Summary of Contents for Miele DAS8930SS
- Page 1 Operating and Installation Instructions Ventilation Hood To prevent accidents and damage to the appliance, you must read these instructions before installing the appliance and using it for the first time. en-US M.-Nr. 12 039 220...
-
Page 2: Table Of Contents
Description of functions ................... 17 Before using for the first time ................18 Selecting vented mode or recirculation mode ............ 18 Setting up Miele@home ..................18 Connecting via the app .................. 19 Connecting via WPS ..................20 Signing out of WiFi (reset to factory settings) ..........21 Setting up Con@ctivity .................. - Page 3 Contents Cleaning and care ..................... 34 Stainless steel housing..................34 Important information for appliances with stainless steel surfaces ....34 Grease filters ....................... 35 Replacing the grease filter................36 OdorFree Charcoal Filter ..................37 Resetting the filter saturation indicator for the charcoal filters....... 37 Disposing of charcoal filters ................
-
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS READ AND SAVE THESE INSTRUCTIONS This appliance complies with current safety requirements. Improper use of the appliance can lead to personal injury and material damage. Read all instructions before installing or using the appliance for the first time. Only use the appliance for its intended purpose. Keep these operating instructions in a safe place and pass them on to any future user. -
Page 5: Safety With Children
IMPORTANT SAFETY INSTRUCTIONS Safety with children Children must be kept away from the ventilation hood unless they are constantly supervised. Children must not be allowed to clean or service the hood. Please supervise children in the vicinity of the hood and do not let them play with it. -
Page 6: Technical Safety
Installation, repair and maintenance work should be performed by a Miele authorized service technician in accordance with national and local safety regulations and the provided installation instructions. Contact Miele’s Technical Service Department for examination, repair or adjustment. - Page 7 The function and operation of the protective measures provided in the domestic electrical installation and in this Miele product must also be maintained in isolated operation or in operation that is not synchronized with the grid power supply, or these measures must be replaced by equivalent measures in the installation.
- Page 8 IMPORTANT SAFETY INSTRUCTIONS If the power cord is damaged, it must only be replaced by a qualified service technician. During installation, maintenance, and repair work, the ventilation hood must be disconnected from the electrical supply. It is only completely isolated from the electricity supply if one of the following applies: - The circuit breakers on the electrical service panel are tripped.
-
Page 9: Correct Use
IMPORTANT SAFETY INSTRUCTIONS Correct use WARNING: TO REDUCE THE RISK OF A COOKTOP GREASE FIRE: - a) Never leave surface units unattended at high settings. Boilovers cause smoking and greasy spillovers may ignite. Heat oils slowly on low or medium settings. - b) Always turn the hood on when cooking at a high heat. - Page 10 IMPORTANT SAFETY INSTRUCTIONS The ventilation hood may become damaged if exposed to excessive heat from a gas cooktop. - When using the ventilation hood over a gas cooktop, ensure that any burners in use are always covered by cookware. Turn burners off when removing the cookware, even if doing so for just a short time.
-
Page 11: Proper Installation
IMPORTANT SAFETY INSTRUCTIONS Proper installation WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: - a) Installation work and electrical wiring must be done by qualified person(s) in accordance with all applicable codes and standards, including fire-rated construction. -
Page 12: Cleaning And Maintenance
When installing the exhaust duct, only use pipes or tubes made of non-flammable material. These can be obtained from your Miele dealer or from Miele Technical Service. Always observe local building code requirements when selecting duct material. Exhaust air should not be vented into a chimney or vent flue which is otherwise in use and should not be channeled into ducting which ventilates rooms with fuel-burning installations. -
Page 13: Accessories And Parts
IMPORTANT SAFETY INSTRUCTIONS Accessories and parts Use only genuine original Miele parts. If parts or accessories from other manufacturers are used, the warranty may become void. Defective components should be replaced by Miele original parts only. Only with these parts can safety of the appliance be assured as intended by the manufacturer. -
Page 14: Caring For The Environment
Consult with local authorities, dealers or Miele in order to dispose of and recycle electrical and electronic appliances. Miele assumes no responsibility for deleting any personal data left on the appliance being disposed. -
Page 15: Guide To The Ventilation Hood
Guide to the ventilation hood... - Page 16 Guide to the ventilation hood a Pull-out canopy b Grease filter c Controls d Overhead lighting e Vent collar f Charcoal filters Optional accessories for recirculation mode g Sensor control for switching the ventilation hood on and off h Sensor controls for switching the blower on and off and for setting the blower power level i Sensor control for the delayed shutdown function j Sensor control for the grease filter saturation indicator...
