- Page 1 aura UHD Gen 2 aura UHD 24/27/32 Gen 2 12G-SDI Professional Film and Television Production Monitor User Manual Article NO: RGB-RD-UM-aura UHD Gen 2 E001 Version NO: V1.1...
-
Page 2: Table Of Contents
Content Content ..................................1 Declarations ................................3 FCC/Warranty ..............................3 Operators Safety Summary ..........................3 Installation Safety Summary .......................... 4 Chapter 1 Your Product ............................5 1.1 In the Box ..............................5 1.2 Product Overview ............................5 1.2.1 Front Panel ............................6 1.2.2 Rear Panel ............................7 1.2.3 Side Panel ............................ - Page 3 2.1.8 Marker .............................. 27 2.1.9 Multi Screen ............................28 2.1.10 Audio .............................. 29 2.1.11 UMD ..............................31 2.1.12 System ............................32 Chapter 3 Ordering Codes ............................34 3.1 Product Code ............................. 34 Chapter 4 Support ..............................35 4.1 Contact Us ..............................35 Chapter 5 Upgrade ..............................36 5.1 Network Upgrade Program Description ....................36 5.2 How to Calibrate Monitor ........................
-
Page 4: Declarations
Thank you for choosing our product! This User Manual is designed to show you how to use this monitor quickly and make use of all the features. Please read all directions and instructions carefully before using this product. Declarations FCC/Warranty Federal Communications Commission (FCC) Statement This equipment has been tested and found to comply with the limits for a class A digital device, pursuant to Part 15 of the FCC rules. -
Page 5: Installation Safety Summary
The general safety information in this summary is for operating personnel. Do Not Remove Covers or Panels There are no user-serviceable parts within the unit. Removal of the top cover will expose dangerous voltages. To avoid personal injury, do not remove the top cover. Do not operate the unit without the cover installed. Power Source This product is intended to operate from a power source that will not apply more than 230 volts rms between the supply conductors or between both supply conductor and ground. -
Page 6: Chapter 1 Your Product
Chapter 1 Your Product 1.1 In the Box Power Adapter 1.2 Product Overview aura UHD Gen 2 is broadcast-grade 4K HDR monitor, equipped with UHD (3840×2160) screen, supports quad link 12G SDI signal up to 8K input backward compatible with 4K@60Hz, supports high-precision 3D LUT with tetrahedral interpolation algorithm, supports HDR formats such as SMPTE ST2084(PQ), hybrid log-gamma HLG, various Gamma curves, camera Log and other professional functions which are widely used in film, television and advertisement industry. -
Page 7: Front Panel
1.2.1 Front Panel ❶ ❶ ❷ ❷ ❿ ⓫ ⓬ ❸ ❹ ⓭ ❺ ❻ ① Speaker 2-channel speaker with HDMI and SDI embedded audio. ② Base Detachable. ③ SDI 1~ SDI 4 Buttons For SDI 1~4 signal selection. Switch between 4-image division mode and optical fiber ④... -
Page 8: Rear Panel
Save/load data. ● ⑧ F1 ~ F4 Buttons Soft Keys for customized function. ⑨ CONTRAST/BRIGHT Button Adjust contrast and brightness value. ⑩ CHROMA/SHARP Button Adjust chroma and sharpness value. SELECT/ENTER Button Rotate to select, and press to confirm. ⑪ Open/close OSD menu. ●... - Page 9 ① Handle For carrying. ② 3.5mm Earphone Jack The speaker will be turned off when earphone is connected. ③ USB Interface For software upgrade. ④ RS422 Interface In and Loop. ⑤ GPI interface to achieve remote control. ⑥ Network Port For connecting network cable.
- Page 10 Data reception (+) Data reception (-) Data transmission (+) Not Connected Not Connected GPI Interface Definition： Name Description GPI1 Low level trigger；preset functions in menu. GPI2 Low level trigger；preset functions in menu. GPI3 Low level trigger；preset functions in menu. GPI4 Low level trigger；preset functions in menu.
