Summary of Contents for Miele DAS 2620 EXTA
- Page 1 Operating and installation instructions Cooker hood To prevent the risk of accidents or damage to the appliance, it is essential to read these instructions before it is installed and used for the first time. en-GB M.-Nr. 12 311 670...
-
Page 2: Table Of Contents
Contents Warning and Safety instructions..............Caring for the environment ................13 Guide to the cooker hood ................. 14 Modes of operation ................... 16 Operation......................17 Switching on the fan.................... 17 Selecting the power level ..................17 Run-on time......................17 Switching the fan off ................... 17 Switching the hob lighting on/off ................ - Page 3 Contents Electrical connection ................... 37 Technical data....................38 Optional accessories for recirculation mode............38...
-
Page 4: Warning And Safety Instructions
Miele cannot be held liable for injury or damage caused by non- compliance with these instructions. Keep these instructions in a safe place and pass them on to any future owner. -
Page 5: Safety With Children
Warning and Safety instructions The cooker hood can only be used by people with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, if they are supervised whilst using it, or have been shown how to use it in a safe way and recognise and understand the consequences of incorrect operation. - Page 6 Unauthorised installation, maintenance and repairs can cause considerable danger for the user. Installation, maintenance and repairs must only be carried out by a Miele authorised technician. A damaged appliance can be dangerous. Check it for visible signs of damage. Do not use a damaged appliance.
- Page 7 Miele authorised technician to protect the user from danger. The lamps are a built-in component of the lighting. Replacement lamps may only be fitted by a Miele authorised technician or by the Miele Customer Service Department. ...
- Page 8 Warning and Safety instructions Using at the same time as another heating appliance that depends on the air from the room Danger of toxic fumes! Great care should be taken when using the cooker hood in the same room or the same area of the house at the same time as another heating appliance that depends on the air from the room.
- Page 9 Warning and Safety instructions In order to ensure safe operation and to prevent gases given off by the heating appliance from being drawn back into the room when the cooker hood and the heater are both operated simultaneously, an underpressure in the room of 0.04 mbar (4 Pa) is the maximum permissible.
- Page 10 Warning and Safety instructions Correct use Open flames are a fire hazard. The use of an open flame under the cooker hood is not permitted. To avoid the danger of fire, do not flambé or grill over an open flame. When switched on, the cooker hood could draw flames into the filter.
-
Page 11: Proper Installation
Components can have sharp edges which may cause injury. Wear gloves to protect your hands from being cut. Exhaust ducting must be of non-inflammable material. Suitable material is available from Miele specialist dealers or the Miele Spares Dept. - Page 12 The steam could reach electrical components and cause a short circuit. Accessories and spare parts Only use genuine original Miele accessories and spare parts with this appliance. Using accessories or spare parts from other manufacturers will invalidate the warranty and Miele cannot accept liability.
-
Page 13: Disposing Of The Packaging Material
Miele, free of charge. By law, you are solely responsible for deleting any personal data from the old appliance prior to disposal. You are... -
Page 14: Guide To The Cooker Hood
Guide to the cooker hood... - Page 15 Guide to the cooker hood a Exhaust duct b Control elements c Charcoal filter Single-use or reactivatable charcoal filters Optional accessories for recirculation mode d Grease filter e Pull-out deflector plate f Hob lighting g Control for switching the fan on and off h Controls for setting the fan power level i Control for switching the lighting on and off j Hinged front panel...
