Summary of Contents for Poly Voyager Free 60+ M
- Page 1 Poly Voyager Free 60+ UC True Wireless Earbuds with Touchscreen Charge Case User Guide SUMMARY This guide provides the end-user with task-based user information for the featured product.
- Page 2 Legal information Copyright and license © 2024, HP Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty.
-
Page 3: Table Of Contents
Table of contents Your earbud system Charge case controls Earbud button controls Earbud swipe sensor controls USB Bluetooth adapter Load software Update your Poly device Replace eartips Charge Check battery level Quick charge Wireless charging (Qi charging) Power First time power... - Page 4 Use sensors ANC and Transparency Mode Launch Microsoft Teams (Teams model only) Make/Take/End Calls Make a call Answer or end a call Mute Answer a second call Redial last outgoing call (smartphone feature) Answer calls from a second device More Features Customize your earbud swipe settings Lock your charge case screen Bluetooth transmitter...
-
Page 5: Your Earbud System
Your earbud system Your earbud system easily connects to your mobile phone and computer. The system includes: ● Wireless earbuds with wearing sensors ● USB Bluetooth adapter for connection to high-fidelity computer audio (design varies by model) ● Charge case with touchscreen controls Your earbud system... -
Page 6: Charge Case Controls
Charge case controls Control features and settings using your charge case touchscreen. Swipe left and right to view navigation menus and tap icons to select menus and control features. Tap X to close a menu. ANC / Transparency Touch screen controls Battery level Music and streaming audio* ANC (Active Noise Canceling) and Transparency Mode... -
Page 7: Earbud Button Controls
Earbud button controls Press an earbud button to control features on your earbud system. To press the raised button on the back of your earbud, pinch the earbud with your thumb and forefinger. Control features using either earbud's button. NOTE: Do not press the buttons on both earbuds at the same time. -
Page 8: Earbud Swipe Sensor Controls
Earbud swipe sensor controls Swipe forward or backward on the earbud swipe sensor to control features on your earbud system. The swipe sensor is next to metallic windscreen on the top of each earbud stem. Swipe forward or backward to adjust levels or make changes. Control by swiping either earbud. -
Page 9: Usb Bluetooth Adapter
USB Bluetooth adapter Your high-fidelity Bluetooth USB adapter comes pre-paired to your Poly device. Plug it into your computer to connect to high-fidelity computer audio. NOTE: Adapter's USB connection and design may vary, but function is the same. Standard LEDs... -
Page 10: Load Software
Load software Download Poly Lens App to get the most out of your device. Some softphones require the installation of Poly software to enable device call control(answer/end and mute) functionality. NOTE: Administrative privileges may be required to download the desktop application. - Page 11 With Poly Lens Desktop App downloaded, plug the charge case into your computer using the provided USB cable. Select your charge case from the device list in Poly Lens Desktop App to view available updates. Click the update button to update charge case firmware or software.
-
Page 12: Fit
Try the 3 eartips to find which size fits you comfortably while blocking external noise. Listen to music and select the eartip that gives you the most bass response. You may prefer a different size eartip in each ear. Replace eartips Change your eartips and lock them in place. -
Page 13: Charge
Charge To charge your earbuds, place them in the charge case. Your earbuds begin charging when placed in the case. To recharge the case, plug it into a computer or USB charging device using the supplied USB cable. Alternatively, recharge using a third-party wireless charger (not included). -
Page 14: Quick Charge
● View earbud and charge case battery level in Poly Lens App . Download at hp.com/lens-app Voice alert Charge case battery menu Talk time indicator "Battery high" Green (more than 70%) 3 hours or more "Battery medium" Green(40-70%) 1 to 3 hours "Battery low"... -
Page 15: Power
Power First time power Your charge case is shipped from the factory in a Deepsleep mode to conserve the battery. ■ On first use, wake your case by pressing the button on the back of the charge case or by plugging into a power source using the provided charge cable. Power on/off your earbud system Your earbuds and case power on and off automatically. -
Page 16: Wake Your Charge Case
Wake your charge case Wake your screen to use features or to view status. Your charge case touch screen times out when idle for 15-45 seconds in most cases. Wake your screen by doing one of the following: ● Tap the touch screen. ●... -
Page 17: Connect And Pair
Settings > Bluetooth > On* ● Android Bluetooth: On > Scan for devices* ● NOTE: * Menus may vary by device. Select " Poly VFree 60 Series." When your earbuds are successfully paired, you hear “pairing successful” and "phone connected." Connect and pair... -
Page 18: Reconnect
Pair to PC with Bluetooth direct Quickly pair to your PC with Bluetooth direct PC pairing and Poly Lens Desktop App . Poly Lens Desktop App improves softphone call control and call quality. This feature requires Poly Lens Desktop App 2.0. Download the app at hp.com/... -
Page 19: Connect To Pc
Windows To configure your Bluetooth USB adapter for streaming media in your PC, go to Start menu > Control Panel > Sound > Playback tab. Select Poly BT700 set it as the Default Device and click OK. To pause music when you place or receive calls, go to Start menu > Control Panel >... -
Page 20: Pair Mode
Your USB adapter requires Poly Lens Desktop App to pair to a Poly audio device. Download: hp.com/lens-app NOTE: Adapter design varies by USB connection. Insert the high-fidelity Bluetooth USB adapter into your laptop or computer and wait for your computer to recognize it. - Page 21 ■ To switch your audio source using your charge case touch screen, go to Audio source > Switch Device and select from your remembered device list. Choose your audio source...
