- Page 1 PREMIUM LTE SERIES PRODUCT MANUAL Blaze LTE+ 30in Griddle Premium LTE Series Blaze LTE2 30in Griddle BLZ-GRIDDLE-LTE30-LP/NG BLZ-GRIDDLE-LTE2-LP/NG SCAN TO REGISTER BlazeGrills.com...
-
Page 2: Table Of Contents
Blaze LTE PRO 30in Griddle Premium LTE Series Unpacking Unit: Table of Contents: Your Blaze Series appliance comes preassembled Unpacking Your Unit and requires very little setup. We do recommend the use of professional help during the installation of your Blaze Introduction / Records unit as improper installation may affect your warranty. -
Page 3: Blaze Introduction / Records
____________________________________________ workmanship of every Blaze product. SERIAL #: Thank you for choosing Blaze and welcome to our family ____________________________________________ of passionate outdoor enthusiasts. We look forward to being a part of your outdoor cooking adventures and... -
Page 4: General Safety And Installation Warnings
Blaze LTE PRO 30in Griddle Premium LTE Series General Safety and Installation Warnings WAR NIN G READ INSTRUCTIONS: Please read this IN MASSACHUSETTS: All gas products manual carefully and before using your must be installed using a “Massachusetts” BLAZE GRIDDLE to ensure proper operation, licensed plumber or gasfitter. - Page 5 Failure to do so could Blaze products come "ready-to-use" but, in some instances like not lighting, it's essential to check burner alignment. Step 1: Remove and lift away griddle cooking surface.
-
Page 6: Specifications
Blaze LTE PRO 30in Griddle Premium LTE Series Griddle Specifications Specifications: Dimensions: BTU output 15,000 BTU per burner (x2) Product dimensions 30 1/8” W x 27 1/5” D x 16 1/3” H Back burner Cutout dimensions: 28 1/4” W x 24 1/4” D x 11 3/4”... -
Page 7: Exploded View & Replacement Parts
10. Power button 15. Badge 11. Regulator hose 12. LED 14. Power supply 13. transformer harness harness Blaze Part Number: Reference Guide BLZ-LTE3-018 1. BLZ-GRIDDLELTE3-003 10. BLZ-3PRO18-003 19. BLZ-GRIDDLE-003 2. BLZ-32-012W 11. BLZ-LP-HOSE/REG 20. BLZ-GRIDDLELTE3-011 3. BLZ-GRIDDLELTE3-004 12. BLZ-GRIDDLELTE3-002 4. BLZ-GRIDDLELTE3-012 13. -
Page 8: Clearance To Combustibles
Blaze LTE PRO 30in Griddle Premium LTE Series Cavity Cutout Size 27 1/5" 30 1/8" 16 1/3" 10 4/5" 11 3/4" cavity cavity 28 1/4" 24 1/4" If the countertop of your outdoor kitchen extends beyond the edge of the island, it will be necessary to 3/4"... - Page 9 The vent hood must provide protection for the overhead construction. The bottom of the exhaust fan should be placed 36'' above the cooking surface. It is imperative that a Blaze appliance is not installed under combustible overhead construction. When installed under overhead non-combustible construction, a vent hood is still recommended.
-
Page 10: Important Safety Instructions
Blaze LTE PRO 30in Griddle Premium LTE Series Important Safety Instructions • All gas appliances will get hot during use. Use • Always open the appliance hood carefully, using only extreme caution when operating the appliance. the handle – the hood may be hot. - Page 11 BLZ-GRIDDLE-LTE3-LP/NG • Non-combustible enclosure: The Blaze griddle must • Maintenance access: When your appliance is be installed in a noncombustible enclosure only. The installed, you should be able to access the gas supply determination of whether a location is combustible...
