Service Manual_2018-V2.0
Service Manual
COMPACT SERIES
Applicable Models
Model Code
Applicable Models
HS-91FN
CE-BD70CM-SQ
22031010003162
The picture in this service manual is only for reference, and specific appearance
and configuration are subject to the real product.
This manual mainly teaches the method, the specific work skill needs engineer to
accumulate through the daily work.
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Midea COMPACT HS-91FN
Summary of Contents for Midea COMPACT HS-91FN
- Page 1 Service Manual_2018-V2.0 Service Manual COMPACT SERIES Applicable Models Model Code Applicable Models HS-91FN CE-BD70CM-SQ 22031010003162 The picture in this service manual is only for reference, and specific appearance and configuration are subject to the real product. This manual mainly teaches the method, the specific work skill needs engineer to accumulate through the daily work.
- Page 2 Service Manual_2018-V2.0 WARNING Important Safety Notice There are special components used in this equipment which are important for safety. These parts are marked in the Schematic Diagrams, Circuit Board Diagrams, Exploded Views and Replacement Parts List. It is essential that these critical parts should be replaced with manufacturer’s specified parts to prevent shock, fire or other hazards.
- Page 3 Service Manual_2018-V2.0 1. Significant update notes (None)
- Page 4 Service Manual_2018-V2.0 2. Safety Warning Code 2.1 Warning for operation safety Important Safety Instructions CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN This symbol indicates that dangerous voltage constituting a risk of electric shock is present within your freezer. This symbol indicates that there are important operating and maintenance instructions in the literature accompanying your freezer.
- Page 5 Service Manual_2018-V2.0 CONNECTING ELECTRICITY Electrical Shock Hazard. Failure to follow these instructions can Plug into a grounded 3-prong outlet. result in death, fire, or electrical shock. Do not remove the ground prong. Do not use an adapter. WARNING Electric Shock Hazard Failure to follow these instructions can result in electric shock, fire, or death.
- Page 6 Service Manual_2018-V2.0 13) Do not store or use gasoline or any flammable liquids inside or in the vicinity of this freezer. 14) Do not use extension cords or ungrounded (two-prong) adapters with this freezer. If the power cord is too short, have a qualified electrician install an outlet near the freezer. Use of an extension cord can negatively affect the freezer’s performance.
- Page 7 Service Manual_2018-V2.0 3. Transport 3.1 Handling Handling 1)Protect the refrigerator in moving it,Same as shown as lef t photo, please move it by handcart with cushion 2)Remove all packing materials and bottom cushion, the m ove into house for placement 3)After moving it to appropriate location, wait for 2 hours bef ore power on.
- Page 8 Service Manual_2018-V2.0 4. Installation and commissioning 4.1 Door Disassembly and Assembly The refrigerator door needs to be dismantled if it cannot enter the room in the whole. 4.2 Installation location Installation location Location that is easy for ventilation shall be chosen to facilitate heat dissipation, enhance its performance and reduce the energy consumption.
- Page 9 Service Manual_2018-V2.0 Unscrew the top cover screws Remove the top cover Remove the hinge cover. Unscrew screws. Remove the upper hinge. Remove the door. Unscrew screws and levelling feet. Remove the lower hinge adjust feet assembly. Fix the levelling feet, lower hinge adjust feet assembly and screws in the opposite side.
- Page 10 Service Manual_2018-V2.0 Place the door stopper and axle sleeve in the opposite side. Place the F door. Place and fix the upper hinge. Fix the hinge cover. Place the top cover. 4.5 Installation of handle（None） 4.6 Installation of door lock（None）...
- Page 11 Service Manual_2018-V2.0 5. Product configuration and dimension 5.1 Main parts and their names (The picture is only for reference, and specific appearance and configuration are subject to the real product) Freezer chamber Refrigerator chamber 1.Screen printing knob2.Temperature control None panel 3.F upper drawer4.F bottom drawer5.Freezer door assembly...
- Page 12 Service Manual_2018-V2.0 8. Dismantling of parts 8.1 Parts on the door Door seal Door seal is installed into door liner groove. 1） Open the refrigerator door; Take the door seal ①out of door liner; Door tray None 8.2 Parts inside the refrigerator Shelves None Freezer Drawer...
