from outside for bottom resistance and get out from inside clips that connect the resistance to the inside of body. Remove resistance pulling back from the hole on side. Photo 6 Photo 5:Top Surface Press clips with pliers from outside for top resistance and get clips out from inside that connect the resistance to the inside of body.
  • Page 105 11) Plug Photo 2 Photo 1 Remove the screws and disconnect cables to replace plug. 12) Turbo Fan (If you don’t have turbo fan in your product, skip this step.) Oven Lamp Turnspit Turbo Fan Photo 1 Remove screws to take out turbo fan and get it out.
  • Page 106 13) Oven Lamp (If you don’t have oven lamp in your product, please skip this step.) Photo 2: External View Photo 1 Turn the lamp glass ans lamp to replace oven lamp. Flex tabs and get lamp holder fron inside. 14) Turnspit (If you don’t have turnspit in your product, please skip this step.) Photo 1: External View Photo 2...
  • Page 107 Photo 3 Photo 4: External View Flex tabs to take out turnspit metal from outside.

  • Page 108: Circuit Diagrams

    2.6.5. Circuit Diagrams: *If you have another product except these options, please ask an expert or contact with us. Midi oven (0+3) with lamp...
  • Page 109 Midi oven 0+5 with lamp...
  • Page 110 Midi Oven with (0+5) with lamp and turnspit...
  • Page 111 Midi Oven (0+6) with grill and lamp...

  • Page 112: Midi Oven With Hotplate (35, 40 And 42 Liter Oven)

