System Configuration Jumper Settings

The function of system configuration jumper installed on each system board
is shown below:
Figure 5-14. System Configuration Jumper
Table 5-1. System Configuration Jumper
Jumper
A
B
C
D
E
NOTE:
The * in the table of system configuration jumper describes the default
status and the default state is not active state.
140
Jumpers and Connectors
Function
ME Function
Disable for Debugs
Reserved for BIOS
PCI-E Setup
BIOS Clear
Password
BIOS Clear CMOS *Disable
System Reset
1 2 1 2 1 2
1 2
A A
B B
C C
D D
E E
Disable Enable
Off
*Disable
-
*Disable
*Disable
On
Enable
-
Enable
Enable
Enable
