Post Error Codes; Collecting System Event Log For Investigation - Dell PowerEdge C6100 Hardware Owner's Manual

POST Error Codes

Collecting System Event Log for Investigation

Error Messages are logged in the System Event Log (SEL). The SEL can be
accessed through system BIOS and the BMC setup for investigation. You can
also access SEL by browsing to the IP address of the BMC.
Code Log in BMC Cause
0000h Yes
0003h Yes
0004h Yes
0005h Yes
000Bh Yes
Timer Count Read/Write Error
CMOS Battery Error
CMOS Diagnostic Status Error
CMOS Checksum Error
CMOS Memory Size Error
Corrective Actions
Remove AC power to the
system for 10 seconds and
restart the system.
If the problem persists, see
"Getting Help" on page 143.
See "Troubleshooting the
System Battery" on
page 118.
Remove AC power to the
system for 10 seconds and
restart the system.
If the problem persists, see
"Getting Help" on page 143.
Remove AC power to the
system for 10 seconds and
restart the system.
If the problem persists, see
"Getting Help" on page 143.
Remove AC power to the
system for 10 seconds and
restart the system.
If the problem persists, see
"Getting Help" on page 143.
About Your System
23