    2.7. Midi Oven With Hotplate (35, 40 and 42 Liter Oven) 2.7.1. Component Disassembly/Assembly: 35 LITER: 1) Knobs Photo 1 Photo 2 Pull back standard knobs on panel and take out.
  • Page 113 2) Control Panel Photo 1 Photo 2 Photo 3:Final Situation Remove 2 screws to take out control panel and lift it up little bit from the bottom side to take out signal lamps for switch and hotplate, disconnect cables for turnspit (If you have turnspit option). After that slide panel down and take out it.
  • Page 114 3) Frame Photo 1: Rear View Photo 2: Sub-View Photo 4: Final Situation Photo 3: Front View Remove the screws on rear surface, sub-surface and front surface. Take out frame without damaging cable connections for hotplate.
  • Page 115 4) Hotplate Photo 2: Front View Photo 1 Photo 3 Photo 4 Remove nuts to replace hotplate. Electrical connection should be disconnected.
  • Page 116 5) Oven Door Photo 1 Photo 2 Photo 3: Final Situation Take out spring metal and remove screws to take out oven door.
  • Page 117 6) Mechanic Timer Thermostat Timer Switch Switch (For Hotplate) Photo 2 Photo 1 Remove screws and take out the mechanic timer. Disconnect cables carefully and pay attention for line.
  • Page 118 7) Thermostat Thermostat Timer Switch Switch (For Hotplate) Photo 1 Photo 2 Remove screws and take out the thermostat. Disconnect cables carefully.
  • Page 119 8) Switch(Commutator) Thermostat Timer Switch Switch (For Hotplate) Photo 2 Photo 1 Remove screws and take out the switch. Disconnect cables carefully.
  • Page 120 9) Hotplate Switch Thermostat Timer Switch Switch (For Hotplate) Photo 1 Photo 2 Remove screws and take out the switch. Disconnect cables carefully.
  • Page 121 10) Bottom And Top Resistance Photo 1: Left View Photo 2: Left View Photo 4: Right View Photo 3: Right View Disconnect all cable connections for bottom and top resistances.
  • Page 122 Photo 5: Inside Of Oven Photo 6 Remove screws that connect the resistance to body and pull back it to take out. 11) Plug Photo 2 Photo 1 Cut the heat shrink and disconnect cables carefully. Finally remove nut to replace plug.
  • Page 123 12) Oven Lamp (If you don’t have oven lamp in your product, please skip this step.) Photo 1 Photo 2: External View Turn the lamp glass and lamp to replace oven lamp and flex slot to take out lamp holder and push it. 13) Turbo Fan (If you don’t have turbo fan in your product, please skip this step.) Photo 1 Remove screws to take out turbo fan and get it out.
  • Page 124 14) Turnspit (If you don’t have turnspit in your product, please skip this step.) Photo 1 Remove screws to take out turbo fan. Photo 2: Inter View Photo 3: External View Flex tabs and push to take out metal for turnspit.
  • Page 125 40 LITER: 1) Knobs Photo 2 Photo 1 Pull back standard knobs on panel and take out.
  • Page 126 2) Control Panel Photo 1 Photo 2 Photo 3:Final Situation Remove 2 screws to take out control panel and lift it up little bit from the bottom side to take out signal lamps for switch and hotplate, disconnect cables for turnspit (If you have turnspit option). After that slide panel down and take out it.
  • Page 127 3) Frame Photo 1: Rear View Photo 2: Sub-View Photo 4: Final Situation Photo 3: Front View Remove the screws on rear surface, sub-surface and front surface. Take out frame without damaging cable connections for hotplate.
  • Page 128 4) Hotplate Photo 2: Front View Photo 1 Photo 3 Photo 4 Remove nuts to replace hotplate. Electrical connection should be disconnected.
  • Page 129 5) Oven Door Photo 1 Photo 2 Photo 3: Final Situation Take out spring metal and remove screws to take out oven door.
  • Page 130 6) Mechanic Timer Thermostat Timer Switch Switch (For Hotplate) Photo 2 Photo 1 Remove screws and take out the mechanic timer. Disconnect cables carefully and pay attention for line.
  • Page 131 7) Thermostat Thermostat Timer Switch Switch (For Hotplate) Photo 1 Photo 2 Remove screws and take out the thermostat. Disconnect cables carefully.
  • Page 132 8) Switch(Commutator) Thermostat Timer Switch Switch (For Hotplate) Photo 2 Photo 1 Remove screws and take out the switch. Disconnect cables carefully.
  • Page 133 9) Hotplate Switch Thermostat Timer Switch Switch (For Hotplate) Photo 1 Photo 2 Remove screws and take out the switch. Disconnect cables carefully.
  • Page 134 10) Bottom And Top Resistance Photo 1: Left View Photo 2: Left View Photo 4: Right View Photo 3: Right View Disconnect all cable connections for bottom and top resistances.
  • Page 135 Photo 5: Inside Of Oven Photo 6 Remove screws that connect the resistance to body and pull back it to take out. 11) Plug Photo 2 Photo 1 Cut the heat shrink and disconnect cables carefully. Finally remove nut to replace plug.
  • Page 136 12) Oven Lamp (If you don’t have oven lamp in your product, please skip this step.) Photo 1 Photo 2: External View Turn the lamp glass and lamp to replace oven lamp and flex slot to take out lamp holder and push it. 13) Turbo Fan (If you don’t have turbo fan in your product, please skip this step.) Photo 1 Remove screws to take out turbo fan and get it out.
  • Page 137 14) Turnspit (If you don’t have turnspit in your product, please skip this step.) Photo 1 Remove screws to take out turbo fan. Photo 2: Inter View Photo 3: External View Flex tabs and push to take out metal for turnspit.
  • Page 138 42 LITER: 1) Knobs Photo 1 Photo 2 Pull back standard knobs on panel and take out.
  • Page 139 2) Cover Glass Photo 1 Photo 2 Photo 3 Photo 4 Separate the metal from glass carefully with the help of a screwdriver, without damaging to the glass and take out glass by paying attention to the hole on right.
  • Page 140 3) Frame Photo 2: Sub-View Photo 1: Rear View Photo 3 Remove the screws on rear surface and sub-surface to take out frame. Take out frame without damaging cable connections for hotplate.
  • Page 141 4) Hotplate Photo 2: Front View Photo 1 Photo 4 Photo 3 Disconnect cable connections and remove nuts to separate frame and hotplate.
  • Page 142 5) Mechanic Timer Thermostat Timer Switch Switch (For Hotplate) Photo 2 Photo 1 Remove screws and take out the mechanic timer. Disconnect cables carefully and pay attention for line.
  • Page 143 6) Thermostat Thermostat Timer Switch Switch (For Hotplate) Photo 1 Photo 2 Remove screws and take out the thermostat. Disconnect cables carefully.
  • Page 144 7) Switch(Commutator) Thermostat Timer Switch Switch (For Hotplate) Photo 2 Photo 1 Remove screws and take out the switch. Disconnect cables carefully.
  • Page 145 8) Hotplate Switch Thermostat Timer Switch Switch (For Hotplate) Photo 1 Photo 2 Remove screws and take out the switch. Disconnect cables carefully.
  • Page 146 9) Bottom And Top Resistance Photo 2 Photo 1 Disconnect cable connection for resistances. Photo 3: Sub-surface Photo 4 Press clips with pliers from outside for bottom resistance and get out from inside clips that connect the resistance to the inside of body. Remove resistance pulling back from the hole on side.
  • Page 147 Photo 5:Top Surface Photo 6 Press clips with pliers from outside for top resistance and get clips out from inside that connect the resistance to the inside of body. Remove resistance pulling back from the hole on side. Photo 7: Holes for resistance on side Photo 8: Holes for resistance on side...
  • Page 148 10) Plug Photo 2 Photo 1 Cut the heat shrink and disconnect cables carefully. Finally remove nut to replace plug. 11) Oven Lamp (If you don’t have oven lamp in your product, please skip this step.) Photo 2 Photo 1 Turn the lamp to replace oven lamp and flex slot to take out lamp holder after disconnecting cables.
  • Page 149 12) Turbo Fan (If you don’t have turbo fan in your product, please skip this step.) Photo 1 Remove screws to take out turbo fan. 13) Turnspit (If you don’t have turnspit in your turnspit, please skip this step.) Photo 1 Disconnect cables and remove screws to take out turnspit and flex slot to take out metal on opposite side.

  • Page 150: Circuit Diagrams

    2.7.2. Circuit Diagrams: *If you have another product except these options, please ask an expert or contact with us. 35 Liter midi oven (0+3) with grill, oven lamp and 2 hotplates...
  • Page 151 40 Liter midi oven (0+3) with oven lamp and 2 hotplates...
  • Page 152 42 Liter midi oven (0+5) with turbo fan, oven lamp and 2 hotplates SELECTOR SWITCH DIAGRAM...

  • Page 153: If The Oven Does Not Work

    3. IF THE OVEN DOES NOT WORK...
  • Page 154 Footnote: Knobs, handles, panel serigraphies that are seen throughout this service manual may vary depending on the product you have purchased.

Table of Contents
