- Page 1 Sauna Heater and Controls Installation & Wiring Instructions SAUNA HEATERS & CONTROLS APPLICABLE TO THIS MANUAL MODEL WATTS VOLTAGE PHASE CONTROL FHSH 12 12000 TKE2-3 FHSH 15 15000 TKE2-3...
- Page 2 MANUFACTURING Sauna Heater and Controls Installation & Wiring Document Rev: B CORPORATION Instructions TABLE OF CONTENTS ......................2 1. ***Cautions & Warnings*** ..................... 2 1.1. Electrical Wiring Routing ........................2 1.2. Water Spray ........................2 1.3. Shower Head ..................2 1.4.
- Page 3 MANUFACTURING Sauna Heater and Controls Installation & Wiring Document Rev: B CORPORATION Instructions ..............9 14. ****NOTE ON INSTALLATION IN A PUBLIC SAUNA*** ........................ 9 15. Troubleshooting Guide ....................11 Heater Guarantee 1. ***CAUTIONS & WARNINGS*** 1.1. ELECTRICAL WIRING ROUTING All wiring to the sauna heater and accessories must be routed away from any direct radiation from the sauna heater 1.2.
- Page 4 MANUFACTURING Sauna Heater and Controls Installation & Wiring Document Rev: B CORPORATION Instructions 3. SAUNA HEATER INSTALLATION Sauna Heaters come fully assembled. NOTICE: REMOVE PLASTIC PROTECTIVE COATING ON THE OUTSIDE OF THE HEATER AFTER COMPLETE INSTALLATION AND ELECTRICAL WIRING BUT BEFORE START-UP. Caution: Avoid a fire;...
- Page 5 MANUFACTURING Sauna Heater and Controls Installation & Wiring Document Rev: B CORPORATION Instructions 3.4. STEP 4 The thermostat temperature sensor should be mounted inside the sauna room at the location shown in FIGURE 5. If the sensor bulb is not positioned correctly, tripping of the high limit switch will occur 3.5.
- Page 6 MANUFACTURING Sauna Heater and Controls Installation & Wiring Document Rev: B CORPORATION Instructions 3.8. STEP 8 The owner must implement a maintenance program for the sauna heater and inspect the sauna heater at the end of each day to ensure the sauna heater is turned off. 4.
- Page 7 MANUFACTURING Sauna Heater and Controls Installation & Wiring Document Rev: B CORPORATION Instructions 9. ELECTRICAL COMPONENTS Please note the following: It is unlawful to install this unit without first obtaining a permit from the local electrical inspection authority Electrical wiring and hook-up should only be done by a certified electrician. Electrical connection by a non-certified person voids the heater warranty.
- Page 8 MANUFACTURING Sauna Heater and Controls Installation & Wiring Document Rev: B CORPORATION Instructions Attention: Utiliser uniquement un contacteur approuvé pour cycles ce fonctionnement Connect the 18/4 wire to the appropriate connections in the Relay Control Box. If more than the supplied 18/ 4 wire is needed for your installation, you can order additional wire from or purchase 18/4 wire locally.
- Page 9 MANUFACTURING Sauna Heater and Controls Installation & Wiring Document Rev: B CORPORATION Instructions 11.3. STEP 3 Be sure to leave a little slack in the 18/2 wire in the stud wall. Strip about 152 mm (6”) from the outer casing of the 18/2 pair, leaving the protective casing on the individual leads. This will make it easier to attach the 18/2 wires to the sensor leads, and gives more flexibility when pushing any excess wire back into the wall.
- Page 10 MANUFACTURING Sauna Heater and Controls Installation & Wiring Document Rev: B CORPORATION Instructions 13.1. “OFF” DISPLAY When the sauna is turned off the display (#2) will show “OFF” 13.2. TURN ON THE SAUNA Press the I/O switch (#1) on the Digital Touchpad to turn on the sauna. 13.3.
- Page 11 MANUFACTURING Sauna Heater and Controls Installation & Wiring Document Rev: B CORPORATION Instructions PROBLEM CAUSE SOLUTION energizing High Limit Switch heater is turned on. Allow heater to cool down. Reset by pushing the eraser end of a pencil through the small hole at the front, bottom of the heater in the center of the silver CSA heater identification label.
- Page 12 MANUFACTURING Sauna Heater and Controls Installation & Wiring Document Rev: B CORPORATION Instructions PROBLEM CAUSE SOLUTION Tripped Temperature High Air leakage This is a common problem. Ensure that there is no air Limit Switch leakage around the sauna door or windows. When the door is closed, adjust the door stop strip to seat tight against the door.
- Page 13 MANUFACTURING Sauna Heater and Controls Installation & Wiring Document Rev: B CORPORATION Instructions No reimbursement by will be allowed for costs incurred to diagnose, remedy, or replace parts without prior written agreement. Electrical wiring and hook-up should only be done by a certified electrician. All equipment must be installed according to our heater installation instructions observing the required clearances of the sauna heater and the proper position of the temperature sensor probe.
