TURING SKYSHIELD
ASSEMBLE YOUR SKYSHIELD
IN 4 EASY STEPS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SKYSHIELD and is the answer not in the manual?

Questions and answers

Related Manuals for Turing SKYSHIELD

Summary of Contents for Turing SKYSHIELD

  • Page 1 TURING SKYSHIELD ASSEMBLE YOUR SKYSHIELD IN 4 EASY STEPS...

  • Page 2: Table Of Contents

    Fig. 2.5 Mounting Cameras on the Bottom ............Part 3:Mounting Speakers to the SkyShield..............Fig. 2.6 Mounting Speakers to the SkyShield ................Step 3: How to Setup Your 4G Router..........Fig. 3.1 4G LTE Router Setup Guide............... Install Antennas to the Top of the SkyShield................

  • Page 3: Step 1: How To Assemble Your Skyshield

    Step 1: How To Assemble Your SkyShield What’s Included in the Box? Bridge 4G Router *2/4G *1/WIFI Heater Fan Power Supply（5V1A） led power supply（12V1A） List of Screws 3mmX10mm 3mmX10mm(Without spacer) 4mmX14mm 4mmX14mm (Without spacer) 4mmX20mm 4mmX35mm 4mmX14mm(Round head ) 8mmX16mm...

  • Page 4: Part 1:Assembly Process

    Part 1: Assembly Process Port 1 Port 3 Port 2 Port 4 power M3*10MM *2 Lan 2 M4*14MM *3 Fig. 1.2 Assembling NVR...

  • Page 5: Part 2:Assembly Process

    Part 2: Assembly Process M3*10MM *2 Fig. 1.3 Assembling Bridge M3*10MM *8 Fig. 1.4 Assembling Router...

  • Page 6: Part 3:Assembly Process

    Part 3: Assembly Process top to bottom Assembling the heater M4*14MM*4 (Round head ) Cross round head screw Fig. 1.5 Assembling Heater...

  • Page 7: Part 4:Assembly Process

    Part 4: Assembly Process Note: This is an optional step and only apply to Skyshield Edge series. Remove two screws M3*6 MM *2 Assembly of POE Fig. 1.6 Assembling POE Switch(Optional)

  • Page 8: Part 5:Assembly Process

    Part 5: Assembly Process Network cable M4*14MM *1 Heater Fans Router Bridge DC*2 Fig. 1.7 Assembling Network Cable...

  • Page 9: Step 2: How To Setup Your Cameras And System

    Step 2: How to Setup Your Cameras and System...

  • Page 10: Part 1:Mounting The Rain Shade

    Part 1: Mounting the Rain Shade Mount rain shade to the left side of the SkyShield with 4x M4*10mm Screws. Rain Shade can be found in a brown box inside the Enclosure.

  • Page 11: Camera Mount Options

    TP-EFDWM TP-SDLPZ TP-SDC TP-VDWM Note: Brackets and Adapters are required to mount cameras to SkyShield, those are Not included in the box,Brackets will be in a separate box or need to order separately Optional Cameras TP-MED4M28 & TP-MED4M4 TP-MED5M28 & TP-MED5M4 TP-MED8M28 TP-MEAD4M28 &...

  • Page 12: Mount Cameras To The Left/Right Position

    Mounting Cameras to the Left/Right Position M4*20MM *8 Fig. 2.2 Left/Right Camera Mounting Position...

  • Page 13: Mounting Vf Bullet/Lpr/Ad Ptz Camera

    Mounting VF Bullet/LPR/AD PTZ Camera M4*35MM *4 M4*14MM *4 M4*14MM *4 M4*14MM *4 Fig. 2.3 Mounting VF Bullet/LPR/AD PTZ Camera...

  • Page 14: Mounting A Ptz Camera

    Mounting a PTZ Camera Disassembly Security Lock M4*14MM *2 Fig. 2.4 Mounting a PTZ Camera...

  • Page 15: Mounting Cameras On The Bottom

    Mounting Cameras on the Bottom Remove the cover plate first M4*14MM *6 M4*14MM*6 (Round head ) Fig. 2.5 Mounting Cameras on the Bottom...

  • Page 16: Part 3:Mounting Speakers To The Skyshield

    Part 3: Mounting Speakers to the SkyShield Through the rubber ring M8*20 MM *2 Assembly of Speakers Camera M8*20 MM *2 Assembly of Speakers Fig. 2.6 Mounting Speakers to the SkyShield...

  • Page 17: Step 3: How To Setup Your 4G Router

    Step 3: How to Setup Your 4G Router Note:Please refer to another Carrier Guidance for more information. Fig. 3.1 4G LTE Router Setup Guide...

  • Page 18: Install Antennas To The Top Of The Skyshield

    Install Antennas to the Top of the SkyShield Note: Antennas are required otherwise router network signals would be blocked by the metal box. Note: WiFi logo and fixed order. Note:The WiFi antenna port is available only in the latest version. If your device doesn’t have it but you still want to connect a WiFi antenna, you can...

  • Page 19: How To Wire The Power Plug

    How to Wire the Power Plug Fig. 3.3 Wiring the Plug Power...

  • Page 20: Step 4: How To Mount Your Skyshield

    Step 4: How to Mount Your SkyShield Worm Gear Hose Clamp*4 Expansion screws*4 Fig. 4.1 Pole/Wall Mount Security locks*1 M10*145MM *1 M10*145MM *2 Fig. 4.2 Attaching SkyShield to Mount...

  • Page 21: Faq

    Answer: 1. First ensure the RS485 cable between Router and Smart Power Strip are properly connected. 2. Second, please login Router's web GUI to check Router's Firmware version. There is known compatibility issue with newer Router Fimware version. If you notice Router FW version is not in bellow compatible list, please upgrade/downgrade it to the right version.

  • Page 22: Q1. I Cannot Reboot Skyshield From Vision

    b. Add new Modbus Serial Device Configuration. CLick Save & APPLY c. Add new Modbus Server Device Configuration. CLick Save & APPLY 4. Check Status Under Status-->Services make sure Modbus Serial Client is enabled. 5. Click Restart Power Strip on Vision Platform to test Restart feature.
