Safety Bars
Safety Lock
Product
number
XULT36WBHX Single Horizontal Wall Bed Mechanism
(Upper Section), 940 mm (37'') x 1930 mm
(Canada) 1 866 832-4040
Mattress Brackets
Manual Ladder
Description
(76'')
(US) 1 800 619-5446
New Horizontal Wall Bed
Set (Upper Section)
Pull up the top of your wardrobe and
turn it into a wall bed with a ladder,
ready for use by large and small with a
load capacity of 190 kg!
Advantages/benefits
 With a high load capacity, anyone can sleep
safely.
 The bottom of the cabinet can also house
retractable bed mechanism XULT36WBHZ,
letting you create a convenient bunk bed.
 Maximizes the space in a room.
 The safety bar prevents sleepers from falling
out of the bed.
 Just one SKU for all parts!
 The base includes 13 slats, each of which is
made of 6 layers of birch, curved and glued
under pressure to guarantee the best possible
support
 The mattress bracket holds the mattress in
place.
 The lowering mechanism features a safety
lock to secure the open position.
 The ladder folds and retracts easily.
 The mounting instructions are available on
our website.
!
Important information
 Cabinet is not included.
Static Load Rating
190 kg (418 lb.)
Maximum mattress
thickness
180 mm (7-1/16'')