-
Page 16: Modes Of Operation
Cooker hoods designed for use with an external motor have to be connected to The air is drawn in and cleaned by the a Miele external motor located in a grease filter and directed outside. position of your choice outside the room. -
Page 17: Operation
Operation It also reduces the risk of residues Switching on the fan accumulating in the cooker hood and Switch the fan on as soon as you start any resultant odours. cooking. This is to ensure that vapours are captured right from the start. Switching the fan off ... -
Page 18: Power Management
Operation Press “” to switch Power Power management management off. The cooker hood is fitted with a power The 1 and B indicators will flash. management system. Power management helps to save energy. It To switch it on, press “”. ensures that the fan power level is The 1 and B indicators will light up reduced automatically and that the... -
Page 19: Energy Saving Tips
Energy saving tips This cooker hood operates very efficiently and economically. The following will help you to save even more energy when using it: - Ensure that there is sufficient ventilation in the kitchen when cooking. In extraction mode, if there is insufficient air flow the cooker hood cannot operate efficiently and this causes increased operating noise... -
Page 20: Cleaning And Care
Unsuitable cleaning agents can becoming dirty again, we recommend damage the surfaces and control treating them with a stainless steel care elements. product (available from Miele). Do not use any cleaning agents containing soda, acid, chloride or Important information for the control solvent. -
Page 21: Grease Filter(S)
Cleaning and care Removing a grease filter Grease filter(s) When handling a grease filter, be Fire hazard careful not to drop it. An oversaturated grease filter is a fire This can result in damage to the filter hazard. and the hob below. -
Page 22: Replacing The Grease Filter
However, this will not Grease filters are available to order via affect the functioning of the grease the Miele Customer Service Department filter in any way. (see end of these operating instructions for contact details) or from your Miele dealer. -
Page 23: Charcoal Filters
Charcoal filters are available to order via Remove the charcoal filter packaging. the Miele Webshop, the Miele Spare Parts Department (see end of this booklet for contact details) or from your Miele dealer. -
Page 24: Disposing Of Charcoal Filters
Cleaning and care When to change the charcoal filters Replace the charcoal filters when they no longer absorb kitchen odours effectively, and at least every 6 months. Disposing of charcoal filters Used charcoal filters can be disposed of with normal household waste. Reactivatable charcoal filters Reactivatable charcoal filters are available for this cooker hood. -
Page 25: Service
In the event of any faults which you purchase. However, you must activate cannot remedy yourself, please contact your cover by calling 0330 160 6640 or your Miele dealer or the Miele Customer registering online at www.miele.co.uk. Service Department. You can book a Miele Customer Service Department call-out online at www.miele.com/service. -
Page 26: Installation
*INSTALLATION* Installation Before installation Before installation, it is important to read the information given on the 1 non-return flap following pages as well as the for fitting into the exhaust socket on “Warning and Safety instructions” at the motor unit (not needed for the beginning of this booklet. -
Page 27: Installation Materials For Recirculation Mode
*INSTALLATION* Installation 4 screws, M4 x 8 mm DML 2000 installation kit for installing a hinged front panel to match kitchen furniture units (not supplied; available as an optional accessory) 4 (8)* screws, 4 x 15 mm Installation materials for recirculation mode You need the following optional 4 screws, 4 x 30 mm accessories for recirculation mode: 8 (12)* screws, 4 x 15 mm DKFS 31-x installation kit... -
Page 28: Appliance Dimensions
*INSTALLATION* Installation Appliance dimensions Dia. 1: DA 2620 in a 600 mm wide cabinet. The drawing is not to scale... - Page 29 *INSTALLATION* Installation Dia. 2: DA 2920 in a 900 mm wide cabinet. The drawing is not to scale See diagram 1 for side view...
- Page 30 *INSTALLATION* Installation Dia. 3: DAS 2920 in a 600 mm wide cabinet or in a 900 mm wide cabinet with side compartments. The drawing is not to scale See diagram 1 for side view Footnotes for diagrams 1 to 3: a The front section of the cabinet must be fitted with a base panel to secure the cooker hood.
