  • Page 1 C.A 1871 Capteur de température infrarouge I I I I I Infrared temperature sensor I I I I I Infrarot-Temperaturfühler I I I I I Sensore di temperatura ad infrarossi I I I I I Captador de temperatura infrarrojo I I I I I F R A N Ç...

  • Page 2: Precautions For Use

    English Meaning of the symbol Warning ! Please refer to the User’s Manual before using the instrument.In this User’s Manual, the instructions preceded by the above symbol, should they not be carried out as shown, can result in a physical accident or dammage the instrument and the installations.
  • Page 3 0.1 for a highly reflective object to 1 for a black object. In the case of the C.A 1871 probe, the emissivity is preset at 0.95, the most frequent value, enabling approximately 90% of applications to be covered.
  • Page 4 4. USE Procedure  1. Plug the connecting lead into a digital multimeter (preferably), choose the setting which allows the temperature to be read off directly, given that the temperature sensor gives out a voltage of 1mV/°C 2. Point the sensor towards the target to be measured and ...

  • Page 5: Specifications

    Ratio between distance from target / diameter of measurement field This ratio, also called the field of vision, indicates the diameter S of the measurement field at a given distance D from the target (see figure below). Diameter of measurement field : D/S = 8/1 Distance from target In the case of small measurement points;...

  • Page 6: Maintenance

    (list on request) or the Chauvin Arnoux subsidiary or Agent in your country. Repairs Repairs under or out of guarantee: please return the product to your distributor. 6. TO ORDER C.A 1871 ............P01.6516.10Z Comes with a 9V battery and these operating instructions.