-
Page 11: Side Panel
1.2.3 Side Panel SFP Interface Insert optical fiber module (module is optional). ① aura UHD Gen 2 User Manual... -
Page 12: Dimensions
1.2.4 Dimensions Following is the dimension of monitor for your reference: aura UHD 24 Gen 2 Net Weight：8.6kg Dimension：571.7mm × 160mm × 414.85mm aura UHD Gen 2 User Manual... - Page 13 aura UHD 27 Gen 2 Net Weight：11.4kg Dimension：661mm × 420mm × 179mm aura UHD Gen 2 User Manual...
- Page 14 aura UHD 32 Gen 2 Weight：15.3kg Gross Weight：751mm × 502mm × 179mm aura UHD Gen 2 User Manual...
-
Page 15: Chapter 2 Use Your Product
Chapter 2 Use Your Product 2.1 Menu Main Menu Status Display User Preset Color Management Picture Scopes Auxiliary Function Display Marker Multi Screen Audio System The monitor comes with OSD menu for parameters adjustment and setting, such as image quality adjustment, input signal setting and more. - Page 16 Marker Multi Screen Audio System Basic Information Show Input Source, Resolution, Image Division, Scan Mode, Aspect Ratio, Zoom Mode, Freeze, Flip Mode, Multi Screen Mode, Key Lock, Audio Source, Volume. Color Information Show Color Preset Mode, Color Temp, Color Gamut, Gamma (EOTF), HDR Auto Setting, Backlight, Input Range, Contrast, Brightness, Chroma, Aperture.
-
Page 17: User Preset
2.1.2 User Preset User Preset: Preset function keys and GPI, and store, load and restore the preset values. Status Display F Button Preset User Preset F1 Button Color Management F2 Button Picture F3 Button Scopes F4 Button Auxiliary Function GPI Preset Display GPI1 Marker... -
Page 18: Color Management
Color preset mode, gamut, gamut contrast, gamut warning, camera log, color temperature, black level expansion, window selection, flip mode, static frame, waveform, single-line waveform, vector, histogram, audio table, auxiliary focus, false color, zebra, UMD, marker display, cross hatch, all-blue/black-white mode, time code, audio signal source, and so on. GPI Preset 5 presets available, which can achieve distant control, storage and load. - Page 19 Picture PQ Option Scopes HLG System Gamma Auxiliary Function Color Gamut Display Color Gamut Warning Marker Color Gamut Clipping Multi Screen Luminance Warning Audio EETF Camera Log System User Camera Log HDR Auto Setting Gamut Comparison Left Color Gamut Right Color Gamut Color Preset Mode Show BT.709, BT.2020, DCI-P3, PQ_DCI-P3, PQ_BT.2100, HLG_BT.2100, User 1-5 Backlight...
- Page 20 Show different brightness value: PQ-300, PQ-500, PQ-1000 HLG System Gamma 1.0, 1.1, 1.2, 1.3, 1.4, 1.5 Color Gamut Choose from： Origian, ITU-R BT.709,SMPTE-C,EBU,DCI-P3,ITU-R BT.2020,User 1-5 Gamut Warning: ON/OFF This function will show image beyond BT.709 in magenta, reminding that the image will not be able to display the color of the part beyond the monitor screen when editing with Rec.709.
- Page 21 actual brightness. When this function is turned on, the highest brightness of HDR is automatically mapped to the highest brightness of the monitor, and the details of the image will be preserved. When this function is turned off, the part of the image that exceeds the real brightness of the monitor will be saturated.
