Summary of Contents for Homecraft Apex 10kw (240v)

  • Page 1 HOMECRAFT SAUNAS The Apex The Pinnacle of Great Heat 10kw (240v) 12kw (240v or 208v) 15kw (240v or 208v) 18kw (208v) WWW.HOMECRAFTSAUNAS.COM INFO@HOMECRAFTSAUNAS.COM...
  • Page 2 Table of Contents Table of Contents Page 1. Front Page Page 2. Table of Contents Page 3. Safety & Warnings Page 4. Heater & Electrical Specs Page 5. Safety Distances & Heat shield Page 6. General Info (heater guard, ventilation) Page 7 .
  • Page 3: Safety Warnings

    Sauna doors must always open outwards, should never have a latch or lock that could cause entrapment Homecraft Doors use a safe roller latch. Never touch a heater that is turned on and never place objects on top of the sauna heater.
  • Page 4 T H E A P E X Sauna heater electrical specifications Apex 240v Optimal Room Size Output Amps Circuit 1Phase (Cubic ft) Wire Size 240v Breaker Apex 10kw 10000w 400-575 41.6 50amp Apex 12kw 12000w 450-750 70amp Apex 15kw 15000w 600-950 62.5 80amp...
  • Page 5 T H E A P E X It is important to recheck your safety to combustible to ensure you have the correct safety spacing Ceiling Heat Shield: A Heat shield is required for ceiling at 7' with the 18kw Apex Remove the stainless steel protective film before Installation.
  • Page 6 Towel Drape Guard: For US customers to properly safeguard the sauna room from potential fires it is necessary to install the Homecraft Drape guard on the top of the sauna heater. This guard is designed to protect the sauna room from the potential of fires.
  • Page 7: Preparing For Sauna Heater Installation

    Check that the electrical connections are installed correctly Take a multimeter and work your way to see where the power is failing If an error is reading on the touchpad see the troubleshooting page on the Homecraft website under resources...
  • Page 8 Ensure the heater is properly in place and the rocks are installed correctly Every Homecraft Heater is approved and certified under CSA & UL...
  • Page 9 IN ACCORDANCE TO LOCAL REGULATIONS Relay Control Box: Every Homecraft heater needs a relay contactor box to effectively install and run your sauna heater. The Relay control box contains the 24-volt class 2 transformer and a magnetic contactor. Components / Parts:...
  • Page 10: Wiring Diagrams

    Wiring Diagrams...
  • Page 12 F O R W A R R A N T Y C L A I M S , P R O O F O F P U R C H A S E A N D P R O P E R I N S T A L L A T I O N D O C U M E N T A T I O N M A Y B E R E Q U I R E D . Thank You from Homecraft www.reallygreatsite.com +123-456-7890 WWW.HOMECRAFTSAUNAS.COM...
