Power over Ethernet (PoE) shall be provided by listed Information Technology Equipment meeting the IEEE 802.3bt PoE standard. The PoE is not intended to be connected to exposed (outside plant) networks. Consult Honeywell for the recommended adapter. Warning: To comply with EN50130-4 requirements, a UPS should be employed when powering the camera from 24 VAC.
Personal data is protected by the General Data Protection Regulation (2016/679) in Europe and therefore the owners of personal data have obtained certain rights thanks to this regulation. We strongly advise you to be fully aware of these owner (“data subjects”) rights as well as which limitations you have to obey regarding the use and distribution of this data.
The manufacturer declares that the equipment supplied with this guide is compliant with the European Parliament and Council Directive on the Restrictions of the use of certain hazardous substances in electrical and electronic equipment (2011/65/EU) as Amended by RoHS 3 (2015/863), and the essential requirements of the EMC Directive (2014/30/EU), conforming to the requirements of standards EN 55032 for emissions, EN 50130-4 for immunity, and EN 62368-1 for electrical equipment safety.
Warranty and Service Subject to the terms and conditions listed on the product warranty, during the warranty period Honeywell will repair or replace, at its sole option, free of charge, any defective products returned prepaid. In the event you have a problem with any Honeywell product, please call Customer Service at 1.800.323.4576 for assistance or to request a Return Merchandise...
TABLE OF CONTENTS About This Document ................1 Overview of Contents ......................1 Introduction ..................2 Overview ............................2 Key Features ..........................2 Accessing the Camera ..............4 Installing the Unified Tool ....................4 Discovering Your Camera on the Network ..............6 Assigning a New IP Address to Your Camera ..............
Page 8
Mode ........................... 20 Video Stream ........................21 Configuring Audio Settings ....................24 Configuring IR Control Settings ..................25 IR Illuminators ......................... 25 Smart IR ..........................25 Configuring Image Settings ..................... 26 White Balance........................27 Image Adjustment ......................27 Defog ........................... 27 3D Noise Reduction ......................
Page 9
SD Card Status ........................ 63 SD Card Format ......................63 SD Card Control ......................64 Content Management ......................64 Searching and Viewing the Records ............... 64 Search Results ........................ 65 Recording Settings ......................66 Adding a Recording Setting ..................67 Setting up a Recording ....................
ABOUT THIS DOCUMENT This document provides instructions for accessing, configuring, and operating the Honeywell 60 Series IP cameras. This document is intended for system installers, administrators, and operators. Overview of Contents This document contains the following chapters and appendixes: •...
All models also support local video storage on micro SDHC cards (up to 1T) when network service is interrupted. Key Features Key features of the Honeywell 60 Series IP cameras include the following: Camera •...
Page 15
• Different user rights for each group System Management • Log function • Support controlling access permission by verifying the client PC’s IP address • System resource information and running real-time status display Honeywell 60 Series Panoramic Camera User Guide...
Self-Service Download Center Video Tools Camera Tools Unified Tool. Download and unzip the installation package of Unified Tool to your computer. To install the Unified Tool: 1. Double-click the installation program in the installation package. Honeywell 60 Series Panoramic Camera User Guide...
Figure 1 Install Unified Tool 2. Click Next and the following figure is displayed: Figure 2 Select Installation Folder 3. Follow the on-screen instructions to configure your settings and click Next. The following figure is displayed: Honeywell 60 Series Panoramic Camera User Guide...
4. Click Next. When the installation is completed, click Close. A shortcut of Unified Tool will be displayed on your desktop. Discovering Your Camera on the Network 1. Double-click on the desktop and the following figure is displayed: Honeywell 60 Series Panoramic Camera User Guide...
Auto discover/IP address/From file on the drop list to discover the cameras. Figure 5 Discover Cameras After the discovering, all discovered devices in the same subnet and different subnet will be displayed in the devices list. Honeywell 60 Series Panoramic Camera User Guide...
If you want, you can assign a new static IP address to the camera. Select the target device(s) as shown in Figure 5, click and the following figure is displayed: Figure 7 IP Assignment Honeywell 60 Series Panoramic Camera User Guide...
Figure 8 Firmware Upgrade The devices were grouped by model. To upgrade the firmware: 1. Select the target device(s) under a model. 2. Click BROWSE and select the upgrade file from your computer. Honeywell 60 Series Panoramic Camera User Guide...
