Related Manuals for NEFF B24CR31 0 Series
Summary of Contents for NEFF B24CR31 0 Series
- Page 1 Oven [en] User manual and installation in- structions B24CR31.0...
-
Page 2: Table Of Contents
en Table of contents You can find additional information and explanations online. Scan the QR code on the title page. Table of contents Table of contents INFORMATION FOR USE Home Connect ........... 1 6 Cleaning and servicing ........ 1 8 Safety... - Page 3 Safety en If there is water in the cooking compartment WARNING ‒ Risk of fire! when it is hot, this may create hot steam. Combustible objects that are left in the cook- Never pour water into the cooking compart- ing compartment may catch fire. ment when the cooking compartment is hot.
-
Page 4: Call Customer Service
en Preventing material damage Never kink, crush or modify the power cord. Once the appliance has been installed, the An ingress of moisture can cause an electric openings in the back panel of the appliance shock. must not be accessible to children. Do not use steam- or high-pressure cleaners Read the special installation instructions. -
Page 5: Environmental Protection And Saving Energy
Environmental protection and saving energy en 3 Environmental protection and saving energy Environmental protection and saving energy 3.1 Disposing of packaging For longer cooking times, you can switch the appliance off 10 minutes before the cooking time ends. The packaging materials are environmentally compatible There is sufficient residual heat to finish cooking the and can be recycled. -
Page 6: Cooking Compartment
en Familiarising yourself with your appliance On certain models, specific details such as colour and shape may differ from those pictured. Display Direction "Display", Page 6 Navigate to the right Swipe left on the display with Buttons your finger "Buttons", Page 6 ... -
Page 7: Functions
Functions en You can remove the shelf supports, e.g. for cleaning. When you open the appliance door, the light in the "Rails", Page 21 cooking compartment switches on. If the appliance door remains open for longer than 15 minutes, the light switches off again. For most functions, the lighting is switched on during operation. -
Page 8: Additional Options
en Functions Symbol Heating function Temperature Top/bottom heat 30 - 275 °C Traditionally bake or roast on one level. This type of heating is espe- cially good for cakes with moist toppings. The heat is emitted evenly from above and below. Circo Therm gentle 125 - 230 °C For gently cooking selected types of food on one level without preheat- ing. -
Page 9: Accessories
Accessories en Symbol Name Rapid heating Activate or deactivate the rapid heating function Home Connect Home network and Home Connect server connected The number of lines shows the signal strength of the home network "Home Connect ", Page 16 Home network Home network not connected "Home Connect ", Page 16 ... -
Page 10: Before Using For The First Time
In so doing, the wire rack is on You will find a comprehensive range of products for top of the upper guide rod. your appliance in our brochures and online: www.neff-home.com Wire rack on universal pan Accessories are appliance-specific. When purchasing accessories, always quote the exact product number (E no.) of your appliance. -
Page 11: Basic Operation
Basic operation en 8 Basic operation Basic operation 8.1 Switching on the appliance When the food is ready, use to switch the appli- ance off. ATTENTION If there is water on the cooking compartment floor when 8.5 Changing the temperature operating the appliance at temperatures above 120 °C, this will damage the enamel. -
Page 12: Time-Setting Options
en Time-setting options Set the required cooking time depending on the oper- Press to start the operation. ating mode. The display shows the time remaining until the opera- "Setting the cooking time", Page 12 tion starts. The appliance is in standby mode. ... -
Page 13: Dishes
Dishes en Press "Ready at". Use or to change the end time. The time at which your food will be ready will appear Press to confirm the setting. on the display. Press to confirm the delayed start. Use the button to select the required end time. Cancelling the "Ready at"... -
Page 14: Favourites
en Favourites Beef slow roast joint - British style Press to start the operation. Beef top side, top rump - British style The appliance starts to heat and the cooking time Joint of veal, marbled counts down. Joint of veal, lean Once the dish is ready, a signal sounds. -
Page 15: Rapid Heating
Rapid heating en 12.2 Deactivating the childproof lock Press and hold "Unlock" until "Childproof lock deactiv- ated" appears. 13 Rapid heating Rapid heating With the rapid heating function, you can shorten the Note: Do not set a cooking time until rapid heating has heat-up time. -
Page 16: Changing Basic Settings
en Home Connect Personalisation Selection Appliance in- Display formation 1 Regional dishes European dishes Appliance inform- Display technical information about the ap- British dishes ation pliance 1 Dishes No pork 14.2 Changing basic settings Kosher only Press to switch the appliance on. Childproof lock Available 1 Press "Basic settings". -
Page 17: Software Update
Home Connect en Basic setting Possible settings Explanation Home Connect assistant Start the assistant You can connect your appliance to the Home Connect app via the Disconnect Home Connect assistant. Note: If you are using the Home Connect assistant for the first time, only the "Start assistant"... -
Page 18: Cleaning And Servicing
en Cleaning and servicing 15.7 Data protection The current software and hardware version of your appliance. Please see the information on data protection. Status of any previous resetting to factory settings. The first time your appliance is registered on a home This initial registration prepares the Home Connect func- network connected to the Internet, your appliance will tions for use and is only required when you want to use transmit the following types of data to the Home Con-... - Page 19 Cleaning and servicing en Range Suitable cleaning agents Information Door handle Hot soapy water To avoid permanent stains, immediately remove any descaling agent that gets onto the surface. Door seal Hot soapy water Do not remove or scrub. Cooking compartment Range Suitable cleaning agents Information Enamel surfaces...
