- Page 1 Pizza Maestro OUTDOOR USE ONLY! Read the operating instructions and warnings before using the appliance. FCC-G-22562 Assembly, maintenance and safety...
-
Page 3: The Story Of Fcc
THE STORY OF FCC The Flying Culinary Circus is the world’s first traveling cooking group. In 2005 Trond, Hans-Kristian, Mathias, and Tor went to New York. A journey that ended up being an adventure of a lifetime. With 65 countries and 300,000 hours of culinary experience in the Chef... -
Page 4: Table Of Contents
CONTENTS The story of FCC................3 Warnings ..................5 Technical data ................6 Read before assembly ...............7 Parts list..................8 Exploded drawing...............9 Assembly instructions ............10 Regulator and hose - Connecting the gas ......13 Gas leak test ................14 User instructions ..............15 Lighting instructions ...............16 Maintenance................18... -
Page 5: Read Before Assembly
READ BEFORE ASSEMBLY ● Some parts of the can get very hot during use. Keep children and others who need supervision at a safe distance. ● The pizza oven is intended for outdoor use only in well-ventilated areas. ● Leak tests (see page 14) must always be carried out before the pizza oven is used and when replacing the gas cylinder. -
Page 6: Technical Data
TECHNICAL DATA 逆时针旋出盖帽，装一节 Total Heat input: 7.6kW (Main burner input: 4.2 kW / Infrared burner: 3.4 kW) 注意：产品装电池时要把内部的披萨石与转盘先取下来 Gas consumption: 553 g/h (Main burner: 306 g/h. Infrared burner: 247 g/h) Gas cylinder (not included): Use standard cylinder approved for use in the Nordic Region. Even though butane and propane gas can be used, we recommend propane for use in the Nordic Region. -
Page 7: Read Before Assembly
If the appliance is damaged during transport, do not start using it before contacting your dealer or support@fccproducts.no. Transport damage to parts, varnish or pizza stone must be reported to the dealer or FCC Products before using the appliance. If damage is reported after, there is a possibility that damage may have occurred during incorrect use. -
Page 8: Parts List
PARTS LIST Code Description 1 pc Pizza Stone Rotation Tray 1 pc Hose Connector 1 pc Pizza Oven Body 1 pc 2 pcs DC Motor 1 pc Control Knob 1 pc M6x15 screw 12 pcs Screwdriver 1 pc Pizza Maestro... -
Page 9: Exploded Drawing
EXPLODED DRAWING 配件明细表 螺丝明细表 编号 名称 数量 编号 名称 数量 披萨石 M6*15螺丝 转盘 螺丝刀 软管接头 披萨炉主体 支撑脚 马达... -
Page 10: Assembly Instructions
ASSEMBLY Place a piece of cardboard on the floor (e.g the outer carton) to prevent scratching the unit and parts during assembly. Before assembly, make sure all parts are present. If any part is missing or damaged, do not attempt to assemble the appliance. Contact customer service for replacement parts. Insert the control knob STEP:1 assembly, part 7. - Page 11 ASSEMBLY STEP:2 Attach the legs (5) onto the oven body, lock them with 8 pcs of M6x15 screws (A). Turn the pizza oven back to right side up, and STEP:3 open the lid. Insert the rotation tray (2) into the hole, put the pizza stone (1) onto the rotation tray.
- Page 12 ASSEMBLY The assembly is completed, but the pizza oven requires batteries to be fully assembled and ready for use. 电池安装示意图 INSTRUCTION FOR BATTERY INSTALLMENT: 1) Open the cap of the DC motor box, put 打开盖板装两节1号电池 2 pcs of D battery (not supplied) and close it. 逆时针旋出盖帽，装一节5号电...
-
Page 13: Connecting Gas
CONNECTING GAS FOLLOW THESE INSTRUCTIONS CAREFULLY TO AVOID SERIOUS DAMAGE TO THE PIZZA OVEN AND CAUSE PERSONAL INJURY. HOSE REGULATOR • Connect the gas hose to the gas inlet on • Check that all controls on the control the pizza oven. Tighten well. panel are in the OFF position before connecting the regulator to the gas •... -
Page 14: Gas Leak Test
If detected leakage cannot be rectified, do not attempt to cure leakage but consult your dealer or FCC Products at support@fccproducts.no for help in solving the problem. Leak test must be done regularly and every time the gas cylinder, regulator or hose is replaced. -
Page 15: User Instructions
150 cm • Do not use under a roof or canopy. • Pizza Maestro will work best when sheltered from the wind. • Plastic or glass table tops are unsuitable surfaces to stand the oven on when in use. •... -
Page 16: Manual Lighting
LIGHTING INSTRUCTIONS NEVER PUT YOUR FACE CLOSE TO THE OVEN WHILE LIGHTING! GAS INSIDE CAN IGNITE, CAUSING BURNS TO SKIN, HAIR AND CLOTHES. PRIOR TO LIGHTING THE PIZZA OVEN • Check that a gas leak test has been performed. • Remove all packaging and other foreign articles. -
Page 17: Pizza Stone
Regulators and gas hoses are sold separately and must comply with national regulations. • We recommend the use of FCC original covers for the best possible protection against rain, pollen and pollution. Remember that the oven must be completely dry and cold before applying the cover. -
Page 18: Plastic Parts
MAINTENANCE CLEANING • All cleaning and maintenance must be done when the oven is completely cold. • Check that the gas is turned off, and the regulator disconnected from the gas bottle. • Use a mixture of washing up liquid and water, or use a suitable grill cleaner with a nylon scrubbing brush/scouring sponge to clean the outside. -
Page 19: Final Check
FINAL CHECK PLACEMENT OF THE PIZZA OVEN • Ensure that the oven is placed at least 150 cm in all directions from house walls, trees, plants and other flammable materials or liquids when in use. • Do not place the oven under a roof or overhang. •... -
Page 20: Troubleshooting
TROUBLESHOOTING PROBLEM POSSIBLE CAUSE PREVENTION/SOLUTION 1. Check to see if propane tank is empty 1. No gas flow 2. Turn the coupling nut about one-half 2. Coupling nut and regu- to three quarters additional turn until lator not fully connected solid stop. -
Page 22: Warranty Claim
Scan code to reach Consumer contact: Always attach your receipt and product serial number when making a warranty claim. PRODUCED IN CHINA FOR FCC PRODUCTS. We are always looking for ways we can improve our products. Therefore, we reserve the right to change technical specifications at any time.
