Figure 3-22. Opening and Closing the System
1
1 traction pad
3 cover release latch lock

Closing the System

1 Place the cover on the chassis and slide it to the front of the chassis until it
snaps into place. See Figure 3-22.
2 Secure the cover with the securing screw. See Figure 3-22.

Cooling Fans

Removing a Cooling Fan

WARNING:
WARNING:
has been powered down. Allow time for the fan to stop spinning before removing it
from the system.
92
Installing System Components
2
Do not attempt to operate the system without the cooling fans.
The cooling fan can continue to spin for some time after the system
3
4
2 system cover
4 securing screw
