- Page 1 Embedded MXM module MX2000A-VA Series USER MANUAL...
-
Page 2: Document Change History
Document Change History Version Date Description Authors V1.0 2024/12/06 Initial Release. Emily Chou MX2000A-VA User Manual... -
Page 3: Copyright Notice
In no event will Aetina be liable to any person for any direct, indirect, special or other consequential damages arising from the use of any information contained herein, even if supplier is expressly advised of the possibility of such damages. -
Page 4: Customer Support Overview
All other product names or trademarks are properties of their respective owners. No ownership is implied or assumed for products, names or trademarks not herein listed by the publisher of this manual. For more information about this and other Aetina products, please visit our website at http://www.Aetina.com/... -
Page 5: Product Warranty
Product Warranty Aetina warrants the original purchaser, that each of its products will be free from defects in materials and workmanship which refers to “Aetina warranty policy” on Aetina’s official website: https://www.aetina.com/. Aetina warranty policy will be updated from time to time, and the last version shall be binding on the parties. - Page 6 14. Never open the equipment. For safety reasons, the equipment should be opened only by qualified service personnel. 15. If any of the following situations arises, please the contact Aetina’s service personnel: – Power cord or plug is damaged –...
-
Page 7: Table Of Contents
Contents 1. Product Specification ..............7 1.1 Features ........................8 1.2 Configuration ......................9 1.3 GPU feature ......................9 2. Hardware Information .............. 10 2.1 Block Diagram ...................... 10 2.2 General Purpose Graphics Processing Unit ............10 2.3 Display Interface ....................11 2.4 PCIE Express ......................11 2.5 Mechanical Dimensions .................. -
Page 8: Product Specification
1. Product Specification The MXM MX2000A-VA module features advanced NVIDIA RTX 2000 Ada Embedded GUP. It’s Ada Lovelace architecture in the MXM 3.1 Type A form factor. With 3072 CUDA core, 24 RT cores and 96 Tensor cores, 8GB GDDR6 memory. The MX2000A-VA support PCIe Gen 4.0 interface is delivers faster sequential data transfer than PCIe Gen 3.0 interface and bringing excellent performance and power efficiency into a wide variety of embedded systems, fully integrating hardware acceleration for both graphics, and computing code, enabling hardware acceleration for a... -
Page 9: Features
Maximum resolution: 7680 x 4320 at 60 Hz Cooling System Operating System Support Windows ® 10-11 64-bit Linux 64-bit Aetina provides PCI Express 4.0 x16 mechanism while data transmission via PCI-Express 4.0 x8. MX2000A-VA User Manual... -
Page 10: Configuration
1.2 Configuration Lists the SKU configuration currently available for the NVIDIA RTX 2000 ADA graphics board. Board configuration Specification MX2000A-VAA-A1 MX2000A-VAW-A1 Chip NVIDIA RTX 2000 Ada Embedded Core clock(MHz) Base= 1635 / Boost= 2115 Memory speed 16.0 Gbps Frame buffer 8GB GDDR6 Memory interface 128-bit... -
Page 11: Hardware Information
DisplayPort DisplayPort MX2000A-VA Block diagram 2.2 General Purpose Graphics Processing Unit The Aetina MX2000A-VA is based on NVIDIA RTX 2000 Ada Embedded GPU. The 2000 ADA is compliant with NVIDIA’s CUDA computing capability 8.9. GPU Resources o GDDR6 SDRAM 4 pieces 512M x 32 GDDR6, total capacity of 8192 Mbytes ... -
Page 12: Display Interface
2.3 Display Interface The MX2000A-VA supports four digital output channels, all of which can operate simultaneously. Digital Output The MX2000A-VA supports DisplayPort output. Analog Output This model does not support Analog output. Display Options The following list is MX2000A-VA graphics module display options. Display Supported for Each Interface DP_A DP_B... -
Page 13: Pin Definition
2.6 Pin Definition Board Interface MXM Board layout Specification Describe NVIDIA RTX 2000 Ada Generation Embedded GPU MXM connector (Golden Finger) Board layout and connectors MXM Pin Assignments MXM connector (card TOP) MXM connector (card BOTTOM) MX2000A-VA User Manual... - Page 14 MXM connector Pinout Signal Location Signal Location Bottom PEX_RX11# Bottom PRSNT_R# PEX_TX11 Bottom PEX_RX11 Bottom WAKE# Bottom Bottom PWR_GOOD (3.3V) PEX_TX10# Bottom PEX_RX10# Bottom PWR_EN PEX_TX10 Bottom PEX_RX10 Bottom 27MHZ_REF Bottom Bottom PEX_TX9# Bottom PEX_RX9# Bottom LVDS_U_HPD PEX_TX9 Bottom PEX_RX9 Bottom JTAG_TESTEN...