-
Page 22: Picture
Gamut Comparison: ON/OFF Can achieve comparison between left and right windows of different color gamut. Left/Right Color Gamut Choose from： Original,ITU-R BT.709,SMPTE-C,EBU,DCI-P3,ITU-R BT.2020,User 1-5. 2.1.4 Picture Picture：For adjustment of picture parameter. Status Display Input Range User Preset Brightness Color Management Contrast Picture Chroma... -
Page 23: Scopes
Blue Bias Copy Input Range Limited: 64-940 Full Range: 0-1023 SDI Range 4-1019 Extension: 64-1019 Brightness:-1024~1023 (Default:0) Contrast:-1024~1023 (Default:1024) Chroma: -50~50 (Default:0) Aperture: 0~100 (Default:50) Black Stretch: ON/OFF This function can enhance contrast Stretch Intensity: 0~1023 (Default:512) Color Temp: Choose from D55,D65（default）,D93,DCI-P3,User 1-3(Set the color temperature to save and load.) Red, Green, Blue Gain: 0~2047 (Default:1024) Red, Green, Blue Bias: -512~511 (Default:0) - Page 24 Scopes：To monitor, analyze and adjust video signals. Status Display Waveform User Preset Waveform Color Color Management WFM Single Line Picture WFM Line Count Scopes Vertical Height Auxiliary Function Vector Scope Display Vector Color Marker Histogram Multi Screen BG Transparency Audio Scopes Position System Waveform: OFF/Brightness Waveform/Component Waveform, RGB Waveform, RGB Superimposed...
-
Page 25: Auxiliary Function
Vertical Height: Display height of single-line waveform, choose from 128-lines, 256-lines and 512-line. Vector Scope: ON/OFF The color and saturation of the image are represented by waveform in a vector oscilloscope. The higher the saturation, the more stretched the waveform. Vector Color: white or green Histogram: Choose from：OFF, Brightness Histogram, RGB Histogram, RGB Superposition Histogram. -
Page 26: Display
Audio System False Color: ON/OFF Different false-color images are displayed when there are different exposure pictures in the image. Blue Only/Mono: Monochrome Mode Setting：OFF, All-Blue, Black-White, All-Red, All-Green Focus Assist: Choose from: OFF, Red, Blue, Green Focus Intensity: Set auxiliary focus intensity Zebra: ON/OFF Count the display area in the image where the Y value is greater than the set value, and mark it with a white slash. - Page 27 Display: Settings of various display modes. Status Display Aspect Ratio User Preset Scan Mode Color Management Zoom Mode Picture Flip Mode Scopes Freeze Auxiliary Function Cross Hatch Display Marker Multi Screen Audio System Aspect Ratio Choose from：AUTO,1:1,16:9,4:3,2.35:1,1.85:1,15:9,16:10 Scan Mode Choose from: Zero Scan, Overscan. Zoom Mode: Achieve a partial amplification of the image.
-
Page 28: Marker
ON: To capture and display a current image. OFF: Continue to play the video. Cross Hatch: OFF/ON This function can display grid lines to help focus different objects. 2.1.8 Marker Marker：Settings of various marking lines. Status Display Marker Display User Preset Aspect Marker Color Management Center Marker... -
Page 29: Multi Screen
Aspect Marker ： Choose from: OFF,16:9,15:9,14:9,13:9,4:3,2.35:1,1.85:1 Center Mark: OFF ,Type 1,Type 2 Safety Area Choose from: OFF,80%,85%,88%,90%,93% Fit Marker: ON/OFF ON: Safe area with aspect ratio OFF: Safe area with screen ratio Marker Outside: Choose from: OFF, Black, Gray, Translucent Line Color Choose from：White, Red, Green, Blue, Black, Gray Line Thickness... -
Page 30: Audio
Scopes Screen D Input Auxiliary Function Screen A Color Mode Display Screen B Color Mode Marker Screen C Color Mode Multi Screen Screen D Color Mode Audio Screen Border Screen A Border Color System Screen B Border Color Screen C Border Color Screen D Border Color Multi Screen Mode: Display multiple signal sources on the same screen Choose from: OFF, Side 3-Split, Bottom 3-Split, Live Broadcast Mode, PBP, PAP... - Page 31 Audio: Settings of audio and audio meter table. Status Display Audio Source User Preset Speaker Out Left Color Management Speaker Out Right Picture Volume Scopes Audio Level Meter Auxiliary Function Meter Direction Display Marker Multi Screen Audio System Audio Source Choose from ：Undefined, embedded audio Speaker Out Left/Right ：...
