ML14XC1 (HFC- 410A) SERIES OUTDOOR UNITS (3-PHASE)
WARNING
Improper installation, adjustment, alteration, service
or maintenance can cause property damage, personal
injury or loss of life. Installation and service must be
performed by a licensed professional HVAC installer or
equivalent, service agency, or the gas supplier.
IMPORTANT
The Clean Air Act of 1990 bans the intentional venting of
refrigerant (CFCs, HCFCs and HFCs) as of July 1, 1992.
Approved methods of recovery, recycling or reclaiming
must be followed. Fines and/or incarceration may be
levied for noncompliance.
CAUTION
As with any mechanical equipment, contact with sharp
sheet metal edges can result in personal injury. Take
care while handling this equipment and wear gloves and
protective clothing.
WARNING
Electric Shock Hazard. Can cause injury or
death. Unit must be properly grounded in
accordance with national and local codes.
Line voltage is present at all components when
unit is not in operation on units with single-
pole contactors. Disconnect all remote electric
power supplies before opening access panel.
Unit may have multiple power supplies.
IMPORTANT: Special procedures are required for clean-
ing the aluminum coil in this unit. See page 24 in this man-
ual for information.
UNIT INFORMATION
Corp. 100047
April 21, 2022

Table of Contents

Model Number Identification ...........................................2
Typical Serial Number Identification ...............................2
Specifications ................................................................3
Electrical Data ...............................................................3
Unit Dimensions - Inches (mm) ....................................4
Typical Unit Parts Arrangement .....................................5
Installation ......................................................................8
Unit Placement ..............................................................8
New or Replacement Line Set ...................................... 11
Brazing Connections ...................................................13
Flushing Line Set and Indoor Coil ................................16
Installing Indoor Metering Device .................................17
Leak Testing the System .............................................18
Evacuating Line Set and Indoor Coil ...........................19
Maintenance ...............................................................24
Typical Field Wiring ......................................................26
Unit Start-Up ...............................................................27
System Refrigerant .....................................................27
This unit must be matched with an indoor coil as specified
with AHRI. For AHRI Certified system match-ups and
expanded ratings, visit www.LennoxPros.com. Coils
previously charged with HCFC-22 must be flushed.
General Information
This ML14XC1 outdoor air conditioner with all-aluminum
coil is designed for use with HFC-410A refrigerant only.
This unit must be installed with an approved indoor air
handler or coil. For AHRI Certified system match-ups and
expanded ratings, visit www.LennoxPros.com. These in-
structions are intended as a general guide and do not su-
persede local codes in any way. Consult authorities hav-
ing jurisdiction before installation.
This outdoor unit is designed for use in systems that use
the following refrigerant metering device:
• Thermal expansion valve (CTXV)
Page 1
ML14XC1
3-PHASE
IMPORTANT

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ML14XC1 Series and is the answer not in the manual?

Questions and answers

Roman Nawrocky
April 9, 2025

pressure switch part number for ML 14xc1s042-a03

1 comments:
Mr. Anderson
April 10, 2025

The pressure switch part number for the Lennox ML14XC1 Series model ML14XC1S042-A03 is S4 (High Pressure Switch).

This answer is automatically generated

Summary of Contents for Lennox ML14XC1 Series

  • Page 1: Table Of Contents

    ML14XC1 UNIT INFORMATION Corp. 100047 3-PHASE April 21, 2022 Service Literature ML14XC1 (HFC- 410A) SERIES OUTDOOR UNITS (3-PHASE) Table of Contents Model Number Identification ...........2 Typical Serial Number Identification .......2 Specifications ..............3 Electrical Data ...............3 Unit Dimensions – Inches (mm) ........4 Typical Unit Parts Arrangement ........5 Operating Gauge Set and Service Valves ......6 Installation ..............8...
  • Page 2: Model Number Identification

    Model Number Identification ML 14 X C 1 - 036 - 233 A 01 Product Tier Revision Level ML = Merit Series Nominal SEER 14 = 14 SEER Ratings Revision Level Refrigerant Type X = R-410A Voltage 233 = 208/230V-3 ph-60Hz-Y voltage 463 = 460V-3 ph-60Hz- G voltage Unit Type 573 = 573V-3 ph-60Hz- J voltage...
  • Page 3: Specifications

    Specifications General Model No. - 208/230V-3ph ML14XC1-036-233 ML14XC1-042-233 ML14XC1-048-233 ML14XC1-060-233 Data Model No. - 460V-3ph ML14XC1-036-463 ML14XC1-042-463 ML14XC1-048-463 ML14XC1-060-463 Model No. - 575V-3ph ML14XC1-036-573 - - - ML14XC1-048-573 ML14XC1-060-573 Nominal Tonnage Indoor Unit Expansion Valve (TXV) 12J19 12J20 12J20 12J20 Sound Rating Number Connections Liquid line o.d.
  • Page 4: Unit Dimensions - Inches (Mm)