3. Click APPLY. You can check the progress status in the device list. Accessing the Camera from a Web Browser To access the camera from a web browser, click next to the IP address of the device as shown in Figure Honeywell 60 Series Panoramic Camera User Guide...
1. Type the camera’s IP address in the address bar of the browser and press Enter on the keyboard. For example, if your camera’s IP address is 159.99.251.189, you would type https://159.99.251.189. Note: Chrome/Edge 88.0 (or later) is supported. Honeywell 60 Series Panoramic Camera User Guide...
For how to resolve the security certificate problem, see Export CA Certificate page 74. 4. Setup a new password according to the password requirements at the first login. Click SAVE. The password cannot be blank. Honeywell 60 Series Panoramic Camera User Guide...
5. Enter the user name as admin and newly created password. Click LOGIN. Figure 13 Login Page Using the Main Page The main page includes the following areas: system menu, live view tool bar, language selection and user account settings. Honeywell 60 Series Panoramic Camera User Guide...
You can change the camera name according to your needs. For more information, see Configuring System General Settings on page 69. Live View Tool Bar From the Live View toolbar, the controls are described in more details below. Honeywell 60 Series Panoramic Camera User Guide...
To configure user account or log out the current account, click as shown in Figure and the following figure is displayed: Figure 16 User Account To configure the user account, click SETTINGS. For details, see Configuring User Accounts Settings on page 75. Honeywell 60 Series Panoramic Camera User Guide...
Page 28
To log out the current account, click LOG OUT. Honeywell 60 Series Panoramic Camera User Guide...
Go to Setup Camera Setup. Select Channel information with Channel 1/2/3/4. Each channel is independent, and can be configured with different settings as below. Go to General Settings. On this page, you can configure the general video settings and day/night settings. Honeywell 60 Series Panoramic Camera User Guide...
Camera font (.ttf): You can select a True Type font file for the display of textual messages on video. Color: Select to display color or black/white video streams. Video Standard: Select the video standard: NTSC or PAL. Honeywell 60 Series Panoramic Camera User Guide...
In night mode, the camera switches off the IR cut filter at all times for the sensor to accept infrared light, thus helping to improve low light sensitivity. • Synchronize with digital input The camera switches between day mode and night mode synchronizing with digital input 1 (Alarm in). Honeywell 60 Series Panoramic Camera User Guide...
4-Megapixel (16:9) (MAX 30fps): Select it and the maximum resolution will be 2560x1440. The aspect ratio will be 16:9. 5-Megapixel (4:3) (MAX 12fps): Select it and the maximum resolution will be 2560x1920. The aspect ratio will be 4:3. Honeywell 60 Series Panoramic Camera User Guide...
MAX 12 fps @ 5 M mode 4M: 2560 x 1440, 1920 x 1080, 25/30 fps @ 4 M mode 1280 x 720, 640 x 360, MAX 25/30 fps @ 4 M mode Figure 20 Video Stream Honeywell 60 Series Panoramic Camera User Guide...
Select the intra frame period from the following durations: 1/4 second, 1/2 second, 1 second, 2 seconds, 3 seconds, and 4 seconds. Honeywell 60 Series Panoramic Camera User Guide...
If Image quality is selected, the camera may drop some video frames in order to maintain image quality. Fixed Quality Figure 22 Fixed Quality All frames are transmitted with the same quality. Honeywell 60 Series Panoramic Camera User Guide...
G.726 bit rate is a speech codec standard covering voice transmission at rates of 16, • 24, 32, and 40kbit/s. After you complete the settings on this page, click SAVE to enable the settings. Honeywell 60 Series Panoramic Camera User Guide...
Manual IR adjust: Select it to control the luminance of IR lights manually. To increase • the luminance of IR lights, drag the slider to the right; to decrease the luminance of IR lights, drag the slider to the left. Honeywell 60 Series Panoramic Camera User Guide...
○ Schedule Mode: Check Enable to apply these settings at and select this mode to apply the settings at a specific period. Enter the time manually in the field. Figure 25 Image Settings Honeywell 60 Series Panoramic Camera User Guide...
Drag the slider to adjust the reduction strength (from low to high). 3D Noise Reduction is mostly applied in low-light conditions. In a low-light Note: condition with fast moving objects, trails of after-images may occur. You may then Honeywell 60 Series Panoramic Camera User Guide...
○ Schedule Mode: Check Enable to apply these settings at and select this mode to apply the settings at a specific period. Enter the time manually in the field. Honeywell 60 Series Panoramic Camera User Guide...
