- Page 1 Operating and Installation Instructions Ventilation Hood To prevent accidents and damage to the appliance, you must read these instructions before installing the appliance and using it for the first time. en-US M.-Nr. 12 311 900...
-
Page 2: Table Of Contents
Description of functions ....................14 Before using for the first time..................15 Selecting extraction mode or recirculation mode............15 Setting up Miele@home ....................15 Performing Scan & Connect ................... 16 Signing out of WiFi (reset to factory settings) ............. 16 Setting up Con@ctivity .................... - Page 3 Contents OdorFree Charcoal Filter ....................30 Resetting the filter saturation indicator for the charcoal filters ......31 Disposing of charcoal filters..................31 Reactivatable charcoal filters .................. 31 Installation........................32 Before installation ......................32 Installation recommendations..................32 Installation materials...................... 32 Installation materials for recirculation mode ............33 Appliance dimensions....................
-
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS READ AND SAVE THESE INSTRUCTIONS This appliance complies with current safety requirements. Improper use of the appliance can lead to personal injury and material damage. Read all instructions before installing or using the appliance for the first time. Only use the appliance for its intended purpose. Keep these operating instructions in a safe place and pass them on to any future user. -
Page 5: Technical Safety
(e.g. parts made at home using a 3D printer). Installation, repair and maintenance work should be performed by a Miele authorized service technician in accordance with national and local safety regulations and the provided installation instructions. Contact Miele’s Technical Service Department for examination, repair or adjustment. - Page 6 IMPORTANT SAFETY INSTRUCTIONS To avoid damaging the ventilation hood, make sure that the connection data (voltage and frequency) on the data plate correspond to the building's power supply before connecting the appliance. If in doubt, consult a qualified electrician. Do not use a power bar or extension cord to connect the ...
-
Page 7: Correct Use
IMPORTANT SAFETY INSTRUCTIONS Correct use WARNING: TO REDUCE THE RISK OF A COOKTOP GREASE FIRE: - a) Never leave surface units unattended. Boilovers cause smoking and greasy spillovers may ignite. Heat oils slowly on low or medium settings. - b) Always turn the hood on when cooking at a high heat. - c) Clean the ventilation hood frequently. -
Page 8: Proper Installation
IMPORTANT SAFETY INSTRUCTIONS The ventilation hood may become damaged if exposed to excessive heat from a gas cooktop. - When using the ventilation hood over a gas cooktop, ensure that any burners in use are always covered by cookware. Turn burners off when removing the cookware, even if doing so for just a short time. - Page 9 When installing the exhaust duct, only use pipes or tubes made of non-flammable material. These can be obtained from your Miele dealer or from Miele Technical Service. Always observe local building code requirements when selecting duct material. Exhaust air should not be vented into a chimney or vent flue which ...
-
Page 10: Cleaning And Maintenance
The steam can reach the electrical components and cause a short circuit. Accessories and parts Use only genuine original Miele parts. If parts or accessories from other manufacturers are used, the warranty may become void. Defective components should be replaced by Miele original parts ... -
Page 11: Caring For The Environment
Consult with local authorities, dealers or Miele in order to dispose of and recycle electrical and electronic appliances. Miele assumes no responsibility for deleting any personal data left on the appliance being disposed. -
Page 12: Guide To The Ventilation Hood
Guide to the ventilation hood... - Page 13 Guide to the ventilation hood a Vent collar b Controls c Charcoal filters Optional accessories for recirculation mode d Grease filter e Pull-out canopy f Overhead lighting g Control for switching the lighting on and off and for dimming the lighting h Control for switching the blower on and off i Controls for setting the blower power j Control for the delayed shutdown function...
