Figure 1-11. Enumeration—Two System Boards
NIC Indicator Codes
Figure 1-12. NIC Indicators
1
link indicator
NIC Status Indicator (link)
Steady amber
Blinks amber
Steady green
Blinks green
Off
18
About Your System
4
1
2
activity indicator
Condition
Link at 1 Gbps speed
Identifying port with 1 Gbps connection
Link at 100 Mbps speed
Identifying port with 10 Mbps or 100 Mbps
connection
Link at 10 Mbps speed
2
2
