aquabrass XPRK01 Installation Manual

Round shower kit

Advertisement

# XPRK01 - # XPRK02
Round shower kit
Kit de douche rond
Installation Guide
Guide d'installation
Optional / Optionnel
(#XPRK02)
Last revision: 08/23/2024
1
aquabrassxpress.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XPRK01 and is the answer not in the manual?

Questions and answers

Summary of Contents for aquabrass XPRK01

  • Page 1 # XPRK01 - # XPRK02 Round shower kit Kit de douche rond Installation Guide Guide d’installation Optional / Optionnel (#XPRK02) Last revision: 08/23/2024 aquabrassxpress.com...
  • Page 2 # XPRK01 - # XPRK02 Round shower kit Kit de douche rond General Dimensions / Dimensions générales 1 7/16” [36mm] 1/8” ø 7 7/8” [200mm] [3mm] 3 15/16” [100mm] 2 7/8” [73mm] 14 9/16” [371mm] ø 7/8” 3/8” [10mm] [22mm] ø...
  • Page 3 # XPRK01 - # XPRK02 Round shower kit Kit de douche rond General Dimensions / Dimensions générales ø 9 1/2” [241mm] 2 3/16” [55mm] 2” [50mm] ø 2” 1/4” [6mm] [50mm] 1-1/2” [38mm] Last revision: 08/23/2024 aquabrassxpress.com...
  • Page 4 # XPRK01 - # XPRK02 Round shower kit Kit de douche rond General Dimensions / Dimensions générales 7/16” 2” [11mm] [50mm] ø 4 3/4” 2 3/16” [55mm] [120mm] 3/4” [19mm] 27 9/16” 10” [700mm] [254mm] 5’ 1/2” connection 1/2” connection aquabrassxpress.com...
  • Page 5 # XPRK01 - # XPRK02 Round shower kit Kit de douche rond General Dimensions / Dimensions générales 1-1/8” [28mm] 7-7/16” [190mm] ø 2-3/4” [70mm] 2-3/16” [55mm] 6-13/16” [173mm] Last revision: 08/23/2024 aquabrassxpress.com...
  • Page 6 # XPRK01 - # XPRK02 Round shower kit Kit de douche rond #XPR795 Trim set / Ensemble décoratif aquabrassxpress.com Last revision: 08/23/2024...
  • Page 7 # XPRK01 - # XPRK02 Round shower kit Kit de douche rond Service parts / Schéma des pièces Item Code English Français Item Code English Français ABSPXP603 Adapter Adaptateur ABSTXP850 Round trim plate Plaque ronde Foam gasket Joint mousse Screw...
  • Page 8: Installation

    # XPRK01 - # XPRK02 Round shower kit Kit de douche rond Installation Close / Fermer Open / Ouvrir aquabrassxpress.com Last revision: 08/23/2024...
  • Page 9 # XPRK01 - # XPRK02 Round shower kit Kit de douche rond Water temperature adjustment / Réglage de la température de l’eau 100°F 38 °C Temperature limit stopper Limitateur de température The highest temperature setting has been factory preset at 120˚F (49˚C). However, the preset temperature can be adjusted by following these steps: Remove the lever (1) and the volume control handle (2).
  • Page 10: Maintenance / Entretien

    # XPRK01 - # XPRK02 Round shower kit Kit de douche rond Maintenance / Entretien To service the cartridges: Shut-off the main water supply, then remove all the components from (7) to (21). Afterwards, shut-off the 2 check valves (1) by turning them clockwise with a screwdriver. Unscrew the screw (3), the large nuts (5 &...
  • Page 11 # XPRK01 - # XPRK02 Round shower kit Kit de douche rond #XPR61 Round shower arm / Bras de douche rond ½" NPT male connection Raccordement ½" mâle NPT Last revision: 08/23/2024 aquabrassxpress.com...
  • Page 12 # XPRK01 - # XPRK02 Round shower kit Kit de douche rond #XPR63 4” round ceiling drop / Bras de plafond rond de 4” NPT ½ " Max. 3" NPT ½ " aquabrassxpress.com Last revision: 08/23/2024...
  • Page 13 # XPRK01 - # XPRK02 Round shower kit Kit de douche rond #XP148 10” round rainhead / Tête de pluie ronde de 10” Shower arm / Bras de douche ceiling drop / Bras de plafond Last revision: 08/23/2024 aquabrassxpress.com...
  • Page 14 # XPRK01 - # XPRK02 Round shower kit Kit de douche rond #XPR86 Round shower rail / Rail de douche rond Drill / Trou 3/4” Drill / Trou Drill / Trou 23 3/4” [603mm] Drill / Trou aquabrassxpress.com Last revision: 08/23/2024...
  • Page 15 # XPRK01 - # XPRK02 Round shower kit Kit de douche rond #XP501 Round waterway / Sortie murale ronde FINISHED WALL MUR FINI 1/2” NPT EXTENSION FITTING (NOT INCLUDED) EXTENSION 1/2” NPT (NON INCLUSE) 1/2” MAX. Min. 1” Max 1-1/2“...
  • Page 16 # XPRK01 - # XPRK02 Round shower kit Kit de douche rond #XPR32 Tub spout / Bec de bain 1/2” copper pipe Tuyau de cuivre 1/2” aquabrassxpress.com Last revision: 08/23/2024...
  • Page 17 # XPRK01 - # XPRK02 Round shower kit Kit de douche rond Configuration examples / Exemples de configurations Configuration 2 Configuration 1 4” CEILING ARM & RAIL OVERSIZED SHOWER WITH 15” SHOWER ARM & RAIL BRAS DE PLAFOND DE 4” ET RAIL DOUCHE SURDIMENTIONNÉE AVEC BRAS DE DOUCHE DE 15”...
  • Page 18: Cleaning And Maintenance

    # XPRK01 - # XPRK02 Round shower kit Kit de douche rond Cleaning and Maintenance Entretien et Nettoyage aquabrassxpress.com Last revision: 08/23/2024...
  • Page 19: Warranty

    The warranty applies only when the product is purchased from an authorized Aquabrass XPress dealer. It is not transferable and is limited to products sold and installed in Canada and the United States.
  • Page 20: Garantie

    Aux fins de la présente garantie, le terme « application résidentielle multifamiliale » désigne un produit Aquabrass XPress obtenu auprès d’un vendeur Aquabrass XPress autorisé; par un acheteur qui possède mais ne vit pas dans le logement résidentiel où le produit est initialement installé...
  • Page 21 # XPRK01 - # XPRK02 Round shower kit Kit de douche rond About / Informations complémentaires CARE & MAINTENANCE Do not allow water residues to come into prolonged contact with the surface finish. After each use, gently dry the product surface with a clean soft cloth to prevent water-spotting and mineral build-up.