-
Page 31: Safety Distance Between Hob And Cooker Hood (S)
*INSTALLATION* Installation Safety distance between hob and cooker hood (S) When planning the installation height of your cooker hood, the minimum safety distance between the top of a cooker or hob and the bottom of the cooker hood is as follows, unless a greater distance is specified by the manufacturer of your cooking appliance. -
Page 32: Installing The Depth Stop (Optional)
*INSTALLATION* Installation Installing the depth stop (optional) Insert the depth stops into the recesses of the deflector plate from behind. The alignment is determined by how far forward you wish to move the stop. You can limit how far the deflector plate can be pushed in. - Page 33 *INSTALLATION* Installation Use a pen to mark the back edge of the deflector plate on the cover. Slide the depth stops forward to the position shown. Pull out the deflector plate. Slide the covers back again. ...
-
Page 34: Connection For Air Extraction
*INSTALLATION* Installation - All connections must be strong and Connection for air extraction airtight. If the cooker hood is used at the - If the exhaust ducting has flaps, same time as a heating appliance these must be opened whenever the that relies on oxygen from the same cooker hood is switched on. -
Page 35: Non-Return Flap
If the exhaust is ducted through an outside wall, a Miele wall vent or roof vent (available as an optional accessory) is recommended. Both of these have a built-in non-return flap. -
Page 36: Silencer
*INSTALLATION* Installation Silencer In recirculation mode, the silencer needs to be positioned between the exhaust vent and the exhaust grille . Check that there is sufficient space. To reduce noise levels even further, a silencer (optional accessory) can be installed in the exhaust ducting. For operation with an external motor, noise from the motor outside the house and inside the kitchen can be... - Page 37 If the mains connection cable is damaged, it must only be replaced with a specific mains connection cable of the same type (available from the Miele Customer Service Department). For safety reasons, such replacement may only be carried out by a qualified specialist or the Miele Customer Service Department.
-
Page 38: Technical Data
Technical data Fan motor* 200 W Hob lighting 3.2 W Total rated load* 203.2 W Mains voltage, frequency AC 230 V, 50 Hz Fuse rating 10 A Length of mains connection cable 1.5 m Weight DAS 2620 12 kg DAS 2920 14 kg DAS 2620 EXTA 9 kg DAS 2920 EXTA 11 kg * For EXTA models, the rated load will depend on the type of external motor fitted. Length of connection cable to external motor: 1.9 m Optional accessories for recirculation mode You need the following installation kits for recirculation mode:... -
Page 39: Data Sheet For Household Cooker Hoods
Technical data Data sheet for household cooker hoods In acc. with delegated regulation (EU) No. 65/2014 and regulation (EU) No. 66/2014 MIELE Model name/identifier DAS 2620 Annual Energy Consumption (AEC 41,7 kWh/year hood Energy efficiency class Energy efficiency index (EEI... - Page 40 Technical data Data sheet for household cooker hoods In acc. with delegated regulation (EU) No. 65/2014 and regulation (EU) No. 66/2014 MIELE Model name/identifier DAS 2920 Annual Energy Consumption (AEC 42,0 kWh/year hood Energy efficiency class Energy efficiency index (EEI...
- Page 41 Power consumption in standby mode (P 0,25 W Nominal power of lighting system 3,2 W Average illumination of the lighting system on the cooking surface 310 Ix Time increase factor The above values were determined in combination with the Miele ABLG 202 external motor.
- Page 42 Power consumption in standby mode (P 0,25 W Nominal power of lighting system 3,2 W Average illumination of the lighting system on the cooking surface 275 Ix Time increase factor The above values were determined in combination with the Miele ABLG 202 external motor.
- Page 43 United Kingdom Miele Co. Ltd., Fairacres, Marcham Road, Abingdon, Oxon, OX14 1TW Tel: 0330 160 6600, Internet: www.miele.co.uk/service, E-mail: info@miele.co.uk Australia Ireland Singapore Miele Australia Pty. Ltd. Miele Ireland Ltd. Miele Pte. Ltd. ACN 005 635 398 2024 Bianconi Avenue...
- Page 44 DAS 2620, DAS 2920, DAS 2620 EXTA, DAS 2920 EXTA en-GB M.-Nr. 12 311 670 / 02...