-
Page 20: 17 "Easy Clean" Cleaning Aid
en Easy Clean cleaning aid are not removed and stick to the surfaces. Red stains not impair the cleaning ability of the self-cleaning sur- are residues from salty food – they are not rust. The faces. stains are not hazardous to health. These marks do Attach the shelf supports. -
Page 21: Rails
Rails en Leave the cooking compartment to dry with the appli- Start the drying function using ance door open for 1 hour or use "Drying function". A notification stating that you should carry out the ne- "Setting Drying function", Page 21 cessary preparatory work for the drying function ap- ... - Page 22 en Appliance door Close the locking levers on the left- and right-hand Locking levers opened hinges . The hinge is now secured and cannot snap shut. Locking levers closed The locking levers are closed. The appliance door is secured and cannot be detached. Close the appliance door.
- Page 23 Appliance door en Lift out the inner pane and set it down carefully on 20.4 Fitting the door panes a flat surface. WARNING ‒ Risk of injury! Lift out the intermediate pane and set it down care- The hinges on the appliance door move when the door fully on a flat surface.
-
Page 24: Troubleshooting
en Troubleshooting Open the appliance door and attach the door seal. Push the inner pane upwards until it is in the left- and right-hand retainers . Note: When sliding the pane in, ensure that the glossy side of the pane is on the outside and the cut- Put the door cover into position ... - Page 25 Adjustment values, e.g. temperature or cooking time, depend on the recipe, quantity and food. Next time, set lower or higher values. Tip: A lot of other information about the preparation, corresponding adjustment values and recipes can be found in the Home Connect app or on our website www.neff- home.com .
-
Page 26: Disposal
You can also display the appliance information in the tions (EU) 65/2014, (EU) 66/2014 and (EU) 2023/826 basic settings. online at www.neff-home.com on the product and ser- "Basic settings", Page 15 vice pages for your appliance, in the area of user manu- als and additional documents. -
Page 27: Declaration Of Conformity
BSH Hausgeräte GmbH hereby declares that the appliance with Home Connect functionality conforms to the essen- tial requirements and other relevant provisions of Directive 2014/53/EU. A detailed RED Declaration of Conformity can be found online at www.neff-home.com among the additional docu- ments on the product page for your appliance. -
Page 28: Baking Tips
en How it works ATTENTION Roasting on the wire rack Acidic food may damage the wire rack Food roasted on the wire rack will become very crispy Do not place acidic food, such as fruit or food with an on all sides. You can roast large poultry, for example, or acidic marinade directly on the wire rack. - Page 29 How it works en Notes If you are warming or cooking the ready meal in The grill element switches on and off continuously. cookware, make sure that the cookware is heat-resist- This is normal. The temperature that you set determ- ant. ines how frequently this occurs.
-
Page 30: Low-Temperature Cooking
en How it works Food Accessory/cookware Height Type of Temperature in Cooking time in heating °C mins Potato gratin, raw ingredients, 4 cm Ovenproof dish 150-170 60-80 deep Chicken, 1.3 kg, unstuffed Uncovered cookware 200-220 60-70 Small chicken portions, 250 g each Uncovered cookware 220-230 30-35 Goose, unstuffed, 3 kg... -
Page 31: Test Dishes
How it works en Sear the meat on all sides on the hob at a very high Issue heat. You want to cook a Place the cold duck breast into a Immediately place the meat into the pre-warmed duck breast at a low pan. -
Page 32: Installation Instructions
en Installation instructions Food Accessory/cookware Height Type of Temperature in Cooking time in heating °C mins Small cakes, 2 levels Universal pan 1 25-35 Baking tray 1 Small cakes, 3 levels 4+3+1 25-35 Baking tray Universal pan 2 Hot water sponge cake Springform cake tin, dia- 160-170 25-35... -
Page 33: Appliance Dimensions
Installation instructions en 27.2 Appliance dimensions WARNING ‒ Risk of electric shock! Once the appliance has been installed, the You will find the dimensions of the appliance here openings in the back panel of the appliance must not be accessible to children, not even through the drawers and kitchen cabinets un- derneath. -
Page 34: Installation In A Tall Unit
en Installation instructions Hob type a raised in mm a flush in mm b in mm Induction hob Full-surface induction hob 1 Gas hob Electric hob 27.5 Installation in a tall unit 27.7 Corner installation Observe the installation dimensions and the installation Observe the installation dimensions and the installation instructions when installing in a tall unit. -
Page 35: Installing The Appliance
Installation instructions en Insert the plug into the protective contact socket. Open the appliance door and unscrew the left and When the appliance is installed, the mains plug of the right-hand panels. power cord must be freely accessible. If free access is not possible, an isolating switch must be integrated into the permanent electrical installation according to the installation regulations. -
Page 36: Removing The Appliance
en Installation instructions Thermal insulation strips must not be fitted to the side panels of the surround unit. 27.10 For handleless kitchens with vertical bar handle strips: Attach a suitable filling piece on both sides in order to cover any sharp edges and to guarantee safe in- stallation. - Page 40 Valid within Great Britain: Imported to Great Britain by BSH Home Appliances Ltd. Grand Union House Old Wolverton Road Wolverton, Milton Keynes MK12 5PT United Kingdom *9001896365* Register your product online neff-home.com BSH Hausgeräte GmbH (050217) REG25 9001896365 Carl-Wery-Straße 34 81739 München, GERMANY...
