Lennox MWZD Manual

MWZD WALL | Standard Efficiency
Wall-Mount Indoor Units | RDS Sensor Furnished |
R E S I D E N T I A L / C O M M E R C I A L
P R O D U C T S P E C I F I C AT I O N S ( E H B )
M OD EL NU MBER ID EN T IF IC AT ION
Series Type
M = Mini-Split
WZ = Wall-Mount Indoor Units with RDS | Standard Efficiency
MWZD Wall-Mount Indoor Unit with RDS Sensor
M WZ D 012 M 6 - 1 P
Unit Type
Major Design Sequence
D = 4th Generation
Nominal Cooling Capacity
007 = 0.50 tons
009 = 0.75 tons
012 = 1 tons
015 =1.25 tons
018 = 1.5 tons
024 = 2 tons
R-32 | 60 Hz
and Furnished Wireless Remote Controller
M I N I - S P L I T S Y S T E M S
Voltage
P = 208/230V-1 phase-60Hz
Minor Design Sequence
1 = 1st Revision
Refrigerant Type
6 = R-32
Zone Type
M = Multi
Form Number 211097 | March 2025
Supersedes all previous versions
0.50 to 2 Tons
