- Page 1 Embedded MXM module M3A1000-PP Series USER MANUAL...
- Page 2 Document Change History Version Date Description Authors V1.0 2023/01/16 Initial Release. Emily Chou V1.1 2023/03/09 Revised ordering info. Emily Chou V1.2 2023/05/10 Revised Board configuration. Emily Chou M3A1000-PP User Manual...
- Page 3 In no event will Aetina be liable to any person for any direct, indirect, special or other consequential damages arising from the use of any information contained herein, even if supplier is expressly advised of the possibility of such damages.
- Page 4 All other product names or trademarks are properties of their respective owners. No ownership is implied or assumed for products, names or trademarks not herein listed by the publisher of this manual. For more information about this and other Aetina products, please visit our website at http://www.Aetina.com/...
- Page 5 Product Warranty Aetina warrants the original purchaser, that each of its products will be free from defects in materials and workmanship which refers to “Aetina warranty policy” on Aetina’s official website: https://www.aetina.com/. Aetina warranty policy will be updated from time to time, and the last version shall be binding on the parties.
- Page 6 14. Never open the equipment. For safety reasons, the equipment should be opened only by qualified service personnel. 15. If any of the following situations arises, please the contact Aetina’s service personnel: Power cord or plug is damaged –...
-
Page 7: Table Of Contents
Contents 1. Product Specification ..............7 1.1 Features ........................8 1.2 Configuration ......................9 2. Hardware Information .............. 10 2.1 Block Diagram ...................... 10 2.2 General Purpose Graphics Processing Unit ............10 2.3 Display Interface ....................11 2.4 PCIE Express ......................11 2.5 Mechanical Dimensions .................. -
Page 8: Product Specification
1. Product Specification The MXM M3A1000-PP module features advanced NVIDIA RTX A1000 Embedded GUP. It’s Ampere architecture in the MXM 3.1 Type A form factor. With 2048 CUDA core, 16 RT cores and 64 Tensor cores, 4GB GDDR6 memory. The M3A1000-PP support PCIe Gen 4 interface is delivers faster sequential data transfer than PCIe Gen 3 interface and bringing excellent performance and power efficiency into a wide variety of embedded systems, fully integrating hardware acceleration for both graphics and computing code, enabling hardware acceleration for a wider class of software... -
Page 9: Features
Maximum resolution: 4096 x 2160 at 60Hz High-Bandwidth Digital Content Protection (HDCP) support ▪ Cooling System ▪ Operating System Support Windows ® 10-11 64-bit ▪ ▪ Linux 64-bit 1- Aetina provides PCI Express 4.0 x16 mechanism while data transmission via PCI-Express 4.0 x8. M3A1000-PP User Manual... -
Page 10: Configuration
1.2 Configuration Lists the SKU configuration currently available for the NVIDIA RTX A1000 graphics board. ◼ Board configuration Specification M3A1000-PPA-A1 M3A1000-PPA-A2 Chip NVIDIA RTX A1000 Embedded GPU Base= 1192 Base= 630 Core clock(MHz) Boost= 1627 Boost= 1140 Memory clock 14.0 Gbps 11.0 Gbps Frame buffer 4GB GDDR6... -
Page 11: Hardware Information
DisplayPort DisplayPort DisplayPort M3A1000-PP Block diagram 2.2 General Purpose Graphics Processing Unit The Aetina M3A1000-PP is based on NVIDIA RTX A1000 Embedded GPU. The A1000 is compliant with NVIDIA’s CUDA computing capability 8.6. ⚫ GPU Resources o GDDR6 SDRAM ▪... -
Page 12: Display Interface
2.3 Display Interface The M3A1000-PP provides four the digital output channels can be active at the same time. ⚫ Digital Output The M3A1000-PP supports DisplayPort and HDMI output. ⚫ Analog Output This model does not support Analog output. ⚫ Hot Plug This model supports Hot Plug detect for digital monitors. -
Page 13: Pin Definition
2.6 Pin Definition ⚫ Board Interface MXM Board layout Specification Describe NVIDIA RTX A1000 GPU MXM connector (Golden finger) Board layout and connectors ⚫ MXM Pin Assignments MXM connector (card TOP) MXM connector (card BOTTOM) M3A1000-PP User Manual... - Page 14 ⚫ MXM connector Pinout MXM connector pinout (continued) M3A1000-PP User Manual...
- Page 15 MXM connector pinout Notes: 1. KEY = Key (or notch) on the PCB edge finger 2. PD = Pull-down resister on module 3. n.c. = Not Connect 4. Reserved = Reserved pin and do NOT connect on system M3A1000-PP User Manual...
-
Page 16: Software Installation
64-bit 3.2 Performing a Quick Installation Experienced users and system administrators can follow these brief instructions for installing Aetina graphics card. Other users should refer to the detailed installation instructions. 1. Uninstall the drivers and software for any installed graphics card(s). -
Page 17: Install Graphics Driver
3. Make sure your system has installed the appropriate motherboard drivers (for the motherboard drivers, please contact the motherboard manufacturer). After installing the operating system, download driver from Aetina official website. Then, go to My Computer, double-click the Download folder and execute the setup.exe program. - Page 18 ⚫ The system is installing the components ⚫ Click the “RESTART NOW” button to restart the computer. Then the driver installation is done M3A1000-PP User Manual...
-
Page 19: Initial Setup
4. Initial Setup 4.1 Thermal Specifications Thermal Specification ◼ Parameter Value Thermal Resistance (Junction to Case, R 0.039°C/W Thermal Resistance (Junction to PCB, R 1.46°C/W GPU shutdown temperature (OVERT) (Note 1) 100°C GPU shutdown temperature (THERM_ALERT) (Note 2) 98°C GPU maximum operating temperature (Note 3) 89°C GPU target temperature 87°C (default). -
Page 20: Appendix
5. Appendix 5.1 Ordering Information Models available ◼ Model Number Description M3A1000-PPA-A1 MXM-A, NVIDIA RTX A1000, Gen4.0 x8, 4GB GDDR6, DP, 60W, 0°C to +55°C M3A1000-PPW-A1 MXM-A, NVIDIA RTX A1000, Gen4.0 x8, 4GB GDDR6, DP, 60W, -40°C to +85°C M3A1000-PPA-A2 MXM-A, NVIDIA RTX A1000, Gen4.0 x8, 4GB GDDR6, DP, 35W, 0°C to +55°C M3A1000-PPW-A2 MXM-A, NVIDIA RTX A1000, Gen4.0 x8, 4GB GDDR6, DP, 35W, -40°C to +85°C... - Page 21 Aetina Corporation | Headquarters 2F-1, No.237, Sec.1, Datong Rd., Xizhi Dist., New Taipei City 221, TAIWAN Phone: +886-2-7709 2568 Fax : +886-2-7746 1102 Mail : sales@Aetina.com www.Aetina.com Copyright © 2022 Aetina Corporation. All rights reserved.