-
Page 32: Umd
2.1.11 UMD UMD：Settings of UMD, TSL, Baud Rate. Status Display UMD Display User Preset Character Color Color Management UMD Position Picture UMD Size Scopes UMD Transparency Auxiliary Function Display Type Display UMD Standard Marker UMD ID Multi Screen Baud Rate Audio Source Name System... -
Page 33: System
Transparency Choose from：OFF,Low,High Display Type: Source ID,UMD UMD Standard: OFF,TSL V3.1,TSL V4.0,TSL V5.0 UMD ID: 0~127 (Default: 0) Baud Rate: 38400,8,e,1 ; 115200,8,e,1 Source Name: Set name of UMD source 2.1.12 System System: Settings of Key Lock, Language, Menu Transparency and more. Status Display Key Lock User Preset... - Page 34 System Key Lock: OFF/Full Lock Full Lock: All function keys are locked and cannot be used. Users need to enter the menu to select OFF for reuse. Language: English/Simplified Chinese Menu Timer: 5s, 10s, 30s, 60s (OSD disappears after the corresponding time.) Menu Position: Choose from: Top Left, Top Right, Middle, Left, Right Menu Transparency...
-
Page 35: Chapter 3 Ordering Codes
Chapter 3 Ordering Codes 3.1 Product Code 410-2380-01-0 aura UHD 24 Gen 2 23.8 Inch 12G-SDI HDR Monitor 410-2700-01-0 aura UHD 27 Gen 2 27 Inch 12G-SDI HDR Monitor 410-3200-01-0 aura UHD 32 Gen 2 32 Inch 12G-SDI HDR Monitor 3.2 Others 490-2000-01-0 V mount battery plate kit for aura UHD 24 Gen 2... -
Page 36: Chapter 4 Support
Chapter 4 Support 4.1 Contact Us aura UHD Gen 2 User Manual... -
Page 37: Chapter 5 Upgrade
Chapter 5 Upgrade 5.1 Network Upgrade Program Description Preparations before the upgrade: 1. Connect the computer and monitor with Ethernet network cable. (The default IP address is 192.168.1.128.) 2. Set the Ethernet to a fixed IP address on the PC. 3. - Page 38 5.On the Internet Protocol Version 4(TCP/IPv4) Properties page, select Use the following IP addresses and set the following parameters: IP Address, Subnet Mask, Default Gateway. Note: 100 in the IP Address figure can be other values as long as it does not conflict with 192.168.1.128 in the monitor, but it must be on the same network segment.
- Page 39 Upgrade monitor program: 1. Double-click pdtools.exe in the pdtools_ folder. The following page is displayed，If a firewall is displayed to block the change software, please allow access. aura UHD Gen 2 User Manual...
- Page 40 2. Click "Refresh Device" on the interface. If the computer is connected to the monitor normally, the following interface will be displayed. If PD TOOL connection fails, disconnect wifi. 3. Click "Upgrade" in the above interface to display the upgrade interface, as shown in the following figure.
- Page 41 4.Click browse -choose target Bin File. 5.Click "Upgrade" on the upgrade interface, as shown below. Upgrading. aura UHD Gen 2 User Manual...
-
Page 42: How To Calibrate Monitor
Upgrading. 6.Update complete. 5.2 How to Calibrate Monitor Prepare: 1.Calibrate software-installed on PC 2.Calibration tool-connect to the same PC 3.DaVinci Resolve+BMD DeckLink Mini Monitor 4K(or other SDI PCIe output card) --installed on the same PC 4.Monitor aura UHD Gen 2 User Manual... -
Page 43: Lut File Upload Operating Instructions
Calibration tool Connect to PC PC with Software：calibration Camera or probe +DaVinCi Resolve Monitor Hardware： BMD decklink mini monitor 4K Export 3D LUT file in .3dl upload 3D LUT file to monitor PC with software：PD Tool 5.3 3D LUT File Upload Operating Instructions Prepare: Before upgrade, unzip the PD tool package. - Page 44 (TCP/IPv4) Properties interface, choose Use the following IP address, fill the IP address, Subnet mask, Default gateway. Remark: IP address the 100 can be other values, as long as it does not conflict with 192.168.1.128, but it must on the same network segment. 3.
