H-SERIES INSTALLATION
& ELECTRICAL
INSTRUCTIONS
6KW, 7.5KW & 9KW
240V / 1 PHASE
Thank you for purchasing our Homecraft H-Series sauna heater. This Classic
heater is one of North America's longest manufactured sauna heaters and is built
in Surrey, B.C Canada. Thank you for your purchase and we know you will love
your sauna.
Sincerely
Kyle Wilson
President
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Homecraft H Series
Summary of Contents for Homecraft H Series
- Page 1 6KW, 7.5KW & 9KW 240V / 1 PHASE Thank you for purchasing our Homecraft H-Series sauna heater. This Classic heater is one of North America’s longest manufactured sauna heaters and is built in Surrey, B.C Canada. Thank you for your purchase and we know you will love your sauna.
-
Page 2: Electrical Specifications
QUESTIONS? 1-800- 604-888-3403 CONTACT US. inquiries@homecraftsaunas.com Electrical Specifications Circuit Wire 90' C Model Watts Voltage Phase Control Breaker copper 6000w 240v Tke2-2 40amp H-Series 7500w 240v Tke2-2 40amp H-Series H-Series 9000w 240v Tke2-2 50amp Heater Specifications MINIMUM CLEARANCE MINIMUM MAXIMUM MODEL WEIGHT CEILING... - Page 3 Table of Contents Page 1: Cover Page Page 2: Electrical & Heater Guide Page 3: Table of Contents Page 4: General Warnings Page 5: Heater Installation & Rock Placement Page 6: Electrical Wiring Diagram Page 7: Relay Box & Temperature Sensor Installation Page 8: Digital Control Installation Page 9: Warranty Page 10: Our guide to great sauna use...
- Page 4 GENERAL WARNINGS & CAUTIONS 1.1 ELECTRICAL WIRING ROUTING ALL WIRING TO THE SAUNA HEATER AND ACCESSORIES MUST BE ROUTED AWAY FROM ANY DIRECT RADIATION FROM THE SAUNA HEATER 1.2. WATER SPRAY NEVER SUBJECT THE SAUNA HEATER OR CONTROL COMPONENTS TO DIRECT WATER SPRAY 1.3.
- Page 5 H-Series Sauna Heater Installation Homecraft sauna heaters come fully assembled. Mounting hardware is supplied with the heater. Please remove the plastic protective coating on the outside of the heater after the sauna heater is completely installed and always before the initial start-up Mounting the Sauna heater: The H-series sauna heaters are to be installed 12'’...
- Page 6 Electrical Wiring Diagram...
-
Page 7: Sauna Heater Installation
Connect the 18/4 wire to the appropriate connections in the Relay Control Box. If more than the supplied 18/4 wire is needed for your installation, you can order additional wire from HOMECRAFT or purchase 18/4 wire locally. Do not splice into the supplied wires if you are short. - Page 8 GFI breaker will not work with our sauna heaters) Be sure to check with your local inspection authority. The Homecraft Tke2-2 control will fit a standard 2-gang electrical box to house the digital wall-mount control panel. This box should be mounted on the outside wall of the sauna.
- Page 9 Warranty does not cover general wear that occurs from normal sauna use Warrant does not apply when: Product has been damaged by carelessness Product has not been installed correctly Product has been modified or tampered with When the product is used with none Homecraft certified components (ie, controls, rocks)
- Page 10 Our Guide to a good sauna A great sauna is experienced when you can find the perfect balance of Heat, Steam and Ventilation. The Heat & Steam portion is where our Sauna heaters come into play and we have designed our heaters with just that in mind.