-
Page 22: The Basics
The basics Adjust the volume Choose: ● Adjust the Volume on your charge case touch screen. Each tap changes the volume one level. ● Adjust the volume on your connected mobile device or computer. ● When streaming media, swipe your earbud sensor to adjust the volume. Swipe forward for volume down or backward for volume up. -
Page 23: Voice Assistant (Smartphone Feature)
ANC Mode and your selected Transparency Mode. ● Poly Lens App : Go to Settings > ANC: Tap to view and select your ANC Mode or Transparency Mode. For more about these settings, see ANC and... - Page 24 ● When your connected Bluetooth USB adapter LED pulses purple, click your earbud button to view Teams notifications. ● To raise or lower your hand during a Teams meeting, press and hold your earbud button for 2seconds. NOTE: The purple multifunction button on the back of your earbud is also your Teams button.
-
Page 25: Make/Take/End Calls
Make/Take/End Calls Make a call ■ To make a call, dial using your computer softphone application or connected mobile device. Answer or end a call ■ To answer or end a call, do one of the following: ● Press once on the button on the back of your earbud. ●... -
Page 26: Redial Last Outgoing Call (Smartphone Feature)
Redial last outgoing call (smartphone feature) ■ Double-click your earbud button to redial the last outgoing mobile call. NOTE: Control with either earbud. Answer calls from a second device It's easy to answer calls from two devices. When on a call, you hear a ringtone notification of the incoming call from the second paired device. -
Page 27: More Features
Customize your earbud swipe sensor settings in Poly Lens App . Download the app: hp.com/lens-app By default, your earbud swipe controls vary by activity. To configure in Poly Lens App , go to Settings > Custom swipe sensor. Changes take effect immediately. Activity... -
Page 28: Bluetooth Transmitter
You hear "device disconnected." ANC and Transparency Mode settings Choose your preferred settings for ANC (Active Noise Canceling) and Transparency Mode. Choose settings in Poly Lens App or on your charge case touchscreen. Category Setting Description Adaptive (default) ●... -
Page 29: Connect New Earbud
Category Setting Description Transparency ● Transparency Mode powered Mode Connect new earbud Connecting a replacement new earbud to your existing system is easy. To connect your new earbud to the existing one, place them both in the charge case. Close the case lid and wait for 10 or more seconds to complete the connection. -
Page 30: Troubleshooting
Configure USB adapter for streaming media on page How do I pair my USB Bluetooth adapter to Poly Lens Desktop App is required to pair your USB another supported Poly audio device? Bluetooth adapter to another device. Your Bluetooth adapter remembers up to 2 supported Poly audio devices, but connects to only one at a time. -
Page 31: Audio
● Customize your earbud settings to control volume at all times. at all times in Poly Lens App . By default, swiping your earbud adjusts your volume only when streaming media and not during other activities. Customize your earbuds on page... -
Page 32: Calls
● To interact with Microsoft Teams, tap the earbud button (Teams-certified model). ● Set your target phone by going to Poly Lens Desktop App > Softphones > Software Settings > Target Softphone Does my Microsoft Teams-enabled earbud Yes, while your headset is optimized for Microsoft... - Page 33 Configure USB adapter for streaming media on page ● Customize or turn off your earbud wearing sensor settings in Poly Lens App . Download the app: hp.com/lens-app TIP: For best audio performance while exercising, turn off wearing sensors in Poly Lens App .
-
Page 34: Safety Warnings
Incorrect reassembly can cause electric shock or fire when the product is subsequently used. ● Unplug, discontinue use and contact Poly if the product overheats or has a damaged outer casing, cord or plug. ● Exposure to high volume sound levels or excessive sound pressure may cause temporary or permanent damage to your hearing. - Page 35 Contact your local recycling center for battery removal and proper disposal. ● Use only the charger supplied by Poly to charge the product and follow the charging instructions provided. Alternatively, if your headset is designed to be charged with your cell phone charger, use only cell phone chargers approved and provided by your cell phone manufacturer.
-
Page 36: Support
Support NEED MORE HELP? support.hp.com/poly HP Inc. 1501 Page Mill Road Palo Alto, CA 94304, U.S.A. 650-857-1501 HP REG 23010, 08028 Barcelona, Spain HP Inc UK Ltd Regulatory Enquiries, Earley West 300 Thames Valley Park Drive Reading, RG6 1PT United Kingdom 台灣惠普資訊科技股份有限公司...
