- Page 1 BPE742380B User Manual Oven BPK742380B BPK742380M USER MANUAL...
-
Page 2: Table Of Contents
FOR PERFECT RESULTS Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler – features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it. -
Page 3: Safety Information
SAFETY INFORMATION 9.2 Function lock........20 12.2 How to manage: Error codes..30 9.3 Automatic switch-off.......21 12.3 Service data.........31 9.4 Cooling fan........21 13. ENERGY EFFICIENCY......31 10. HINTS AND TIPS........22 13.1 Product Information and Product 10.1 Cooking recommendations..22 Information Sheet according to EU 10.2 Moist Fan Baking...... -
Page 4: General Safety
SAFETY INFORMATION Children should be supervised to ensure that they do not • play with the appliance. Keep all packaging away from children and dispose of it • appropriately. WARNING: The appliance and its accessible parts become • hot during use. Keep children and pets away from the appliance when in use and when cooling down. -
Page 5: Safety Instructions
SAFETY INSTRUCTIONS Always use oven gloves to remove or insert accessories or • ovenware. Use only the food sensor (core temperature sensor) • recommended for this appliance. To remove the shelf supports first pull the front of the shelf • support and then the rear end away from the side walls. -
Page 6: Electrical Connection
SAFETY INSTRUCTIONS Height of the back of the appliance 576 mm Width of the front of the appliance 595 mm Width of the back of the appliance 559 mm Depth of the appliance 567 mm Built in depth of the appliance 546 mm Depth with open door 1027 mm... -
Page 7: Use
SAFETY INSTRUCTIONS • This appliance is supplied with a main plug and a main cable. 2.3 Use WARNING! Risk of injury, burns and electric shock or explosion. • Do not change the specification of this appliance. • Make sure that the ventilation openings are not blocked. •... -
Page 8: Pyrolytic Cleaning
SAFETY INSTRUCTIONS • Be careful when you remove the door from the appliance. The door is heavy! • Clean regularly the appliance to prevent the deterioration of the surface material. • Clean the appliance with a moist soft cloth. Use only neutral detergents. Do not use abrasive products, abrasive cleaning pads, solvents or metal objects. -
Page 9: Disposal
PRODUCT DESCRIPTION 2.8 Disposal WARNING! Risk of injury or suffocation. • Contact your municipal authority for information on how to dispose of the appliance. • Disconnect the appliance from the mains supply. • Cut off the mains electrical cable close to the appliance and dispose of it. •... -
Page 10: Control Panel
CONTROL PANEL Grill- / Roasting pan To bake and roast or as a pan to collect fat. Food sensor To measure the temperature inside food. Telescopic runners For inserting and removing trays and wireshelf more easily. 4. CONTROL PANEL 4.1 Control panel overview ON / OFF Press and hold to turn the appliance on and off. -
Page 11: Display
CONTROL PANEL Lamp switch To turn the lamp on and off. Fast Heat Up To turn on and off the function: Fast Heat Up. Press Move Press and hold Touch the surface with finger‐ Slide fingertip over the sur‐ Touch the surface for 3 sec‐ tip. -
Page 12: Before First Use
BEFORE FIRST USE 5. BEFORE FIRST USE WARNING! Refer to Safety chapters. 5.1 Initial Cleaning Step 1 Step 2 Step 3 Clean the appliance and the Remove all accessories and Place the accessories and the accessories only with a micro‐ removable shelf supports from removable shelf supports in fibre cloth, warm water and a... -
Page 13: How To Set: Heating Functions
DAILY USE 6.1 How to set: Heating functions Step 1 Turn on the oven. The display shows the default heating function. Step 2 Press the symbol of the heating function to enter the submenu. Step 3 Select the heating function and press: . - Page 14 DAILY USE STANDARD Heating function Application To grill thin pieces of food and to toast bread. Grill To roast large meat joints or poultry with bones on one shelf position. To make gratins and to brown. Turbo Grilling To bake on up to three shelf positions at the same time and to dry food. Set the temperature 20 - 40 °C lower than for Conventional Cooking.