Center: This option will automatically add an inclusive window in the middle of the • window and give the necessary light compensation. Metering mode: Auto: The algorithm chooses the best metering strategy • BLC: This metering method increases the weight of dark area • Honeywell 60 Series Panoramic Camera User Guide...
Low to High), depending on the lighting condition at the installation site. You can select a higher effect when the contrast is high (between the shaded area and the light behind the objects). Honeywell 60 Series Panoramic Camera User Guide...
Figure 29 Focus To zoom in on an image, drag the slider to the right. • To zoom out on an image, drag the slider to the left. • To fine-tune the zoom, click • Honeywell 60 Series Panoramic Camera User Guide...
Page 44
It is recommended that this function be used only when you have a solid object in your Note: view window that is showing a consistent color or texture. This function will not take effect if you set the focus window on a distant background. Honeywell 60 Series Panoramic Camera User Guide...
Up to 5 privacy mask windows can be configured on the same screen. • If you want to delete the privacy mask window, click the ‘x’ mark on the right side of • privacy mask window name. Honeywell 60 Series Panoramic Camera User Guide...
Settings, page • Configuring HTTPS Settings, page • Configuring IEEE 802.1X Settings, page Configuring Network General Settings This section describes how to configure a wired network connection for the camera. Figure 31 Network Type Honeywell 60 Series Panoramic Camera User Guide...
Page 47
The UPnP protocol is used to detect network devices with clients running Windows. The camera can be detected by Windows' built-in network browser. To enable UPnP in Windows 10: 1. Go to Start Control Panel Network and Sharing Center. Honeywell 60 Series Panoramic Camera User Guide...
Follow the steps below to link to an IPv6 address: 1. Open your web browser. 2. Enter the link-global or link-local IPv6 address in the address bar of your web browser. 3. The format should be: http://[2001:0c08:2500:0002:0202:d1ff:fe04:65f4]/ Honeywell 60 Series Panoramic Camera User Guide...
Figure 35 Streaming Protocols - HTTP To utilize HTTP authentication, make sure that you have set a password for the camera Configuring User Accounts Settings on page 75. first. For more information, see Honeywell 60 Series Panoramic Camera User Guide...
Authentication (digest): User credentials are encrypted with MD5 algorithm which provides better protection against unauthorized access. Channel 1/2/3/4 Access name for main stream/sub stream: The camera supports multiple streams simultaneously. The access name is used to differentiate the streaming source. Honeywell 60 Series Panoramic Camera User Guide...
Page 51
RTP port for audio: By default, the RTP port for metadata is set to 5558. RTCP port for audio: By default, the RTCP port for metadata is set to 5559. Multicast settings for Stream 1/2: Select Stream 1 or Stream 2 to display the detailed configuration information. Honeywell 60 Series Panoramic Camera User Guide...
DDNS is a service that allows your camera, especially when assigned with a dynamic IP address, to have a fixed host and domain name. Figure 38 DDNS Enable DDNS: Check to enable the DDNS setting. Honeywell 60 Series Panoramic Camera User Guide...
CoS refers to Class of Service. It indicates the frame priority level from 0 (lowest) to 7 (highest). The priority is set up on the network switches, which then use different queuing disciplines to forward the packets. Honeywell 60 Series Panoramic Camera User Guide...
L2 protocol. QoS/DSCP Routers at each network node classify packets according to their DSCP ((Differentiated Services Codepoint) value and give them a particular forwarding treatment; for example, how much bandwidth to reserve for it. Honeywell 60 Series Panoramic Camera User Guide...
Managed device: A network node on a managed network. For example: routers, • switches, bridges, hubs, computer hosts, printers, IP telephones, network cameras, web server, and database. Before configuring SNMP settings on the page, enable your NMS first. Honeywell 60 Series Panoramic Camera User Guide...
Authentication password: Enter the password for authentication (at least 8 • characters). Encryption password: Enter a password for encryption (at least 8 characters). • Configuring HTTPS Settings Go to Setup Network Setup HTTPS. Honeywell 60 Series Panoramic Camera User Guide...
Enter the information of Country, State or province, Locality, Organization and Organization unit. Click CREATE. Click EXPORT to export the certificate request to your local computer. After you get the signing certificate from the certificate issuing authority, click CHOOSE FILE and Honeywell 60 Series Panoramic Camera User Guide...
RADIUS server must support and enable 802.1x settings. To configure IEEE 802.1x settings: 1. Before connecting the camera to the protected network with 802.1x, apply a digital certificate from a Certificate Authority (i.e., your network administrator) which can Honeywell 60 Series Panoramic Camera User Guide...