    Unit Dimensions – Inches (mm) 4-3/8 4-3/8 (111) (111) INLET 4-3/8 4-3/8 (111 111) OPTIONAL UNIT INLET INLET STAND-OFF KIT (4) COMPRESSOR (Field Installed) COIL DRAIN OUTLETS (Around perimeter of base) 6-3/8 SUCTION LINE 4-3/8 (162) CONNECTION (111) LIQUID LINE INLET 6-3/8 4-3/8...
  • Page 5: Typical Unit Parts Arrangement

    Typical Unit Parts Arrangement CONTROL PANEL CONTROL PANEL 230/460V 575V COMPRESSOR HARNESS COMPRESSOR HARNESS HIGH PRESSURE HIGH PRESSURE SWITCH (S4) SWITCH (S4) LIQUID LINE LIQUID LINE SERVICE VALVE SERVICE VALVE LIQUID LINE LIQUID LINE SUCTION LINE SERVICE VALVE SERVICE VALVE SUCTION LINE SERVICE VALVE PORT...
  • Page 6: Operating Gauge Set And Service Valves

    Gauge hoses must be rated for use at up to 800 psig recess. of pressure with a 4000 psig burst rating. See the Lennox Service and Application Notes #C-08-1 for further details and information. OPERATING SERVICE VALVES The liquid and vapor line service valves are used for re-...
  • Page 7 SERVICE VALVES ANGLE AND BALL Operating Angle Type Service Valve: 1. Remove stem cap with an appropriately sized wrench. 2. Use a service wrench with a hex-head extension (3/16” for liquid line valve sizes and 5/16” for vapor line valve sizes) to back the stem out counterclockwise as far as it will go.
  • Page 8: Installation

    Installation The slab should have a slope tolerance as described in Unit Placement figure 6, detail B. See Unit Dimensions on page 4 for sizing mounting slab, NOTE – If necessary for stability, anchor unit to slab as platforms or supports. described in figure 4, detail B.
  • Page 9 DETAIL B DETAIL A Install unit level or, if on a slope, maintain slope tolerance of 2 degrees INSTALL UNIT AWAY (or 2 inches per 5 feet [50 mm per 1.5 m]) away from building structure. FROM WINDOWS DISCHARGE AIR BUILDING STRUCTURE MOUNTING...
  • Page 10: Removing And Installing Louvered Panels

    Removing and Installing Louvered Panels WARNING To prevent personal injury, or damage to panels, unit or structure, be sure to observe the following: While installing or servicing this unit, carefully stow all removed panels out of the way, so that the panels will not cause injury to personnel, nor cause damage to objects or structures nearby, nor will the panels be subjected to damage (e.g., being bent or scratched).
  • Page 11: New Or Replacement Line Set

    (braze connections) to the indoor to a spark or open flame, can cause fire and/ unit coil (flare or braze connections). Use Lennox L15 or an explosion, that could result in property (braze, non-flare) series line set, or use field-fabricated damage, personal injury or death.
  • Page 12 LINE SET IMPORTANT — Refrigerant lines must not contact structure. INSTALLATION REFRIGERANT LINE SET — INSTALLING Line Set Isolation — The following illustrations are VERTICAL RUNS (NEW CONSTRUCTION SHOWN) examples of proper refrigerant line set isolation: NOTE — Insulate liquid line when it is routed through areas where the surrounding ambient temperature could become higher than the REFRIGERANT LINE SET —...
  • Page 13: Brazing Connections

    Polyol ester (POE) oils are used Perform operations only in well-ventilated areas. in Lennox units charged with HFC-410A refrigerant. Wear gloves and protective goggles or face shield to Residual mineral oil can act as an insulator, preventing protect against burns.
  • Page 14 CAP AND CORE REMOVAL PIPING PANEL REMOVAL AND LINE SET PREPARATION Remove service cap and core from both the suction and liquid line service ports. Remove piping panel for easier access to service valves. Cut ends SERVICE PORT CAP of the refrigerant lines square (free from nicks or dents) and debur the ends.
  • Page 15 WRAP SERVICE VALVES To help protect service valve seals during brazing, wrap water-saturated cloths around service valve bodies and copper tube stubs. Use additional water-saturated cloths underneath the valve body to protect the base paint. FLOW NITROGEN Flow regulated nitrogen (at 1 to 2 psig) through the refrigeration gauge set into the valve stem port connection on the liquid service valve and out of the suction / vapor valve stem port.
  • Page 16: Flushing Line Set And Indoor Coil