-
Page 17: Extraction Mode
Description of functions The following functions are available on Recirculation mode your ventilation hood, depending on the Recirculation mode hoods require a model: recirculation kit and OdorFree Charcoal Filters (available as optional Extraction mode accessories), see “Technical Data” for more information. The air is drawn in and cleaned by the grease filters and directed outside. -
Page 18: Before Using For The First Time
Miele app. Pull out the deflector plate. If your Miele cooktop is connected to a Switch off the blower with the control home WiFi network, you can control the 2 and the lighting with the control . -
Page 19: Connecting Via The App
Connecting via the app Start signing the appliance on in the The Miele app can be used to connect app. Follow the signing in to your network. instructions. Install the Miele app on your mobile If requested to activate WiFi on the device. -
Page 20: Connecting Via Wps
Before using for the first time Touch the On/Off switch . Connecting via WPS All symbols light up with reduced Your WiFi router must support WPS brightness. (WiFi Protected Setup). Touch the On/Off switch . All symbols light up with reduced ... -
Page 21: Signing Out Of Wifi (Reset To Factory Settings)
With an existing WiFi connection, 2 and Tip: If your WiFi router does not support 3 will light up constantly. WPS, please connect via the Miele app. The ventilation hood is ready for disconnection during the next two minutes. -
Page 22: Setting Up Con@Ctivity
Con@ctivity is the direct communication Touch the 1 control. system between an induction Miele cooktop and a Miele ventilation hood. It enables the ventilation hood to operate automatically depending on the 2 will light up constantly, 3 will flash on operational state of a Miele cooktop and off. -
Page 23: Con@Ctivity Via The Home Wifi Network (Con@Ctivity 3.0)
(Con@ctivity 3.0) connection (Con@ctivity 3.0) Prerequisite: Prerequisite: - Home WiFi network - WiFi enabled Miele cooktop - WiFi-enabled Miele cooktop If you do not have a home network, you can establish a direct connection Connect the ventilation hood and... -
Page 24: Reattempting The Connection
Before using for the first time Start WiFi connection on the cooktop. For more details, see the cooktop operating instructions. When successfully connected, 2 and 3 will light up constantly. Quit connection mode on the ventilation hood by touching the delayed shutdown control . -
Page 25: Operation (Automatic Mode)
Operation (Automatic mode) When Con@ctivity is active, the ventilation hood always operates in automatic mode (see “Before using for the first time – Setting up Con@ctivity”). If you wish to operate the ventilation hood manually; see “Operation (Manual mode) – Cooking without Examples for fan levels 1 to B Con@ctivity”. -
Page 26: Cooking Process
Operation (Automatic mode) Cooking process Switching off For example, you switch on a burner Turn off all burners. at the highest power level to heat Over the next few minutes, the cookware for frying. After approx. ventilation hood blower setting will 10 seconds to 4 minutes, you then decrease one level at a time until the reduce the power level (60 seconds... -
Page 27: Temporarily Exiting Automatic Mode
Operation (Automatic mode) You can also operate the ventilation Temporarily exiting Automatic hood manually for a complete cooking mode process. To temporarily exit Automatic mode To do so, switch the ventilation hood when cooking: blower on before the cooktop. ... -
Page 28: Operation (Manual Mode)
Operation (Manual mode) Cooking without Con@ctivity Selecting the power level (Manual mode) Power levels 1 to 3 are available for light to heavy cooking vapors and odors. The ventilation hood can be operated manually if: For strong vapors and odors that are temporarily produced when cooking, - The Con@ctivity function is not e.g., during searing, select the B... -
Page 29: Selecting The Delayed Shutdown Time
Operation (Manual mode) Selecting the delayed Dimming/switching the shutdown time cooktop lighting on/off You can switch the cooktop lighting It is advisable to run the blower for a few minutes after cooking has finished. on by pulling the deflector plate out This helps to neutralize any lingering and off by pushing it in. -
Page 30: Changing Settings
Changing settings Touch the On/Off switch . All settings are made with the ventilation hood switched off. All symbols light up with reduced Pull out the deflector plate and switch brightness. off the blower and the lighting. Press and hold the delayed shutdown control ... -
Page 31: Adjusting Or Deactivating The Filter Saturation Indicator For The Charcoal Filter
Changing settings Adjusting or deactivating the Deactivating power filter saturation indicator for management the charcoal filter Keep in mind that this may increase energy consumption. Charcoal filters are needed for recirculation mode. Activating/deactivating power The filter saturation indicator can be set management to suit the customer’s cooking habits. -
Page 32: Audible Signal For The Sensor Controls
Changing settings All the indicator lights will go out. If you do not confirm the new setting within 4 minutes, the ventilation hood will revert to the previous setting. Audible signal for the sensor controls When a function is selected with the sensor controls, a short audible signal will sound for confirmation. -
Page 33: Energy-Saving Tips
Energy-saving tips This hood operates in a very efficient - Use the Con@ctivity function. The and energy-saving manner. The ventilation hood will switch on and off following will help you to save even automatically. The ventilation hood more energy when using it: will select the optimum power level for the cooking you are doing, which - Ensure that there is sufficient... -
