- Page 1 EB4PL90KCN EB4PL90KSP Microwave combi-oven User Manual...
-
Page 2: Table Of Contents
WE’RE THINKING OF YOU Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings with it decades of professional experience and innovation. Ingenious and stylish, it has been designed with you in mind. So whenever you use it, you can be safe in the knowledge that you’ll get great results every time. - Page 3 15. IT'S EASY!..........35 different kinds of food......26 16. GUARANTEE ..........37 10.5 Cooking tables for test institutes..26 17. ENVIRONMENTAL CONCERNS.....37 11. CARE AND CLEANING......28 11.1 Notes on cleaning......28 My Electrolux Kitchen app Subject to change without notice. 3/40...
-
Page 4: Safety Information
Children should be supervised to ensure that they do not • play with the appliance and mobile devices with My Electrolux Kitchen . Keep all packaging away from children and dispose of it • appropriately. WARNING: The appliance and its accessible parts become •... - Page 5 SAFETY INFORMATION This appliance may be used in, offices, hotel guest rooms, • bed & breakfast guest rooms, farm guest houses and other similar accommodation where such use does not exceed (average) domestic usage levels. Only a qualified person must install this appliance and •...
- Page 6 SAFETY INFORMATION WARNING: Do not heat liquids and other foods in sealed • containers. They are liable to explode. Use only utensils that are suitable for use in microwave • ovens. When heating food in plastic or paper containers, observe •...
-
Page 7: Safety Instructions
SAFETY INSTRUCTIONS 2. SAFETY INSTRUCTIONS 2.1 Installation WARNING! Only a qualified person must install this appliance. • Remove all the packaging. • Do not install or use a damaged appliance. • Follow the installation instructions supplied with the appliance. • Always take care when moving the appliance as it is heavy. Always use safety gloves and enclosed footwear. -
Page 8: Electrical Connection
SAFETY INSTRUCTIONS 2.2 Electrical connection WARNING! Risk of fire and electric shock. • All electrical connections should be made by a qualified electrician. • The appliance must be earthed. • Make sure that the parameters on the rating plate are compatible with the electrical ratings of the mains power supply. -
Page 9: Care And Cleaning
SAFETY INSTRUCTIONS WARNING! Risk of damage to the appliance. • To prevent damage or discoloration to the enamel: – do not put aluminium foil directly on the bottom of cavity of the appliance. – do not put water directly into the hot appliance. –... -
Page 10: Service
PRODUCT DESCRIPTION 2.6 Service • To repair the appliance contact the Authorised Service Centre. • Use original spare parts only. 2.7 Disposal WARNING! Risk of injury or suffocation. • Contact your municipal authority for information on how to dispose of the appliance. •... -
Page 11: Control Panel
CONTROL PANEL Glass baking tray For cakes and biscuits. 4. CONTROL PANEL 4.1 Control panel overview ON / OFF Press and hold to turn the appliance on and off. Display Shows the current settings of the appliance. Press Move Press and hold Touch the surface with finger‐... -
Page 12: Display
CONTROL PANEL 4.2 Display The display with the maximum number of func‐ B C D tions set. A. Menu / Back Conventional cooking B. Wi-Fi (selected models only) C. Time of day D. Information E. Timer H G F E F. -
Page 13: Before First Use
To connect the appliance you need: • Wireless network with the Internet connection. • Mobile device connected to the same wireless network. Step 1 Download the mobile app My Electrolux Kitchen and follow the instructions for the next steps. Step 2 Turn on the appliance. -
Page 14: Software Licences
5.4 Software licences The software in this product contains components that are based on free and open source software. Electrolux acknowledges the contributions of the open software and robotics communities to the development project. To access the source code of these free and open source software components whose license conditions require publishing, and to see their full copyright information and applicable license terms, visit: http://electrolux.opensoftwarerepository.com (folder GTM3). -
Page 15: How To Set: Microwave Functions
DAILY USE - press to turn off the heating function. Step 7 Turn off the oven. 6.2 How to set: Microwave functions Step 1 Remove all accessories and turn on the appliance. Step 2 Select a microwave heating function. The display shows the default heating functions. To see more heating functions press: Step 3 Press: W. -
Page 16: How To Set: Assisted Cooking
DAILY USE Step 2 To extend the cooking time: Press one of the time shortcuts on the Press on the running time value to go to display. the time slider. Move the dot on the slider to the chosen value. The microwave can be switched on at any time with: Microwave quick start. - Page 17 DAILY USE Heating function Application To make convenience food (e.g., french fries, potato wedges or spring rolls) crispy. Frozen Foods To bake and roast food on one shelf position. Conventional Cooking To bake pizza. To make intensive browning and a crispy bottom. Pizza Function To bake cakes with crispy bottom and to preserve food.
- Page 18 DAILY USE Heating function Application For dishes such as lasagna or potato gratin. To make gratins and to brown. Au Gratin To prepare tender, succulent roasts. Slow Cooking To keep food warm. Keep Warm Use this function to prepare bread and bread rolls with a very good pro‐ fessional-like result in terms of crispiness, colour and crust gloss.
-
Page 19: Clock Functions
CLOCK FUNCTIONS Heating function Application Baking and roasting food on one shelf position. The function with MW boost, power range: 100 - 600 W. Conventional Cooking + MW To cook food in a short time and to brown it. The function with MW boost, power range: 100 - 600 W. -
Page 20: How To Set: Clock Functions
CLOCK FUNCTIONS Start criteria Comment The timer starts when cooking starts. The timer starts when the appliance reaches the set temperature. Start criteria, End action and Delayed start are not available for microwave functions. 7.2 How to set: Clock functions How to set the clock Step 1 Press:... - Page 21 CLOCK FUNCTIONS How to delay start and end of cooking Step 1 Press: Step 2 Slide and press to set the clock. Press: How to delay start without setting the end of cooking Step 1 Set the heating function and the temperature. Step 2 Press: Step 3...