-
Page 14: Description Of Functions
Description of functions The following functions are available on Recirculation mode your ventilation hood, depending on the (only with conversion kit and charcoal model: filters as optional accessories, see “Technical data”) Extraction mode The air is drawn in and cleaned first by Air entering through the intake is the grease filter and then by charcoal cleaned by the grease filters and... -
Page 15: Before Using For The First Time
Miele app. filter(s) has to be deactivated. If your Miele cooktop is connected to a Switch off the blower and the lighting. home WiFi network, you can control the Press the control and the ventilation hood automatically via the operating-hours control ... -
Page 16: Performing Scan & Connect
Apple App ® Store or the Google Play Store™. Install the Miele app and set up a user Press and hold the control. account. Scan the QR code again. -
Page 17: Setting Up Con@Ctivity
Setting up Con@ctivity network (Con@ctivity 3.0) Con@ctivity is the direct communication system between an Prerequisite: induction Miele cooktop and a Miele - Home WiFi network ventilation hood. It enables the - WiFi-enabled Miele cooktop ventilation hood to operate automatically depending on the ... -
Page 18: Reattempting The Connection
Before using for the first time When successfully connected, 2 and 3 will light up constantly. Quit connection mode on the ventilation hood by pressing the delayed shutdown control . Con@ctivity has now been activated. With a direct WiFi connection, it is not possible to connect the cooktop and the ventilation hood to a home network. -
Page 19: Operation (Automatic Mode)
Operation (Automatic mode) Reaction time When Con@ctivity is active, the ventilation hood always operates in Changing the power setting on the automatic mode (see “Before using for cooktop does not lead to an immediate the first time – Setting up increase or decrease in cooking vapors. -
Page 20: Switching Off
Operation (Automatic mode) Activate the delayed shutdown Switching off function on the ventilation hood. Turn off all burners. The blower will switch itself off after the selected run-on time, and the Over the next few minutes, the lighting will remain on. -
Page 21: Operation (Manual Mode)
Operation (Manual mode) Reducing power down from the Cooking without Con@ctivity Booster setting (Manual mode) If power management is activated The ventilation hood can be operated (default setting), the blower manually if: automatically switches back to level 3 - The Con@ctivity function is not after 5 minutes. -
Page 22: Turning Off The Fan
Operation (Manual mode) Turning off the fan Power management Push in the canopy. The ventilation hood is equipped with a power management system. Power The next time the canopy is pulled out, management helps to save energy. It the fan will operate at power level 2 ensures that the blower power level is again. -
Page 23: Energy-Saving Tips
Energy-saving tips This hood operates in a very efficient - Use the Con@ctivity function. The and energy-saving manner. The ventilation hood will switch on and off following will help you to save even automatically. The ventilation hood more energy when using it: will select the optimum power level for the cooking you are doing, which - Ensure that there is sufficient... -
Page 24: Changing Settings
Changing settings Switch off the blower and the lighting. Adjusting the grease filter filter saturation indicator Press the delayed shutdown control and the filter saturation The filter saturation indicator can be set control at the same time. to suit the customer’s cooking habits. The grease filter symbol ... -
Page 25: Adjusting Or Deactivating The Filter Saturation Indicator For The Charcoal Filter
Changing settings Adjusting or deactivating the Deactivating power filter saturation indicator for the management charcoal filter Keep in mind that this may increase energy consumption. Charcoal filters are needed for recirculation mode. Activating/deactivating power The filter saturation indicator can be set management to suit the customer’s cooking habits. -
Page 26: Cleaning And Care
Unsuitable cleaning agents can treating them with a stainless steel care damage the surfaces and control product (available from Miele). elements. Important information for the controls Do not use any cleaning agents containing soda, acid, chloride, or If soiling is not removed promptly, it solvent. -
Page 27: Filter Saturation Indicator
Cleaning and care Filter saturation indicator Grease filter The ventilation hood registers the length Risk of fire of time it has been operated. An oversaturated grease filter is a fire Filter saturation indicators show when hazard. the filters need to be cleaned or Clean the grease filter at regular changed by lighting up the grease filter intervals. - Page 28 Cleaning and care Removing the grease filters Cleaning the grease filter in the dishwasher When handling the grease filter, Risk of damage due to be careful not to drop it. excessively high temperatures in the This can result in damage to the filter dishwasher.
- Page 29 Use a commonly available household prevent the risk of these catching fire. dishwashing detergent. In a Miele dishwasher use the “Normal” program. Depending on the detergent used, cleaning the filter in a dishwasher may cause the inside filter surfaces to become discolored.