CA, and then upload related certificate(s). 4. When all settings are complete, move the camera to the protected LAN by connecting it to an 802.1x enabled switch. The devices will then start the authentication automatically. Honeywell 60 Series Panoramic Camera User Guide...
1. Click NEW to add a new motion detection window. 2. In the Window Name text box, enter a name for the motion detection window. a. Draw a detection area by clicking four corner points on the target area. You can Honeywell 60 Series Panoramic Camera User Guide...
Channel 1/2/3/4. Each channel is independent, and can be configured with different settings as below. This section explains how to configure camera tamper detection settings. With tamper detection, the camera can detect incidents such as redirection, blocking or defocusing, or even spray paint. Honeywell 60 Series Panoramic Camera User Guide...
For more information, see Trigger on page 55. Configuring Alarm In and Alarm Out Go to Setup Video Analytics Alarm In and Alarm Out. Honeywell 60 Series Panoramic Camera User Guide...
• A usually noisy environment, such as a factory, suddenly becomes quiet due to a breakdown of machines. • Dark environments where video motion detection may not function well. Honeywell 60 Series Panoramic Camera User Guide...
Audio. After unmuting, sometimes you need to refresh the page to make the audio detection page settings take effect. The default of the camera can be muted due to the lack of an internal microphone. An external microphone is provided by users. Honeywell 60 Series Panoramic Camera User Guide...
Click help, there is an illustration shown in the pop-up window explaining that an event can be triggered by many sources, such as motion detection or external alarm input devices. When an event is triggered, Honeywell 60 Series Panoramic Camera User Guide...
Detect next motion detection or digital input after x seconds: Enter the duration in • seconds to pause motion detection after a motion is detected. This can prevent event-related actions to take place too frequently. Honeywell 60 Series Panoramic Camera User Guide...
This option triggers the camera when the power to the camera is disconnected and re- connected. Recording notification This option allows the camera to trigger when the recording disk is full or when recording starts to overwrite older data. Audio detection Honeywell 60 Series Panoramic Camera User Guide...
A total of 5 server settings can be configured. There are the following server types available: Email and HTTP. Select the item to display the detailed configuration options. You can configure either one or all of them. Honeywell 60 Series Panoramic Camera User Guide...
Server list. If you wish to add other server options, click Add server. Server type – SFTP Select to send the media files to an SFTP server when a trigger is activated. Honeywell 60 Series Panoramic Camera User Guide...
If successful, you will receive a test.txt file on the SFTP server. Server type - HTTP Select to send the media files to an HTTP server when a trigger is activated. Honeywell 60 Series Panoramic Camera User Guide...
Select to send snapshots when a trigger is activated. Media name: Enter a name for the media setting. • Source: Select to take snapshots from any of the video streams. • Send pre-event images: • Honeywell 60 Series Panoramic Camera User Guide...
Page 72
Click SAVE MEDIA to enable the settings. Media type - System log Select to send a system log when a trigger is activated. Click SAVE MEDIA to enable the settings, and then click CLOSE to exit the page. Honeywell 60 Series Panoramic Camera User Guide...
You can only delete a server setting when it is not applied in an existing event setting. To remove a media setting from the list, select a media name and click DELETE. You can only delete a media setting when it is not applied in an existing event setting. Honeywell 60 Series Panoramic Camera User Guide...
Using an SD card that already contains data recorded by another device • should not be used in this camera. Do not modify or change the folder names in the SD card. That may result • Honeywell 60 Series Panoramic Camera User Guide...
Figure 61 No SD Card Figure 62 SD Card Onboard SD Card Format Figure 63 SD Card Format To format the SD Card, click FORMAT. SD card encryption by LUKS (Linux Unified Key Setup). Note: Honeywell 60 Series Panoramic Camera User Guide...
This tab allows the user to set up search criteria for recorded data. If you do not select any criteria and click SEARCH, all recorded data will be listed in the Search Results tab. Honeywell 60 Series Panoramic Camera User Guide...
The following is an example of search results. To sort the search results, click each column header. Figure 66 Search Results Play: Click on a search result and a Play window will be displayed for immediate • review of the selected file. Honeywell 60 Series Panoramic Camera User Guide...
SD Test: Insert the SD card and click here to test. Format your SD card via the camera’s web console when using it for the first Note: time. For more information, see SD Card Status on page 63. Honeywell 60 Series Panoramic Camera User Guide...