Page 34: Cleaning And Care
To prevent the surfaces from quickly Stainless steel housing becoming dirty again, we recommend treating them with a stainless steel care General information product (available from Miele). The surfaces and control buttons Special instructions for glass are susceptible to scratching and surfaces chipping. -
Page 35: Grease Filters
Cleaning and care Removing the grease filters Grease filters When handling the grease filter, Risk of fire be careful not to drop it. Oversaturated grease filters are a fire This can result in damage to the filter hazard. and the cooktop below. -
Page 36: Replacing The Grease Filter
Use a commonly available household 3 seconds, until only the 1 is flashing. dishwashing detergent. The grease filter symbol goes out. In a Miele dishwasher use the Replacing the grease filter “Normal” program. Regular usage and cleaning can cause Depending on the detergent used, the filter surfaces to become worn. -
Page 37: Odorfree Charcoal Filter
The filter saturation indicator reminds Charcoal filters are available to order via you to regularly replace the charcoal the Miele Web Store (see end of this filters by illuminating the charcoal filter booklet for contact details), or from symbol . -
Page 38: Reactivatable Charcoal Filters
Cleaning and care Reactivatable charcoal filters Reactivatable charcoal filters are available for this ventilation hood. They can be used several times after being reactivated in the oven. Please follow the operating instructions supplied with the filters. Open the tab using a tool such as a screwdriver. -
Page 39: Customer Service
In the event of a fault which you cannot remedy yourself, please contact your Miele dealer or Miele Customer Service. You can book a Miele Service Call online at www.miele.com/service. Contact information for Miele Customer Service can be found at the end of this document. -
Page 40: Installation
*INSTALLATION* Installation Before installation Installation materials Before installation, it is important to read the information contained in this chapter and in the “IMPORTANT 1 non-return flap SAFETY INSTRUCTIONS” chapter. for installation in the exhaust vent on the motor (not needed for recirculation Information is subject to change. -
Page 41: Installation Materials For Recirculation Mode
*INSTALLATION* Installation Further installation materials (optional accessories) 6 screws, 4 x 15 mm 4 M4 x 16 mm screws DASL 38 trims Installation plan You will need the trims if you wish to See the installation plan for details of replace an appliance from the DA 35xx the individual steps involved in the or DA 36xx series with this ventilation installation of this appliance. -
Page 42: Appliance Dimensions
*INSTALLATION* Installation Appliance dimensions DAS 8930 in a 35 ⁷/₁₆" (900 mm) wide cabinet. The drawing is not to scale a The mounting brackets are designed for cabinets with sides that are between ⁵/₈" and ³/₄" (16 and 19 mm) thick. b The ducting can also be connected at the back. c Cut-out for vented mode or recirculation mode with DUU 150 conversion kit d The upper cabinet can be fitted with a partition after installation. -
Page 43: Distance Between Cooktop And Ventilation Hood (S)
Please also observe the information contained in the “IMPORTANT SAFETY INSTRUCTIONS” section. Minimum distance S Cooking appliance Miele Non-Miele appliance appliance Electric Cooktops 24" (610 mm) Electric Barbeques and Fryers 26"... -
Page 44: Adjusting The Deflector Plate
*INSTALLATION* Installation Adjusting the deflector plate Air venting When retracted, the deflector plate is WARNING: Danger of toxic fumes. held in place by magnets. Gas cooking appliances release The retaining force of the magnets can carbon monoxide that can be be adjusted. -
Page 45: Non-Return Flap
If the exhaust is ducted through an potential condensate. outside wall, a Miele wall vent or roof Condensate traps for 5" (125 mm) or vent (available as an optional 6" (150 mm) diameter ducting are accessory) is recommended. -
Page 46: Reducing Collar
*INSTALLATION* Installation Electrical connection Miele will not accept warranty claims for any functional defects or damage WARNING: TO REDUCE THE RISK caused by inadequate ducting. OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE Reducing Collar THE FOLLOWING: (optional accessory) - Page 47 *INSTALLATION* Installation Grounding Instructions WARNING - Improper grounding can result in a risk of electric shock. This appliance must be grounded. In the event of an electrical short circuit, grounding reduces the risk of electric shock by providing a path of least resistance.
-
Page 48: Technical Data
Technical data Blower motor 350 W Overhead lighting 3 W Total rated load 353 W Supply voltage, frequency 120 V AC, 60 Hz Fuse rating 15 A Power-cord length 2.5 ft (0.75 m) Weight 44.1 lbs (20 kg) WiFi module Frequency range 2.400–2.4835 GHz Maximum transmission power < 100 mW Optional accessories for recirculation mode For recirculation mode, installation kit DUU 150 or DUU 151 and charcoal filters DKF 31-900 P or DFK 31-R (reactivatable) must be purchased as optional accessories. - Page 51 Customer Service. U.S.A. Canada Miele, Inc. Importer Miele Limited National Headquarters 9 Independence Way Headquarters and Miele Centre Princeton, NJ 08540 161 Four Valley Drive www.mieleusa.com Vaughan, ON L4K 4V8 www.miele.ca Customer Support Phone: 888-99-MIELE (64353) Customer Care Centre info@mieleusa.com...
- Page 52 DAS 8930 en-US M.-Nr. 12 039 220 / 01...
