TABS/SLOTS
MACHINE
SCREW
Installation
NOTE: Shut off all power sources to the
FLEXmax 80 before replacing the fan.
1. Remove the machine screw that secures
the fan cover.
2. Press in the sides of the fan cover to
release the tabs and pull up on the
cover.
3. Remove the fan cover once the tabs
have cleared their slots.
COVER REMOVED
4
