Multi-Power Miniature Media Converter 10/100/1000
Provides Gigabit speeds in a
robust media converter. Uses
duplex multimode, duplex single-
mode, or single-strand single-mode
fiber, depending on the converter
model.
LGC322A-R5 LGC325A-R5
LGC320A-R5
LGC321A-R5
LGC324A-R5
