Stryker Smartbadge Vocera V5000 Series Quick Reference Manual

Using the USB-C cable
1. Connect your Smartbadge to a USB cable.
2. Insert the USB-C cable to the USB-port
of a laptop or a desktop computer.
Note: The charging rate is reduced when
connected to a laptop or desktop computer.
Using the Vocera power adaptor
1. Connect your Smartbadge to the Vocera
10W power adaptor.
2. Insert the adaptor into the wall socket.
Caution
Danger of explosion if battery is incorrectly
replaced. Replace only with the same or equivalent
type recommended by the manufacturer. Dispose
of used batteries according to the manufacturer's
instructions.
For more information on battery and charger safety,
refer to the Vocera Smartbadge Safety and
Regulatory User Guide at: http://pubs.vocera.com/
portal/index.html#topics/device.html
Mise en garde
Attention: il y a danger d'explosion s'il y a
remplacement incorrect de la batterie, remplacer
uniquement avec une batterie du même type
ou d'un type équivalent recommandé par le
constructeur. Mettre au rebut les batteries usagées
conformément aux instructions du fabricant.
Vocera, part of Stryker
3030 Orchard Parkway
San Jose CA, 95134
t: +1 408 882 5100
f: +1 408 882 5101
toll free: +1 888 9VOCERA
info@vocera.com
vocera.com
Charger specifications
Power supply:
100-240VAC, 50/60Hz
Dimensions:
20 cm (8") L x 7 cm (23/4") W x 5.5 cm
(21/4") H
With battery inserted:
8 cm (31/4") H
Weight:
32 g (1.1 oz)
Stryker Corporation or its divisions or other corporate affiliated
entities own, use or have applied for the following trademarks or
service marks: Stryker, Vocera. All other trademarks are trademarks of
their respective owners or holders. The absence of a product or service
name or logo from this list does not constitute a waiver of Stryker's
trademark or other intellectual property rights concerning that name
or logo. Copyright © 2022 Stryker.
AC_SB_BatteryGuide_BG_10_26_22.
930-02010 Rev. C.
Vocera V5000
®
Smartbadge series
batteries and chargers
quick reference
guide