-
Page 12: Electrical Safety
Blaze LTE PRO 30in Griddle Premium LTE Series Electrical Safety and Installation Warnings Extension cords may be used if care is exercised in • Do not operate any appliance with a damaged their use. If an extension cord is used:... -
Page 13: Gas Safety And Installation Warnings
WARNING: DO NOT USE OPEN FLAME Use only replacement regulator and hose TO CHECK FOR LEAKS. USE OF AN assemblies specified by BLAZE KITCHEN CO. OPEN FLAME COULD RESULT IN A FIRE, EXPLOSION AND BODILY HARM. WARNING: DO NOT USE A DENTED, EXPIRED, OR RUSTED LP CYLINDER. -
Page 14: Gas Connections
Blaze LTE PRO 30in Griddle Premium LTE Series Gas Connections Install the factory-supplied hose and regulator assembly as shown: Procedure for LP Cylinder Connection (20 lbs.): All purging and refilling of LP cylinders must be performed by qualified personnel in the LP gas industry. -
Page 15: Natural Gas Installation
BLZ-GRIDDLE-LTE3-LP/NG Natural Gas Installation: Natural gas Connection: The installation must conform with local codes or, in the • Connect a suitable natural gas flex connector to the absence of local codes, with either the National Fuel Gas griddle regulator located on the rear right corner Code, ANSI Z223.1/NFPA 54, Natural Gas and Propane of the appliance. -
Page 16: Fuel Conversions
Blaze LTE PRO 30in Griddle Premium LTE Series Fuel Conversion Fuel (Gas) Conversion Instructions Convertible Gas Regulator (if applicable): for Blaze gas griddle: Caution: This should only by performed by a licensed Caution: This should only by performed by a gas professional. -
Page 17: Local Codes
BLZ-GRIDDLE-LTE3-LP/NG Checking for Gas Leaks: Local Codes: • Perform a leak test before each use and when- • The self-contained LP system appliance is design ever the gas cylinder is connected to the regulator certified to be used with a standard 20 lb., 12 1/4" or whenever any part of the gas system is discon- diameter;... -
Page 18: Installing The Appliance
Blaze LTE PRO 30in Griddle Premium LTE Series Installing the Appliance in a BBQ Island Safety Information and Install: the consumer can dictate their preference. Ensure your island cavity is adequately vented. Number of vents shown in diagram is for informational purposes Two person lift: You will need a second person to only. -
Page 19: Ventilation
5 inches from the installation. Stainless steel vent panels are available from bottom of the island to the top of the vent. your dealer to cover the island venting. A Blaze insulating • Vents must meet ANSI standard codes. -
Page 20: First-Time Operation
Blaze LTE PRO 30in Griddle Premium LTE Series First-Time Operation Powering the Griddle: Warning: Before lighting the burners inspect the gas Step 1: Make sure unit is plugged into a 15-AMP supply piping or hose. If there is evidence of cuts, wear, Breaker with GFI protection. -
Page 21: Lighting The Appliance
BLZ-GRIDDLE-LTE3-LP/NG Lighting the Appliance: Step 4: Push in and turn the control knob to HIGH. Step 1: Open the hood. Step 5: If the burner does not light after five seconds, turn the control knobs to the OFF position. Step 2: Use caution when lighting burners by standing Step 6: Wait five minutes until the gas clears before... - Page 22 Blaze LTE PRO 30in Griddle Premium LTE Series Seasoning: Seasoning Instructions: Follow these simple cleaning and seasoning steps for STEP 1: Clean the griddle. Remove all food debris with optimal performance and long life of your griddle. spatula or scraper. Rinse and dry.
-
Page 23: Perfect Pancake Recipe
BLZ-GRIDDLE-LTE3-LP/NG Tips for Seared Steaks: Preheat the Griddle: Start with a high temperature (450°F-500°F) to sear the first side of the steak for a flavorful crust. Finish Cooking: After searing, reduce the temperature to 375°F-400°F to finish cooking to your desired doneness. Use a Thermometer: For accurate results, use a meat thermometer to check the internal temperature (e.g., 130°F for medium-rare). -
Page 24: How To Guide/Cleaning
(which will cause the appearance of rust). • The Blaze griddle heats very quickly, and very evenly! *Vinyl covers are the best way to protect appliances from the elements. They can be purchased through •... -
Page 25: Cleaning Your Griddle
BLZ-GRIDDLE-LTE3-LP/NG spots if left to dry. of griddle and scrub with stainless steel scrub pad to remove remaining staining and grease. Move liquid to Dry the griddle: Use a clean, dry microfiber cloth to drip tray. dry the griddle thoroughly. This helps to prevent water 3. -
Page 26: Warranty
The incorrect installation • Valves - Lifetime (Parts Only) of the Blaze gas appliance will void the warranty. Please call Blaze for more information on correct installation of Multi-user warranty the gas appliance. -
Page 27: Frequently Asked Questions
Frequently Asked Questions: Please leave these instructions with the Q: Where can I register my product? consumer. Your Blaze product can be register at blazegrills.com/ Please read and retain support/register-your-product/. these instructions for future reference and Q: Can I still register if it has been over 30 days? before installation or operation.