    Flushing Line Set and Indoor Coil TYPICAL EXISTING FIXED ORIFICE TYPICAL EXISTING EXPANSION VALVE REMOVAL REMOVAL PROCEDURE (UNCASED PROCEDURE (UNCASED COIL SHOWN) COIL SHOWN) STUB END TWO PIECE PATCH PLATE LIQUID LINE CHECK DISTRIBUTOR TUBES (UNCASED COIL ONLY) ORIFICE EXPANSION LIQUID LINE ORIFICE HOUSING HOUSING VALVE...
  • Page 17: Installing Indoor Metering Device

    Installing Indoor Metering Device This outdoor unit is designed for use in systems that use expansion valve in a manner that will provide access for an expansion valve (TXV) metering device at the indoor field servicing of the expansion valve. Refer to below illus- coil.
  • Page 18: Leak Testing The System

    IMPORTANT Leak Testing the System The Environmental Protection Agency (EPA) prohibits IMPORTANT the intentional venting of HFC refrigerants during maintenance, service, repair and disposal of appliance. Leak detector must be capable of sensing HFC refrigerant. Approved methods of recovery, recycling or reclaiming must be followed.
  • Page 19: Evacuating Line Set And Indoor Coil

    Evacuating Line Set and Indoor Coil CONNECT GAUGE SET HIGH NOTE — Remove cores from service valves (if not already done). Connect low side of manifold gauge set with 1/4 SAE in-line tee to vapor line service valve Connect high side of manifold gauge set to liquid line service valve OUTDOOR MANIFOLD...
  • Page 20: Electrical - Circuit Sizing And Wire Routing

    IMPORTANT Electrical – Circuit Sizing and Wire Routing In the U.S.A., wiring must conform with current local codes Use a thermocouple or thermistor electronic vacuum and the current National Electric Code (NEC). In Canada, gauge that is calibrated in microns. Use an instrument wiring must conform with current local codes and the cur- capable of accurately measuring down to 50 microns.
  • Page 21 ROUTING HIGH VOLTAGE/ GROUND AND CONTROL WIRING CAPACITOR HIGH VOLTAGE / GROUND WIRES HIGH VOLTAGE FIELD WIRING Any excess high voltage field wiring should be trimmed and LOW VOLTAGE secured away from any low voltage field wiring. To facilitate a FIELD WIRING GROUND conduit, a cutout is located in the bottom of the control panel.
  • Page 22 FIGURE 15. Typical Factory Wiring – G and Y Voltages Page 22...
  • Page 23 FIGURE 16. Typical Factory Wiring – J Voltage Page 23...
  • Page 24: Maintenance

    (S40) located on the liquid line (see figure 1 for at a moderate pressure (less than 50psi). If the location). coil cannot be cleaned using water alone, Lennox When liquid line temperature drops below 50° F the ther- recommends use of a coil cleaner with a pH in the mostat closes energizing HR1.
  • Page 25 7. Inspect the duct system for leaks or other problems. General System Test with System Operating Repair or replace as necessary. 1. Your technician should perform a general system test. 8. Check for bearing/bushing wear on indoor blower mo- He will turn on the air conditioner to check operating tor.
  • Page 26: Typical Field Wiring

    CONTROL INDOOR BLOWER WIRING WIRE RUN LENGTH AWG# INSULATION TYPE LESS THAN 100' (30 METERS) TEMPERATURE RATING COMMON MORE THAN 100' (30 METERS) 16 35ºC MINIMUM. Typical Field Wiring Typical Field Wiring Diagram (Y and G Voltages) Typical Field Wiring Diagram (J Voltage) FIGURE 17.
  • Page 27: Unit Start-Up

    6 - Set the thermostat for a cooling demand. Turn on Unit Start-Up power to the indoor unit and close the outdoor unit disconnect switch to start the unit. IMPORTANT 7 - Recheck voltage while the unit is running. Power If unit is equipped with a crankcase heater, it should must be within range shown on the nameplate.
  • Page 28 ADDING OR REMOVING REFRIGERANT This system uses HFC-410A refrigerant which operates at much higher pressures than HCFC-22. The pre-installed liquid line filter drier is approved for use with HFC-410A only. Do not replace it with components designed for use with HCFC-22. This unit is NOT approved for use with coils which use capillary tubes or fixed orifices as a refrigerant metering device.
  • Page 29 1. Confirm proper airflow across coil using figure 65ºF START: Measure outdoor ambient temperature (18.3ºC) and 2. Compare unit pressures with normal operating Above pressures provided on applicable charging USE WEIGH IN METHOD DO NOT CHARGE UNIT sticker as reference in table 1. ABOVE or 3.
  • Page 30 TABLE 3. HFC-410A Temperature – Pressure (Psig) °F °C Psig °F °C Psig -40.0 11.6 15.6 -37.2 14.9 18.3 -34.4 18.5 21.1 -31.7 22.5 23.9 -28.9 26.9 26.7 -26.1 31.7 29.4 -23.3 36.8 32.2 -20.6 42.5 35.0 -17.8 48.6 37.8 -15.0 55.2 40.6...