Motion Detection or Manual Trigger. For more information, see Configuring Event Settings on page 51. When there is no alarm trigger: • ○ JPEG mode: record 1 frame per second. ○ H.264 mode: record the I frame only. Honeywell 60 Series Panoramic Camera User Guide...
Click Recording 1 (Name): Opens the Recording Settings page to modify. • Click ON (Status): The Status will become OFF and stop recording. • Click SD (Destination): Opens the file list of recordings. • Honeywell 60 Series Panoramic Camera User Guide...
Go to Setup System Setup General Settings. This section explains how to configure the basic settings for the camera, such as the host name and system time. Figure 71 Configuring System General Settings Honeywell 60 Series Panoramic Camera User Guide...
Update interval: Select to update the time using the NTP server on an hourly, daily, • weekly, or monthly basis. Configuring Maintenance Settings Go to Setup System Setup Maintenance. This chapter describes how to restore the camera to factory default, upgrade firmware version, etc. Honeywell 60 Series Panoramic Camera User Guide...
If the upgrade is successful, the “Reboot system now!! This connection will close” message will be displayed. After that, re-access the camera. If an SD card is inserted to the camera, wait for the SD card formatting to complete. Honeywell 60 Series Panoramic Camera User Guide...
If the connection fails after rebooting, manually enter the IP address of the camera in the address field to resume the connection. Importing /Exporting Files Export / Update daylight saving time rules, custom language file, configuration file, and server status report. Honeywell 60 Series Panoramic Camera User Guide...
2. Save and open the export_translator.xml file. 3. Replace all English string value in bold black (see Figure 74) into your own language and save the file. The following figure is a sample segment. Honeywell 60 Series Panoramic Camera User Guide...
Export configuration file Enter a password for exporting the configuration file and then click EXPORT to export all parameters for the camera and user-defined scripts. Honeywell 60 Series Panoramic Camera User Guide...
When this process is completed, the LED status should return to normal. Configuring User Accounts Settings Go to Setup System Setup User Accounts. This section describes how to create multiple accounts and grant privileges to these accounts. Honeywell 60 Series Panoramic Camera User Guide...
2. Make necessary changes and click UPDATE or DELETE to enable the setting. Configuring Access List Settings Go to Setup System Setup Access List. This section describes how to control access permission by verifying the client PC’s IP address. Honeywell 60 Series Panoramic Camera User Guide...
The IPv6 access list column will not be displayed unless you enable IPv6 Note: • on the Network page. For more information about IPv6 Settings, see Enable IPv6 on page 36. The Range rule only applies to IPv4 addresses. • Honeywell 60 Series Panoramic Camera User Guide...
Administrator IP address Always allow the IP address to access this device: Check it and add the Administrator’s IP address in this field to make sure the Administrator can always connect to the device. Honeywell 60 Series Panoramic Camera User Guide...
Access log displays the access time and IP address of all viewers (including operators and administrators) in a chronological order. The access log is stored in the camera’s buffer area and will be deleted after the camera is rebooted. Honeywell 60 Series Panoramic Camera...
Figure 78 Access Log Version Go to Information Version. On the Version page, you can view the software version. Honeywell 60 Series Panoramic Camera User Guide...
CHAPTER TROUBLESHOOTING Troubleshooting for Common Issues Refer to the following guidelines to troubleshoot any performance issues. If you require additional assistance, contact Honeywell Technical Support (see back cover for contact information). Table 5 Troubleshooting Issues Solutions • Ensure that your browser’s security settings allow ActiveX controls.
The RCM compliance logo. This logo indicates that the product conforms with Australian RCM guidelines. The CE compliance logo. This logo indicates that the product conforms to the relevant guidelines/standards for the European Union harmonization legislation. Honeywell 60 Series Panoramic Camera...
Page 95
The caution symbol. This symbol indicates important information. The protective earth (ground) symbol. This symbol indicates that the marked terminal is intended for connection to the protective earth/grounding conductor. Eurasian Conformity (EAC) RoHS Honeywell 60 Series Panoramic Camera User Guide...
Page 96
Honeywell Building Technologies – Security Россия и СНГ Honeywell Building Technologies – Security Americas (Head Office) 121059 Moscow, UI, Kiev 7 Honeywell Commercial Security Russia 715 Peachtree St. NE Tel: +7 (495) 797-93-71 Atlanta, GA 30308 Tel: +1 800 323 4576 Honeywell Building Technologies –...
