CORAB WS-024R Installation Manual

Ground mounted system, double support rammed into the ground, 4 rows of landscape modules

Advertisement

Quick Links

CORAB WS-024R
INSTRUKCJA MONTAŻU
System wolnostojący, dwupodpor
wbijany w ziemię
4 moduły w rzędzie poziomo
Dla modułów o wymiarach długość 2250-2400 mm / szerokość 1094-1149 mm
System dedicated for the following module dimensions: 2250-2400 mm / width 1094-1149 mm
Nie stosuj systemu do modułów fotowoltaicznych typu Bi-facial.
Do not use the system for Bi-facial PV modules.
Narzędzia potrzebne do montażu
/Tools needed for installation
rozmiar/size 6
wkrętarka/screwdriver
01WS024R/2023/EBC
INSTALLATION MANUAL
y
Ground mounted system, double support
rammed into the ground,
4 rows of landscape modules
rozm./size 2 x 19 mm
koncówki - bity imbusowe/
screwdriver bits
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the WS-024R and is the answer not in the manual?

Questions and answers

Summary of Contents for CORAB WS-024R

  • Page 1 CORAB WS-024R INSTRUKCJA MONTAŻU INSTALLATION MANUAL System wolnostojący, dwupodpor Ground mounted system, double support wbijany w ziemię rammed into the ground, 4 moduły w rzędzie poziomo 4 rows of landscape modules Dla modułów o wymiarach długość 2250-2400 mm / szerokość 1094-1149 mm System dedicated for the following module dimensions: 2250-2400 mm / width 1094-1149 mm Nie stosuj systemu do modułów fotowoltaicznych typu Bi-facial.
  • Page 2 Elementy/Elements Ilość modułów / Number of PV modules Indeks Nazwa Index Name Podkładka poszerzana M12 130 120 100 M1067 Washer expanded M12 Mocowanie inwertera XPF_WS004N.8.001 Inverter mou ng set Stężenie skośne z linki L=3700 XPF_WS006U.6.002 Turnbuckle wire tensioner L=3700 Podkładka podatna M8 M1070 Safety washer M8 Śruba imbusowa M8x20...
  • Page 3 Montaż/Installation Wymiar X obliczyć według wzoru: Y= długość modułu + 20 Przykład dla długości 2250 mm: Y= 2250 + 20 Y= 2270 mm Dimension X calculate with the following formula: Y= module length + 20 Example for 2250 length mm: Y= 2250 + 20 Y= 2270 mm 13,15,14,12...
  • Page 4 10 12 11 10 10 12 13 Wymiar Y obliczyć według wzoru Dimension Y calculate with the Y= (długość modułu + 20) x2 – 4520 following formula: 21 10 12 Przykład dla długości 2250 mm: Y= (module length + 20) x2 - 4520 Y= (2250 + 20) x2 –...
  • Page 5 PV module PV module 16 11 17 11 Śruba M12x40 Screw M12x40 Nakrętka M12 Nut M12 2x Podkładka M12 2x Washer M12 Podkładka sprężysta M12 Spring washer M12 Otwory wiercić zgodnie z uwagą 1 Drill holes according to note 1 Długość...
  • Page 6 Uwaga 2 / Note 2 XPF_WS007N.3.0000 L3550 Otwory wiercić zgodnie z uwagą 1 Drill holes according to note 1 Uwaga 1: Otwory w podporach oraz belce mocowania inwertera pod śrubę M12 wykonać Śruba M12x30 Screw M12x30 w następujących krokach: Nakrętka M12 Nut M12 1.
  • Page 7 Pobijak do uziomów Ground rod driver * Dostępny poza zestawem / Available out of the set ** Nie występuje w sprzedaży Corab / Not available for sale in Corab company 01WS024R/2023/EBC...
  • Page 8 Niemniej jako producent systemów moco- wań nie ponosimy odpowiedzialności za ich prawidłowe wykorzysta- their correct use and proper assembly. Corab S.A. does not analyze the needs of nal customers or the expected placement conditions of nie i ich prawidłowy montaż. Corab S.A. nie analizuje potrzeb photovoltaic installations.
  • Page 9: Maintenance

    The use of other spare parts may lead to serious damage to property or Stosowanie innych części zamiennych może prowadzić do poważ- hazards to health of people in the vicinity of the PV system! The Corab® nych szkód w mieniu lub zagrożenia dla zdrowia osób przebywają- system forms a uniform and consistent set of elements.
