- Page 1 ORIGINAL INSTRUCTIONS>EN CORDLESS GRASS TRIMMER EZ20VCB USER GUIDE CAUTION: Read this manual before using this machine!
- Page 2 ©2022 Energizer. Energizer and certain graphic designs are trademarks of Energizer Brands, LLC and related subsidiaries and are used under license by Builder SAS. All other brand names are trademarks of their respective owners. Neither Builder SAS nor Energizer Brands, LLC is affiliated with the respective owners of their trademarks.
- Page 3 Let’s get started. You’re excited to power up, so we’ll keep this brief!
-
Page 4: Table Of Contents
CONTENTS 1. SAFETY INSTRUCTIONS........................5 2. YOUR PRODUCT..........................14 3. ASSEMBLY............................16 4. OPERATION............................20 5. MAINTENANCE AND STORAGE..................... 21 6. DISPOSAL............................. 21 7. DECLARATION OF CONFORMITY ....................22 8. WARRANTY............................23 9. PRODUCT FAILURE........................... 24 10. WARRANTY EXCLUSIONS......................25... -
Page 5: Safety Informations
1. SAFETY INFORMATIONS WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term "power tool" in the warnings refers to your mains-operated (corded) power tool or battery- operated (cordless) power tool. - Page 6 conditions. Water entering a power tool will increase the risk of electric shock. d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep cord away from heat, oil, sharp edges or moving parts.
- Page 7 energizing power tools that have the switch on invites accidents. d) Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury.
- Page 8 d) Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool. Power tools are dangerous in the hands of untrained users. e) Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and any other condition that may affect the power tool’s operation.
- Page 9 make a connection from one terminal to another. Shorting the battery terminals together may cause burns or a fire. d) Under abusive conditions, liquid may be ejected from battery; avoid contact. contact accidentally occurs, flush with water. If liquid contacts eyes, additionally seek medical help. Liquid ejected from the battery may cause irritation or burns.
- Page 10 Warning! never allow children, persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge or people unfamiliar with these instructions to use the machine. Avoid using the trimmer while people, especially children, infirm people or pets, are nearby. ...
- Page 11 on walls or rocks. Do not switch on the machine in enclosed or poorly ventilated spaces or in the presence of inflammable and /or explosive substances such as liquid, gases and powders. Always stop the trimmer and remove the battery when cutting is delayed or when walking from one cutting location to another.
- Page 12 Warning! Do not touch moving hazardous parts before the machine is disconnected from the mains. The moving hazardous parts have come to a complete stop. Avoid using the machine in bad weather conditions especially when there is a risk of lightning. ...
- Page 13 Residual risks • Cuts from the blade • Inhalation of particles of material to be cut • Projection of the parts of the cutting blades • Contact with uncovered cutting head (wounds, cuts) • Contact with tool in operation (injuries, cuts) •...
-
Page 14: Your Product
2. YOUR PRODUCT 2.1 Description... - Page 15 1. ON/OFF trigger lock-out button 7. Single line cutting spool 2. Battery port 8. Line cutting blade adjustment dial 3. ON/OFF trigger 9. Guide 4. Assist handle locking lever 10. Shaft length adjuster lock 5. Edger adjustment button 11. Shaft angle adjuster lock 6.
-
Page 16: Assembly
3. ASSEMBLY NOTE: Supplied without battery or charger. - Page 17 a. Charging (Charger and battery not included in this model) 1) Take the battery pack out of the equipment. Do this by pressing the push lock button. 2) Check that your mains voltage is the same as that marked on the rating plate of the battery charger.
- Page 18 Whether there is good contact at the charging contacts. Whether the battery pack is warm or not. The battery protection system will not allow the battery to be charged if the battery temperature is over 40℃ after use. Allow the battery pack to cool to room temperature before commencing with the charging.
- Page 19 b. ATTACHING THE GUARD Remove the battery pack. Invert the grass trimmer/edger to access the trimmer head. Remove the pre-installed screw from the trimmer head. Place the guard on to the trimmer head so that the large part of the guard sits to the rear (Fig.3). Align the screw hole on the guard with the screw hole on the trimmer head.
-
Page 20: Operation
j. REMOVING THE BATTERY PACK Locate the battery release catch on the top of the battery and press downwards (Fig.13). Whilst holding down the battery release catch slide the battery pack away from the tool. 4. OPERATION To avoid injury: Do not squeeze the trigger while the grass trimmer/edger is inverted. -
Page 21: Maintenance And Storage
5. MAINTENANCE AND STORAGE Warning! To prevent accidental starting that could cause serious personal injury; always remove the battery pack from the product before adjusting, inspecting, or cleaning. Never disassemble the tool or carry out any repairs. Always have the trimmer and charger maintained or repaired by a competent person at an authorized service centre. -
Page 22: Declaration Of Conformity
BUILDER SAS 32 rue Aristide Bergès - Z.I. du Casque - 31270 Cugnaux - France Declares that the machine: Designation: CORDLESS GRASS TRIMMER EZ20VCB Serial number: 20221109158-20221109557 Is in conformity with the European Directives: Machine Directive 2006/42/EC EMC Directive 2014/30/EU RoHS Directive 2011/65/EU+2015/863/EU Noise directive 2000/14/EC + Annex VI &... -
Page 23: Warranty
8. WARRANTY WARRANTY The manufacturer guarantees the product against defects in material and workmanship for a period of 2 years from the date of the original purchase. The warranty only applies if the product is for household use. The warranty does not cover breakdowns due to normal wear and tear. The manufacturer agrees to replace parts identified as defective by the designated distributor. -
Page 24: Product Failure
9. PRODUCT FAILURE WHAT TO DO IF MY MACHINE BREAKS DOWN? If you bought your product in a store: a) Empty the fuel tank if your product has one. b) Make sure that your machine is complete with all accessories supplied, and clean! If this is not the case, the repairer will refuse the machine. -
Page 25: Warranty Exclusions
10. WARRANTY EXCLUSIONS THE WARRANTY DOES NOT COVER: • Start-up and setting up of the product. • Damage resulting from normal wear and tear of the product. • Damage resulting from improper use of the product. • Damage resulting from assembly or start-up not in accordance with the user manual. •... - Page 26 NOTES...
- Page 27 NOTES...