-
Page 15: Notes On: Moist Fan Baking
DAILY USE SPECIALS Heating function Application To preserve vegetables (e.g., pickles). Preserving To dry sliced fruit, vegetables and mushrooms. Dehydrating To preheat plates for serving. Plate Warming To defrost food (vegetables and fruit). The defrosting time depends on the amount and size of the frozen food. Defrost For dishes such as lasagna or potato gratin. -
Page 16: Clock Functions
CLOCK FUNCTIONS 7. CLOCK FUNCTIONS 7.1 Clock functions description Clock function Application Cooking time To set the length of cooking. Maximum is 23 h 59 min. End action To set what happens when the timer ends counting. Delayed start To postpone the start and / or end of cooking. Time extension To extend cooking time. - Page 17 CLOCK FUNCTIONS How to choose end option Step 2 Press: Step 3 Set the cooking time. Step 4 Press: Step 5 Press: End action. Step 6 Choose the preferred: End action. Step 7 Press: . Repeat the action until the display shows the main screen. How to delay start of cooking Step 1 Set the heating function and the temperature.
-
Page 18: Using The Accessories
USING THE ACCESSORIES How to change timer settings Step 2 Set the timer value. Step 3 Press: You can change the set time during cooking at any time. 8. USING THE ACCESSORIES WARNING! Refer to Safety chapters. 8.1 Inserting accessories A small indentation at the top increases safety. -
Page 19: How To Use: Food Sensor
USING THE ACCESSORIES There are two temperatures to be set: The oven temperature: minimum 120 °C. The core temperature. For the best cooking results: Ingredients should be at Do not use it for liquid During cooking it must remain in room temperature. -
Page 20: Additional Functions
ADDITIONAL FUNCTIONS Step 5 - press to set the core temperature of the sensor. Step 6 - press to set the preferred option: • Sound alarm - when food reaches the core temperature, the signal sounds. • Sound alarm and stop cooking - when food reaches the core temperature, the sig‐ nal sounds and the oven stops. -
Page 21: Automatic Switch-Off
ADDITIONAL FUNCTIONS Step 1 Turn on the appliance. Step 2 Set a heating function. Step 3 - press at the same time to turn on the function. To turn off the function repeat step 3. 9.3 Automatic switch-off For safety reasons the appliance turns off after some time, if a heating function works and you do not change any settings. -
Page 22: Hints And Tips
HINTS AND TIPS 10. HINTS AND TIPS 10.1 Cooking recommendations The temperature and cooking times in the tables are guidelines only. They depend on the recipes and the quality and quantity of the ingredients used. Your appliance may bake or roast differently to the appliance you had before. The hints below show recommended settings for temperature, cooking time and shelf position for specific types of the food. -
Page 23: Moist Fan Baking - Recommended Accessories
HINTS AND TIPS 10.3 Moist Fan Baking - recommended accessories Use the dark and non-reflective tins and containers. They have better heat absorption than the light colour and reflective dishes. Ramekins Pizza pan Baking dish Flan base tin Ceramic Dark, non-reflective Dark, non-reflective Dark, non-reflective 8 cm diameter,... -
Page 24: Care And Cleaning
CARE AND CLEANING °C Small cakes, 20 per tray, True Fan Cooking 20 - 30 preheat the empty oven Small cakes, 20 per tray, Conventional Cooking 20 - 30 preheat the empty oven Multilevel baking - biscuits °C Short bread True Fan Cooking 25 - 45 2 / 4... -
Page 25: Notes On Cleaning
CARE AND CLEANING 11.1 Notes on cleaning Clean the front of the appliance only with a microfibre cloth with warm water and a mild detergent. Use a cleaning solution to clean metal surfaces. Cleaning Clean stains with a mild detergent. Agents Clean the cavity after each use. -
