Midea COMPACT HS-78FN Service Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Service Manual_2023-V1.0
Service Manual
COMPACT SERIES
Applicable Models
Model Code
Applicable Models
CE-BD60CM-JQ
HS-78FN
22031010004864
The picture in this service manual is only for reference, and specific
appearance and configuration are subject to the real product.
This manual mainly teaches the method, the specific work skill needs engineer
to accumulate through the daily work.
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the COMPACT HS-78FN and is the answer not in the manual?

Questions and answers

Related Manuals for Midea COMPACT HS-78FN

Summary of Contents for Midea COMPACT HS-78FN

  • Page 1 Service Manual_2023-V1.0 Service Manual COMPACT SERIES Applicable Models Model Code Applicable Models CE-BD60CM-JQ HS-78FN 22031010004864 The picture in this service manual is only for reference, and specific appearance and configuration are subject to the real product. This manual mainly teaches the method, the specific work skill needs engineer to accumulate through the daily work.
  • Page 2 Service Manual_2023-V1.0 WARNING Important Safety Notice There are special components used in this equipment which are important for safety. These parts are marked in the Schematic Diagrams, Circuit Board Diagrams, Exploded Views and Replacement Parts List. It is essential that these critical parts should be replaced with manufacturer’s specified parts to prevent shock, fire or other hazards.
  • Page 3 Service Manual_2023-V1.0 Contents 1. SIGNIFICANT UPDATE NOTES (NONE) ......................5 2. SAFETY WARNING CODE ............................. 6 2.1 W ..........................6 ARNING FOR OPERATION SAFETY 2.2 S ......................... 8 AFETY INSTRUCTION FOR REFRIGERANT 3. TRANSPORT ................................9 3.1 H ..................................9 ANDLING 4. INSTALLATION AND COMMISSIONING ......................10 4.1 D ........................10 ISASSEMBLY AND...
  • Page 4 Service Manual_2023-V1.0...
  • Page 5 Service Manual_2023-V1.0 1. Significant update notes (None)
  • Page 6 Service Manual_2023-V1.0 2. Safety Warning Code 2.1 Warning for operation safety Important Safety Instructions CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN This symbol indicates that dangerous voltage constituting a risk of electric shock is present within your freezer. This symbol indicates that there are important operating and maintenance instructions in the literature accompanying your freezer.
  • Page 7 Service Manual_2023-V1.0 CONNECTING ELECTRICITY Electrical Shock Hazard. Failure to follow these instructions can Plug into a grounded 3-prong outlet. result in death, fire, or electrical shock. Do not remove the ground prong. Do not use an adapter. WARNING Electric Shock Hazard Failure to follow these instructions can result in electric shock, fire, or death.
  • Page 8 Service Manual_2023-V1.0 13) Do not store or use gasoline or any flammable liquids inside or in the vicinity of this freezer. 14) Do not use extension cords or ungrounded (two-prong) adapters with this freezer. If the power cord is too short, have a qualified electrician install an outlet near the freezer. Use of an extension cord can negatively affect the freezer’s performance.
  • Page 9 Service Manual_2023-V1.0 3. Transport 3.1 Handling Handling 1)Protect the refrigerator in moving it,Same as shown as rig ht photo, please move it by handcart with cushion 2)Remove all packing materials and bottom cushion, the m ove into house for placement 3)After moving it to appropriate location, wait for 2 hours bef ore power on.
  • Page 10 Service Manual_2023-V1.0 4. Installation and commissioning 4.1 Door Disassembly and Assembly The refrigerator door needs to be dismantled if it cannot enter the room in the whole. 4.2 Installation location Installation location Location that is easy for ventilation shall be chosen to facilitate heat dissipation, enhance its performance and reduce the energy consumption.
  • Page 11 Service Manual_2023-V1.0 4.4 Left or right open door reversal Door reversal Dismantle the upper hinge cover， screws and upper hinge，and remove the plastic screw hole caps from the other side. Dismantle the door and the bottom hinge assembly and adjustable foot, then assemble the bottom hinge assembly and adjustable foot on other side.
  • Page 12 Service Manual_2023-V1.0 Put the door on bottom hinge and assemble the upper hinge, upper hinge cover and plastic screw hole caps successively. 4.5 Installation of handle（None） 4.6 Installation of door lock（None）...
  • Page 13 Service Manual_2023-V1.0 5. Product configuration and dimension 5.1 Main parts and their names (The picture is only for reference, and specific appearance and configuration are subject to the real product) Freezer chamber Refrigerator chamber 1、Drawer flip None 2、Fruits and vegetables box 3、Temperature control knob 4、Freezer door assembly...
  • Page 14 Service Manual_2023-V1.0 5.2 External dimension Description Code Size (mm) Height to Top of Case Width Depth w/Cabinet Depth w/Door Depth w/Handle Depth (Door open 90 deg. w) Width (Door open 180 deg. w) Depth (Door open 180 deg. w) (The picture is only for reference)
  • Page 15 Service Manual_2023-V1.0 5.3 Location of S/N Some products also have S/N on the lower part of the right side of the Cabinet.
  • Page 16 Service Manual_2023-V1.0 6. Product specification 6.1 Electrical parameters CE-BD60CM-JQ Product Name Applicable Models HS-78FN Item Specification Specification Refrigerant R600a Compressor N075YL Starter(PTC) QP2-15 Overload protector(OLP) DRB12R61A1 Integrate PTC+OLP None Variable frequency driver board None Capacitor None Power filter None Rmc: 60.5±7％Ω Winding resistance of compressor Rsc: 18.7±7％Ω...
  • Page 17 Service Manual_2023-V1.0 6.3 Circuit diagram...
  • Page 18 Service Manual_2023-V1.0 8. Dismantling of parts 8.1 Parts on the door Door seal It's more convenient to pull out from the corner. Take the door seal ①out of door liner; When reloading, the door must be installed into the tank, carefully pressed flat, and check whether there is a gap between the door seal and the box body.
  • Page 19 Service Manual_2023-V1.0 Remove the freezer drawer according to below steps: 1）；Pull the drawer out completely; 2）；Lift it up slightly and take it out from the refrigerator.
