Fan Controller Board Connectors

Figure 5-12. Fan Controller Board Connectors
19
18
17
16
15
14
1 front panel connector for system
board 4
3 front panel connector for system
board 1
5 system fan board power connector 1
7 system fan control connector
9 PIC firmware update connector
11 system fan board connector 1
13 hard drive backplane I2C connector
15 system fan connectors 4
17 front panel connector 1
19 system fan connectors 1
138
Jumpers and Connectors
1 2 3
13
4 6
5
12
10
11
2 front panel connector for system
board 2
4 front panel connector for system
board 3
6 2 or 3 system boards use the jumper
for P12V to power on
8 system fan board power connector 2
10 system fan board connector 2
12 system fan connectors 3
14 system fan connectors 5
16 front panel connector 2
18 system fan connectors 3
8
7
9
