GPIB and RS-232-C The CH (Channel) command sets the parameters of a specified channel.
Commands and CH {L|C]R}{1/2} <link>:<argument>
Syntax
Table 2-1 and Table 2-2 list the links and arguments of the CH command.
Link Argument Argument Ranges
BWHi: <NRX> HF Limit (when queried)
11301, 11301A Oscilloscope: 400E+6
11302, 11302A Oscilloscope: 500E+6
Coupling: AC | DC | OFF
IMiPedance: <NRx> 50
OPFSet:! <NRx> Voits/div Offset Range Resolution
10 mv #250 mv 250E~6V
20 mv £500 mv 500E-6V
50 mv 1.25 V 1.25E-3V
100 mV t2.5V 2.5E-3V
200 mv ob V 5.0E-3V
500 mV H12.5V 12.5E~3V
iv 25 V 25E-3V
Resolution is for GPIB, RS-232-C, or numeric
SENsitivity: <NRx> 10E-3, 20E-3, 50E-3, 100E-3, 200E-3,
The numbers listed are those available at
the input connectors. Connecting an atte-
nuating probe will change the value pro-
portional to the probe's attenuation factor.
Query-only Link Response Meaning
? PRObe <qstring> Returns a description of the probe con-
nected to the channel. For a Level 1
TEKPROBE, the query returns "Level 1."
For a Level 2 TEKPROBE, the query re-
turns "Level2/ <probe_type>/ <serial
_nhumber> ." When no TEKPROBE is con-
nected, the query returns "NONE."
? UNIis <qstring> Returns the units of conversion of a probe
connected to the specified channel input.
11A72 User Reference Supplement . 23