- Page 45 5.Click "Upgrade" in the interface, the pop-up interface is as follows, and click "merge files". 6.Click "Checked" behind USER1/USER2/USER3/USER4/USER5. If you only upgrade USER1 and USER2, you only need to click Select behind USER1 and USER2 to select, and then click "Browse" to select the 3D LUT file to be upgraded, the file should be in .3dl format.
- Page 46 7.Finally, click“Browse” to select location file for merged 3d lut file "Merge Selected Files". After output path is selected, optionally filling in project name and user text and then click “Merge selected files” . The merged file will be stored in the selected file path. aura UHD Gen 2 User Manual...
- Page 47 8.Click "Upgrade Files" on the upgrade interface, as shown below. 9.Select "browse". Select the merged file generated from last step. aura UHD Gen 2 User Manual...
- Page 48 Finally, click “Upgrade”. aura UHD Gen 2 User Manual...
-
Page 49: Chapter 6 Appendix
Chapter 6 Appendix 6.1 Specification Model aura UHD 24 Gen 2 aura UHD 27 Gen 2 aura UHD 32 Gen 2 Physical Net Weight 8.6kg 11.4kg 15.3kg Packaged 12kg 15.3kg 20.6kg Weight 571.7 × 160 × 414.85mm 661 × 420 × 179mm 751 ×... - Page 50 Video Signal SDI Signal 1080p@50/59.94/60 Format Format 1080p@23.98/24/25/29.97/30 720p@50/59.94/60 3840×2160p@23.98/24/25/29.97/30/50/59.94/60 2048×1080@23. 98/24/25/29.97/30p/psf, 47.95/48/50/59.94/60p 3840×2160p@24/25/30 HDMI Signal 720p@50/59.94/60;1080i@50/59.94/60 Format 1080p@23.98/24/25/29.97/30/50/59.94/60 3840×2160p@23.98/24/25/29.97/30/50/59.94/60 4096×2160p@23.98/24/25/29.97/30/50/59.94/60 Audio Audio Support De-embedding Audio Meter 16 channels （Up to 8 channels can be displayed simultaneously.） Built-in Speaker 1×8 ohm/0.5W Headphone Stereo mini jack×1 General...
-
Page 51: Supported Signal Format
Operating 30%～85%, RH Humidity Storage -20-60℃ Humidity 6.2 Supported Signal Format SDI Signal Format Single Link Division Protocol Resolution Color Space Frame Rate Mode Method 60P, 60/1.001p, 50p, 30P, SMPTE-296M 1280×720 4:2:2, YCbCr, 10bit 30/1.001p, 25p, 24p, 24/1.001p 30p, 30/1.001p, 25p, 24p, 24/1.001p SMPTE-274M 1920×1080... - Page 52 4:4:4, YCbCr/ 30PsF, 30/1.001PsF, 25PsF, B-DL YCbCrA, 10bit 24PsF, 24/1.001PsF 30p, 30/1.001p, 25p, 24p, 24/1.001p Level A 4:4:4, RGB, 12bit SMPTE-274M 1920×1080 30PsF, 30/1.001PsF, 25PsF, Level 4:4:4, YCbCr, 12bit 24PsF, 24/1.001PsF B-DL 60i, 60/1.001i, 50i 30p, 30/1.001p, 25p, 24p, Level A SMPTE-2048 4:4:4, RGB, 12bit 24/1.001p...
- Page 53 SMPTE-2048 30p, 30/1.001p, 25p, 24p, 4096×2160 4:2:2, YCbCr, 12bit MODE-1 2SI/SQD 24/1.001p 4096×2160 4:4:4, XYZ, 12bit 30p, 25p, 24p MODE-1 2SI/SQD Dual Link Division Protocol Resolution Color Space Frame Rate Mode Method SMPTE-274M 1920×1080 4:2:2, YCbCr, 10bit 60p, 60/1.001p, 50p SMPTE-2048 60p, 60/1.001p, 50p, 48p, 2048×1080...