Page 26: How To Use: Pyrolytic Cleaning
CARE AND CLEANING 11.3 How to use: Pyrolytic Cleaning Clean the oven with Pyrolytic Cleaning. WARNING! There is a risk of burns. CAUTION! If there are other appliances installed in the same cabinet, do not use them at the same time as this function. It can cause damage to the oven. Before the Pyrolytic Cleaning: Turn off the oven and wait Remove all accessories and... -
Page 27: How To Remove And Install: Door
CARE AND CLEANING Use the function: Pyrolytic Cleaning. 11.5 How to remove and install: Door You can remove the door and the internal glass panels to clean it. The number of glass panels is different for different models. WARNING! The door is heavy. CAUTION! Carefully handle the glass, especially around the edges of the front panel. -
Page 28: How To Replace: Lamp
CARE AND CLEANING Step 7 Clean the glass panel with water and soap. Dry the glass panel carefully. Do not clean the glass panels in the dish‐ washer. Step 8 After cleaning, do the above steps in the opposite se‐ quence. -
Page 29: Troubleshooting
TROUBLESHOOTING Side lamp Step 1 Remove the left shelf support to get access to the lamp. Step 2 Use a narrow, blunt object (e.g. a teaspoon) to remove the glass cov‐ Step 3 Clean the glass cover. Step 4 Replace the lamp with a suitable 300 °C heat-resistant lamp. -
Page 30: How To Manage: Error Codes
TROUBLESHOOTING The appliance does not turn on or does not heat up Possible cause Remedy The appliance Child Lock is on. Refer to "Menu" chapter, Submenu for: Op‐ tions. Components Description Remedy The lamp is burnt out. Replace the lamp, for details refer to "Care and Cleaning"... -
Page 31: Service Data
......... Serial number (S.N.) ......... 13. ENERGY EFFICIENCY 13.1 Product Information and Product Information Sheet according to EU Ecodesign and Energy Labelling Regulations Supplier's name BPE742380B 944188678 Model identification BPK742380B 944188672 BPK742380M 944188679 Energy Efficiency Index 61.2 Energy efficiency class Energy consumption with a standard load, conventional 1.09 kWh/cycle... -
Page 32: Energy Saving
ENERGY EFFICIENCY BPE742380B 35.0 kg Mass BPK742380B 36.0 kg BPK742380M 35.5 kg IEC/EN 60350-1 - Household electric cooking appliances - Part 1: Ranges, ovens, steam ovens and grills - Methods for measuring performance. 13.2 Energy saving The appliance has features which help you save energy during everyday cooking. -
Page 33: Menu Structure
MENU STRUCTURE 14. MENU STRUCTURE 14.1 Menu Menu item Application Assisted Cooking Lists automatic programmes. Cleaning Lists cleaning programmes. Favourites Lists the favourite settings. Options To set the appliance configuration. Settings Setup To set the appliance configuration. Service Shows the software version and con‐ figuration. -
Page 34: Submenu For: Setup
MENU STRUCTURE Submenu Application Child Lock Prevents accidental activation of the appliance. When the option is on, the text Child Lock appears in the display when you turn on the appli‐ ance. To enable the appliance use, choose the code letters in the al‐ phabetical order. -
Page 35: S Easy
IT'S EASY! Submenu Description Reset all settings Restores factory settings. 15. IT'S EASY! Before first use you have to set: Display bright‐ Language Key tones Buzzer volume Time of day ness Familiarize yourself with the basic icons on the control panel and the display: ON / OFF Menu Favourites... -
Page 36: Environmental Concerns
IT'S EASY! Get to know how to cook quickly Use the automatic programmes to prepare a dish quickly with the default settings: Assisted Step 1 Step 2 Step 3 Step 4 Cooking Choose the dish. Press: Press: Press: As‐ sisted Cooking. Use quick functions to set the cooking time 10% Finish assist To extend the cooking time press +1min. - Page 40 www.aeg.com/shop...
