Midplane Connectors

Figure 5-7. Midplane Connectors—3.5"
1 midplane connector 1
3 midplane power connector for
system boards 1 and 2
5 front panel connector for system
boards 3 and 4
7 mini-SAS connector for system
boards 3 and 4 (hard drive 1, 2, 3,
and 4)
9 mini-SAS connector for system
boards 1 and 2 (hard drive 1, 2, 3,
and 4)
11 midplane
Figure 5-8. Midplane Connectors—2.5"
2
1
134
Jumpers and Connectors
1
11 10 9
3 4
2
8 7
2 midplane connector 2
4 midplane power connector for
system boards 3 and 4
6 front panel connector for system
boards 1 and 2
8 mini-SAS connector for system
boards 3 and 4 (hard drive 5 and 6)
10 mini-SAS connector for system
boards 1 and 2 (hard drive 5 and 6)
5 6 7
3 4
6 5
9
8 10 11