- Page 54 SMPTE 23.98p,24p,25p,29.97p,30p,50p, 8192×4320 4:2:2, YCbCr, 10bit 2082-10 59.94p,60p 30p, 30/1.001p, 25p, 24p, SMPTE-2036 24/1.001p 3840×2160 4:2:2, YCbCr, 10bit 30PsF, 30/1.001PsF, 25PsF, 24PsF, 24/1.001PsF 30p, 30/1.001p, 25p, 24p, SMPTE-2048 24/1.001p 4096×2160 4:2:2, YCbCr, 10bit 30PsF, 30/1.001PsF, 25PsF, 24PsF, 24/1.001PsF Level A SMPTE-2036 4:2:2, YCbCr, 10bit 3840×2160...
-
Page 55: Umd Testing Method
Level A SMPTE-2048 30p, 30/1.001p, 25p, 24p, 4096×2160 4:2:2, YCbCr, 12bit Level 2SI/SQD 24/1.001p B-DL Level A 4096×2160 4:4:4, XYZ, 12bit 30p, 25p, 24p, Level 2SI/SQD B-DL Level A 4096×2160 4:4:4, XYZ, 12bit 30PsF, 25PsF, 24PsF Level B-DL HDMI Signal Format 4096×2160p (60 / 59.94 / 50 / 30 / 29.97 / 25 / 24 / 23.98) 3840×2160p (60 / 59.94 / 50 / 30 / 29.97 / 25 / 24 / 23.98) 1080p (60 / 59.94 / 50 / 30 / 29.97 / 25 / 24 / 23.98) - Page 56 Step 4: Double-click the “Umd V3.1 Test.ptp” file as shown below. Next, double-click “COM3” in the top right corner of the window, then set the values such as SN serial number, baud rate (here is ” 38400,Even,8,1”) by checking the USB to RS422 connection recognized by your computer.
-
Page 57: Terms & Definitions
6.4 Terms & Definitions ● RCA: Connector used primarily in consumer AV equipment for both audio and video. The RCA connector was developed by the Radio Corporation of America. ●BNC: Stands for Bayonet Neill-Concelman. A cable connector used extensively in television (named for its inventors). - Page 58 Support resolution 1920 × 1080 at 120 Hz or 2560 × 1440 at 60 Hz). It added support for 10 bpc, 12 bpc, and 16 bpc color depth (30, 36, and 48 bit/px), called deep color. ●HDMI 1.4: Released on June 5, 2009, added support for 4096 × 2160 at 24 Hz, 3840 × 2160 at 24, 25, and 30 Hz, and 1920 × 1080 at 120 Hz.
- Page 59 ● SFP: Small form-factor pluggable , is a compact, hot-pluggable network interface module used for both telecommunication and data communications applications. ● Optical Fiber Connector: Terminates the end of an optical fiber, and enables quicker connection and disconnection than splicing. The connectors mechanically couple and align the cores of fibers so light can pass. 4 most common types of optical fiber connectors are SC, FC, LC,ST.
- Page 60 3.1&3.2 ●NTSC: The colour video standard used in North America and some other parts of the world created by the National Television Standards Committee in the 1950s. NTSC utilizes an interlaced video signals. ●PAL: Phase Alternate Line. A television standard in which the phase of the colour carrier is alternated from line to line.
- Page 61 ●RTMP: Real-Time Messaging Protocol (RTMP) was initially a proprietary protocol developed by Macromedia (now Adobe) for streaming audio, video and data over the Internet, between a Flash player and a server. ●RTSP: The Real Time Streaming Protocol (RTSP) is a network control protocol designed for use in entertainment and communications systems to control streaming media servers.
- Page 62 ●Contrast Ratio: The ratio of the high light output level divided by the low light output level. In theory, the contrast ratio of the television system should be at least 100:1, if not 300:1. In reality, there are several limitations. Well-controlled viewing conditions should yield a practical contrast ratio of 30:1 to 50:1. ●Colour Temperature: The colour quality, expressed in degrees Kelvin (K), of a light source.
-
Page 63: Revision History
Add UMD Testing Method Aster All information herein is Xiamen RGBlink Science & Technology Co Ltd. excepting noted. is a registered trademark of Xiamen RGBlink Science & Technology Co Ltd. While all efforts are made for accuracy at time of printing, we reserve the right to alter otherwise make change without notice.
