- Page 1 Oslo Sauna Add On Heater Installation Models Prior to 2023 0800 99 33 88 | service@alpinespas.co.nz | www.alpinespas.co.nz 1800 99 33 88 | service@alpinespas.com.au | www.alpinespas.com.au...
- Page 3 CONTENTS Important Safety & Operational Cautions Parts Check Assembly Instructions Notes Oslo Model 2023 Serial Number 24010435-2301869 Oslo Model 2021-2022 Serial Number 2301868 and below...
- Page 4 IMPORTANT SAFETY & OPERATIONAL CAUTIONS PLEASE READ THE ENTIRE MANUAL THROUGHLY BEFORE PROCEEDING WITH INSTALATION SAFETY THIS PRODUCT NEEDS TO BE CONNECTED TO AN ELECTRICAL SUPPLY THAT HAS AN APPROPRIATELY RATED RCD AND INSTALLED ACCORDING TO NATIONAL ELECTRICAL STANDARDS. IF YOU ARE UNCERTAIN IF YOUR POWER SUPPLY IS PROTECTED BY AN RCD, CONTACT YOUR LOCAL ELECTRICIAN TO CONFIRM.
- Page 5 A danger of electrical shock exists. DO NOT attempt any repair without consulting Alpine Spas first. Unauthorised repair attempts will void warranty. Unplug the sauna from the wall outlet before cleaning DO NOT use liquid cleaners or aerosol cleansers inside the sauna.
-
Page 6: Parts Check
PARTS CHECK Tools required include screw drivers set, power drill set, measuring tape, level, hand saw. Supplied tools - 30mm Hole Saw. INSTALLATION PARTS Front Heater Screws: Wood Bar Eye Bar 3pc 4*40mm for Wood Eye Bar Wooden Cable Cover for Inside Cover 6pc 3*35mm for Wooden Cable PVC Cable Covers for Outside 8pc 3*8mm for PVC Cable Cover... - Page 7 ASSEMBLY INSTRUCTIONS Your front heater may require additional assembly prior to installation on your Oslo Sauna. Unscrew the 4 small screws to remove the black glass front (Figure A) Gently insert (either way around) the glass bulb into the socket at one of the ends...
- Page 8 ASSEMBLY INSTRUCTIONS 2023 Oslo Model Serial numbers 24010435 - 2301869 Remove all components from the box and check off against the list. Unplug Sauna from the wall to cut off the power supply. We recommend unscrewing the 2x 4*40mm screws from the bench seat and setting the screws aside while completing the next steps.
- Page 9 ASSEMBLY INSTRUCTIONS Drill another hole in the back panel Using the supplied Hole saw create of the sauna. Start under the bench a hole in the lower left foot area of the seat and drill toward the back wall bench seat support. This needs to be at at least 20mm from the floor and in least 20mm from the floor and 20mm 40mm from the left wall.
- Page 10 ASSEMBLY INSTRUCTIONS PVC hole covers are to be used for Install Wood eye bar against the right each of the 3 holes drilled. hand wall, between the door frame and Thread a PVC hole cover over the heat- the right wall heater using 4*40mm er cable from the screw end toward the screws.
- Page 11 ASSEMBLY INSTRUCTIONS The final cable layout should look similar to the below...
- Page 12 ASSEMBLY INSTRUCTIONS Connect the heater cable running Measure the distance from the bench from the bench support to the front support hole and the edge of the wooden heater cable protruding from the eye bar allowing for the heater cable. Cut bottom of the front heater using pre the Wooden cable cover to size place the installed connector.
- Page 13 ASSEMBLY INSTRUCTIONS Plug in the Heater cable into the Measure the distance vertically up console on the roof into the next the back wall and cut the PVC cable available power slot. Replug the main cover if nessesary. power cable and switch on. Fix one section of the PVC Cable Cover along the cable route up the back wall and screw in place using the 3*8mm...
- Page 14 ASSEMBLY INSTRUCTIONS 2021/2022 Oslo Model Serial numbers 2301868 and below Remove all components from the box and check off against the list. Unplug Sauna from the wall to cut off the power supply. Using the supplied Hole Saw drill a hole in the back panel on the lower left side under the seat.
- Page 15 ASSEMBLY INSTRUCTIONS PVC hole covers are to be used for Install Wood eye bar against the right hole drilled. hand wall, between the door frame and the right wall heater using 4*40mm Thread a PVC hole cover over the screws. The notched end should sit heater cable from the screw end flush against the skirting board with a toward the plug end.
- Page 16 ASSEMBLY INSTRUCTIONS Measure the distance from the bench Connect the heater cable support hole and the edge of the wooden running from the bench support eye bar allowing for the heater cable. Cut to the front heater cable protrud- the Wooden cable cover to size place the ing from the bottom of the front cable underneath and screw in place using heater using pre installed con-...
- Page 17 ASSEMBLY INSTRUCTIONS Measure the distance vertically up the The final cable layout should look back wall and cut the PVC cable cover if similar to the below, with the arrows nessesary. marking the cable run. Fix one section of the PVC Cable Cover along the cable route up the back wall and screw in place using the 3*8mm screws.
- Page 18 NOTES...
- Page 19 NOTES...
-
Page 20: Contact Information
CONTACT INFORMATION If you need assistance, please get in touch via phone or email. service@alpinespas.co.nz 0800 99 33 88 service@alpinespas.com.au 1800 99 33 88 For a digital copy of this guide and also the outdoor sauna user guide visit: http://alpinespas.co.nz/support/ http://alpinespas.com.au/support/ Version 26042024...
