Vista Barrel Sauna
Assembly Manual
Harvia Heater Edition
Assembly VIDEO available from our support page:
http://alpinespas.co.nz/support OR
http://alpinespas.com.au/support
0800 99 33 88 | service@alpinespas.co.nz | www.alpinespas.co.nz
1800 99 33 88 | service@alpinespas.com.au | www.alpinespas.com.au

Advertisement

loading
Need help?

Need help?

Do you have a question about the Vista Barrel Sauna and is the answer not in the manual?

Questions and answers

Related Manuals for Alpine Spas Vista Barrel Sauna

Summary of Contents for Alpine Spas Vista Barrel Sauna

  • Page 1 Vista Barrel Sauna Assembly Manual Harvia Heater Edition Assembly VIDEO available from our support page: http://alpinespas.co.nz/support OR http://alpinespas.com.au/support 0800 99 33 88 | service@alpinespas.co.nz | www.alpinespas.co.nz 1800 99 33 88 | service@alpinespas.com.au | www.alpinespas.com.au...
  • Page 2 IMPORTANT! READ THIS SECTION ENTIRELY BEFORE PROCEEDING WITH INSTALLATION. LOCATION Think carefully about where you want to locate the sauna. After you have completed the installation the sauna won’t be able to be moved due to its size and weight. The sauna will need to be in a location that can have power access installed.

  • Page 3: Three Phase

    BEFORE YOU START ELECTRICS - HEATER Three Phase The provided sauna heater must be installed by a registered electrician. No wiring, For three phase installation, connect each phase to L4, L5 and L6. switches, RCD or electrical accessories are included. Setup Install the heater as per the manufacturer instructions included, along with any electrical protective devices .

  • Page 4: Warranty

    14. DO NOT use the unit during an electrical storm, as there is a remote risk of shock. INDOOR SAUNAS*: Alpine Spas warrant the workmanship against defects in materials and 15. Altering or tampering of any electrical connections on the power supply will void the manufacturer’s warranty.

  • Page 5: Parts List

    PRE-ASSEMBLY CHECKS PARTS LABELED PARTS LIST Installation Parts Part Name Label* Part Name Label* Inside Floor Panel Regular Staves Outside Floor Panel Starting Bottom Stave Final Top Stave 5 (several sizes) Glass Door Front Edge Capping Glass Door Hinges (with Allen key) 2 Set Rear Edge Capping Door Handle, Magnet &...

  • Page 6: Foundation Requirements

    PRE-ASSEMBLY CHECKS FOUNDATION TOOLS An outdoor sauna can weigh up to 600kg once assembled, therefor requires a sturdy foundation. This needs Tools required include screw drivers set, power drill set, measuring tape, level, mallet, socket set, to be a flat, level surface that supports the entire weight of the sauna and users. We recommend using either a concrete slab or a pile foundation.
  • Page 7 INSTALLATION INSTRUCTIONS Stand all three cradles bases, equal distance apart The double sided base support screw is used to connect There are four double ended screws for the end cradle Secure the cradle support lengths by placing the half matching the length of the four cradle support lengths. the end cradle base supports to the support lengths.
  • Page 8 INSTALLATION INSTRUCTIONS Next, screw the bottom stave into the cradle base Begin to lay 2x staves on either side of the mounted Continue to thoroughly oil the bottom of the base, use The base should now be completely oiled. Double check supports using 3x ‘5*50mm’...
  • Page 9 INSTALLATION INSTRUCTIONS Install 10x more staves onto either side of the barrel. Use a rubber mallet to gently tighten up the staves as you go. Continue to install 7x more staves one by one on each Add the next 7 staves to each side but DO NOT SCREW Use ‘3*30mm Screws’...
  • Page 10 INSTALLATION INSTRUCTIONS OILING - For maximum coverage, we want to oil under Locate your steel bands and remove the blue protective Once all 3 bands are in place and bolted together, adjust the heights of the six bolts so they are level on both sides. Tighten the steel bands.
  • Page 11 INSTALLATION INSTRUCTIONS OILING - Tape off the door frame, rear window and protect the inside doorway from drips. Continue to oil the exterior Position segment F2 and F along the drip edge, making sure the flat part of the segment is flush with the bottom of the drip thoroughly.
  • Page 12 INSTALLATION INSTRUCTIONS Locate the 14 oiled decorative boards and begin to Place the pre-oiled exterior floor panel in position and Secure it in place using 2x 4*40mm screws into the pre- Lay the bench seat on top and position it into place. install these, start from the top center and work your ensure it is level before securing using 2x 4*40mm drilled holes on the side supports.
  • Page 13 Secure the hinges to the glass door using the provided Install the door handle using the 6*75mm screw. Be Harvia Heater Installation Instructions hinges and allen key. Position the door in place and sure to put the oiled handle on the outside. secure the hinges to the recessed frame using the 4*40mm screws.
  • Page 14 Notes Sketch...

  • Page 15: Contact Information

    CONTACT INFORMATION If you need assistance, please get in touch via phone or email. service@alpinespas.co.nz 0800 99 33 88 service@alpinespas.com.au 1800 99 33 88 For a digital copy of this guide and also the outdoor sauna user guide visit: http://alpinespas.co.nz/support/ http://alpinespas.com.au/support/ Version 230911...