-
Page 30: Replacing The Grease Filter
Charcoal filters are available to order via The grease filter symbol goes out. the Miele website or from your Miele dealer. When cleaning the grease filter before The charcoal filters are listed under the full operating time has elapsed: “Technical data”... -
Page 31: Resetting The Filter Saturation Indicator For The Charcoal Filters
Cleaning and care Installing/replacing the charcoal filters When to change the OdorFree Charcoal Filter The matching frames must be installed Replace the charcoal filters when they in order to use the charcoal filter. no longer absorb kitchen odors Follow the directions on the effectively, and at least every 6 months. -
Page 32: Installation
*INSTALLATION* Installation Before installation Installation materials Before installation, it is important to read the information contained in this chapter and in the “IMPORTANT 1 non-return flap SAFETY INSTRUCTIONS” chapter. for installation in the exhaust vent on the motor (not needed for recirculation mode) Information is subject to change. -
Page 33: Installation Materials For Recirculation Mode
*INSTALLATION* Installation 4 screws, M4 x 8 mm DML 2000 installation kit for installing a hinged front panel to match kitchen cabinetry (not supplied; available as an optional accessory) 5 (9)* screws, 4 x 15 mm Installation materials for recirculation mode You need the following optional 4 screws, 4 x 30 mm accessories for recirculation mode. -
Page 34: Appliance Dimensions
*INSTALLATION* Installation Appliance dimensions Diagram 1: DAS 4720 in a 23 5/8" (600 mm) wide cabinet. The drawing is not to scale. - Page 35 *INSTALLATION* Installation Diagram 2: DAS 4720 in a 30" (762 mm) wide cabinet DAS 4920 in a 35 7/16" (900 mm) wide cabinet The drawing is not to scale. See diagram 1 for side view.
- Page 36 *INSTALLATION* Installation Diagram 3: DAS 4920 in a 23 5/8" (600 mm) wide cabinet or in a 35 7/16" (900 mm) wide cabinet with side compartments The drawing is not to scale. See diagram 1 for side view. Footnotes for diagrams 1 to 3: a Vented or recirculation with DUU 150 conversion kit b DML 2000 bracket (accessory) for installing a front panel c Can be adjusted via depth stop * In this installation situation, the deflector plate is flush with the front edge of the...
-
Page 37: Distance Between Cooktop And Ventilation Hood (S)
Please also observe the information contained in the “IMPORTANT SAFETY INSTRUCTIONS” section. Minimum distance S Cooking appliance Miele Non-Miele appliance appliance Electric Cooktops 24" (610 mm) Electric Barbeques and Fryers 26"... -
Page 38: Installing The Depth Stop (Optional)
*INSTALLATION* Installation Installing the depth stop (optional) Insert the depth stops into the recesses of the deflector plate from behind. The lip on the depth stop faces backward. You can limit how far the deflector plate Install the ventilation hood. can be pushed in. - Page 39 *INSTALLATION* Installation Slide the covers back again. Drill a pilot hole 3/8" (10 mm) in front of the pen mark and screw the depth stop into place. Carefully push in the deflector plate as far as the required position. This will push the depth stops into the required position.
-
Page 40: Air Venting
If the exhaust is ducted through an - The diameter of the vent ducting must outside wall, a Miele wall vent or roof not be smaller than the cross-section vent (available as an optional accessory) of the vent collar (see “Appliance is recommended. -
Page 41: Condensate
*INSTALLATION* Installation Condensate Miele will not accept warranty claims for any functional defects or damage If the ducting is to run through cool caused by inadequate ducting. rooms or ceiling space, for example, the significant variations in temperature Reducing Collar between the different areas can cause condensate to form. -
Page 42: Electrical Connection
If there is any question concerning accordance with CSA C22.1-12, the electrical connection of this Canadian Electrical Code, Part I. appliance to your power supply, please consult a licensed electrician or call Miele’s Technical Service Department. WARNING: THIS APPLIANCE MUST BE GROUNDED... -
Page 43: Customer Service
In the event of a fault which you cannot remedy yourself, please contact your Miele dealer or Miele Customer Service. You can book a Miele Service Call online at www.miele.com/service. Contact information for Miele Customer Service can be found at the end of this document. -
Page 44: Technical Data
Technical data Fan motor 350 W Overhead lighting 3 W Total connected load 353 W Supply voltage, frequency 120 V AC, 60 Hz Fuse rating 15 A Power cord length 2.5 ft (0.75 m) Weight DAS 4720 35.3 lbs (16 kg) DAS 4920 37.5 lbs (17 kg) WiFi module Frequency range 2.400–2.4835 GHz Maximum transmission power <... - Page 47 Customer Service. U.S.A. Canada Miele, Inc. Importer Miele Limited National Headquarters Headquarters and Miele Centre 9 Independence Way 161 Four Valley Drive Princeton, NJ 08540 www.mieleusa.com Vaughan, ON L4K 4V8 www.miele.ca Customer Support Phone: 888-99-MIELE (64353) Customer Care Centre info@mieleusa.com...