-
Page 22: Using The Accessories
USING THE ACCESSORIES How to change timer settings Step 1 Choose the value on the slider or press the preferred time value to change the timer value. Step 2 Press: You can change the set time during cooking at any time. 8. -
Page 23: Additional Functions
ADDITIONAL FUNCTIONS 9. ADDITIONAL FUNCTIONS 9.1 How to save: Favourites You can save your favourite settings, such as the heating function, the cooking time, the temperature or the cleaning function. You can save 3 favourite settings. Step 1 Turn on the appliance. Step 2 Select the preferred setting. -
Page 24: Hints And Tips
HINTS AND TIPS 10. HINTS AND TIPS 10.1 Cooking recommendations The temperature and cooking times in the tables are guidelines only. They depend on the recipes and the quality and quantity of the ingredients used. Your appliance may bake or roast differently to the appliance you had before. The hints below show recommended settings for temperature, cooking time and shelf position for specific types of the food. - Page 25 HINTS AND TIPS Cookware / Material Ovenproof glass and porcelain with no metal components, e.g. heat-proof glass Non-ovenproof glass and porce‐ lain without any silver, gold, plat‐ inum or other metal decorations Glass and glass ceramic made of ovenproof / frost-proof materi‐ Ovenproof ceramic and earthen‐...
-
Page 26: Recommended Power Settings For Different Kinds Of Food
HINTS AND TIPS 10.4 Recommended power settings for different kinds of food The data in the table is for guidance only. 700 - 1000 W Searing at the start of the cooking process Heating liquids 500 - 600 W Defrosting and Cooking vegeta‐... - Page 27 HINTS AND TIPS Sponge cake 0.475 Bottom 8 - 9 Turn container around by 1/4, half‐ way through the cooking time. Meatloaf 25 - 27 Turn container around by 1/4, half‐ way through the cooking time. Egg custard 30 - 33 Meat defrosting Turn the meat up‐...
-
Page 28: Care And Cleaning
CARE AND CLEANING 11. CARE AND CLEANING WARNING! Refer to Safety chapters. 11.1 Notes on cleaning Clean the front of the appliance only with a microfibre cloth with warm water and a mild detergent. Use a cleaning solution to clean metal surfaces. Cleaning Clean stains with a mild detergent. -
Page 29: How To Replace: Lamp
TROUBLESHOOTING Install the shelf supports in the opposite sequence. 11.3 How to replace: Lamp WARNING! Risk of electric shock. The lamp can be hot. Always hold the halogen lamp with a cloth to prevent grease residue from burning on the lamp. Before you replace the lamp: Step 1 Step 2... - Page 30 TROUBLESHOOTING The appliance does not turn on or does not heat up Possible cause Remedy The clock is not set. Set the clock, for details refer to Clock func‐ tions chapter, How to set: Clock functions. The door is not closed correctly. Fully close the door.
-
Page 31: How To Manage: Error Codes
TROUBLESHOOTING Problems with Wi-Fi signal Possible cause Remedy The wireless network signal is weak. Move router as close to the appliance as possi‐ ble. The wireless signal is disrupted by another mi‐ Turn off the microwave oven. crowave oven placed near the appliance. Avoid using another microwave oven and the Remote Control of the appliance at the same time. -
Page 32: Service Data
ENERGY EFFICIENCY Code and description Remedy F602, F603 - Wi-Fi is not available. Turn the appliance off and on. 12.3 Service data If you cannot find a solution to the problem yourself, contact your dealer or an Authorised Service Centre. The necessary data for the service centre is on the rating plate. -
Page 33: Menu Structure
MENU STRUCTURE 14. MENU STRUCTURE 14.1 Menu Menu item Application Favourites Lists the favourite settings. Assisted Cooking Lists automatic programmes. Options To set the appliance configuration. Settings Connections To set the network configuration. Setup To set the appliance configuration. Service Shows the software version and con‐... -
Page 34: Submenu For: Connections
MENU STRUCTURE 14.3 Submenu for: Connections Submenu Description Wi-Fi To enable and disable: Wi-Fi. Remote operation To enable and disable remote control. Option visible only after you turn on: Wi-Fi. Network To check network status and the signal power of: Wi-Fi. Auto remote operation To start remote operation automatically after pressing START. -
Page 35: Submenu For: Service
IT'S EASY! 14.5 Submenu for: Service Submenu Description Demo mode Activation / deactivation code: 2468 Licence Information about licenses. Software version Information about software version. Reset all settings Restores factory settings. Reset all popups Restores all pop-ups to the original settings. 15. - Page 36 IT'S EASY! Start using the appliance MW quick start Start Microwave Press: at any time with the default set‐ tings: 30 sec / 1000W. Start cooking Step 1 Step 2 Step 3 Step 4 Step 5 Step 6 - move the - press to go - press to finger on the...
-
Page 37: Guarantee
GUARANTEE GUARANTEE Customer Service Centres Point of Service Industriestrasse 10 Le Trési 6 Via Violino 11 5506 Mägenwil 1028 Préverenges 6928 Manno Morgenstrasse 131 3018 Bern Langgasse 10 9008 St. Gallen Am Mattenhof 4a/b 6010 Kriens Schlossstrasse 1 4133 Pratteln Comercialstrasse 19 7000 Chur Spare parts service Industriestrasse 10, 5506 Mägenwil, Tel. - Page 40 www.electrolux.com/shop...