- Page 15 Signal Location Signal Location PEX_TX5# Bottom PEX_RX5# Bottom OEM0 PEX_TX5 OEM1 Bottom PEX_RX5 Bottom OEM2 OEM3 Bottom Bottom OEM4 PEX_TX4# OEM5 Bottom PEX_RX4# Bottom OEM6 PEX_TX4 OEM7 Bottom PEX_RX4 Bottom Bottom Bottom PEX_TX15# PEX_TX3# PEX_RX15# Bottom PEX_RX3# Bottom PEX_TX15 PEX_TX3 PEX_RX15 Bottom PEX_RX3...
- Page 16 Signal Location Signal Location Bottom DP_C_L3# Bottom DP_D_L2# PEX_RX0# Bottom DP_C_L3 Bottom PEX_TX0# DP_D_L2 PEX_RX0 Bottom Bottom PEX_TX0 Bottom DP_C_AUX# Bottom DP_D_L3# PEX_REFCLK# Bottom DP_C_AUX Bottom PEX_CLK_REQ# DP_D_L3 PEX_REFCLK Bottom RSVD Bottom IFPA_DP_HPD_R PEX_RST# Bottom RSVD Bottom IFPB_DP_HPD_R VGA_DDC_DAT DP_D_AUX# JTAG_TDO Bottom RSVD...
- Page 17 Signal Location Signal Location DP_B_L1# LVDS_UTX2# Bottom DP_A_L0# Bottom LVDS_LT3# DP_B_L1 LVDS_UTX2 Bottom DP_A_L0 Bottom LVDS_LT3 Bottom Bottom DP_B_L2# LVDS_UTX1# Bottom DP_A_L1# Bottom LVDS_LT2# DP_B_L2 LVDS_UTX1 Bottom DP_A_L1 Bottom LVDS_LT2 Bottom Bottom DP_B_L3# LVDS_UTX0# Bottom DP_A_L2# Bottom LVDS_LT1# DP_B_L3 LVDS_UTX0 Bottom DP_A_L2 Bottom...
- Page 18 Notes: 1. KEY = Key (or notch) on the PCB edge finger 2. PD = Pull-down resister on module 3. n.c. = Not Connect 4. Reserved = Reserved pin and do NOT connect on system 5. Y= Yes (Functional) / N= No Connection MX2000A-VA User Manual...
-
Page 19: Software Installation
GPU, not system memory. 3.2 Performing a Quick Installation Experienced users and system administrators can follow these brief instructions for installing Aetina graphics card. Other users should refer to the detailed installation instructions. 1. Uninstall the drivers and software for any installed graphics card(s). -
Page 20: Install Graphics Driver
3. Make sure your system has installed the appropriate motherboard drivers (for the motherboard drivers, please contact the motherboard manufacturer). After installing the operating system, download driver from Aetina official website. Then, go to My Computer, double-click the Download folder and execute the setup.exe program. - Page 21 The system is installing the components Click the “RESTART NOW” button to restart the computer. Then the driver installation is done MX2000A-VA User Manual...
-
Page 22: Initial Setup
4. Initial Setup 4.1 Thermal Specifications Thermal Specification Parameter Value Thermal Resistance (Junction to Case, R 0.048°C/W Thermal Resistance (Junction to PCB, R 1.45°C/W GPU shutdown temperature (OVERT) (Note 1) 100°C GPU slowdown temperature (THERM_ALERT) (Note 2) 97°C GPU maximum operating temperature (Note 3) 89°C GPU target temperature 87°C (default). -
Page 23: Appendix
5. Appendix 5.1 Ordering Information Models available Model Number Description MX2000A-VAA-A1 MXM GPU Module Type A, NVIDIA RTX 2000 Ada, 8GB GDDR6, 3x DP, 60W, 0°C to +55°C MX2000A-VAW-A1 MXM GPU Module Type A, NVIDIA RTX 2000 Ada, 8GB GDDR6, 3x DP, 60W, -40°C to +85°C MX2000A-VA User Manual... - Page 24 Aetina Corporation | Headquarters 17F, No.237, Sec.1, Datong Rd., Xizhi Dist., New Taipei City 221, TAIWAN Phone: +886-2-7709 2568 Fax : +886-2-7746 1102 Mail : sales@Aetina.com www.Aetina.com Copyright © 2024 Aetina Corporation. All rights reserved.
