Richelieu 62NB8301210 Manual

Panels assembly on 62NB0 profiles with templates

USE OF TEMPLATES FOR: SCREWS PLACING ON THE BACK SIDE OF THE PANEL

45°

Insert

Template

BACK SIDE OF

THE PANEL:

Place the

screws at the

bottom of the

eyelets/slots

Turn to

block

Fix the screws

using

62NBATULL2G

tool to leave

space for

sliding

Table of Contents

Do you have a question about the 62NB8301210 and is the answer not in the manual?

Page 1 Panels assembly on 62NB0 profiles with templates USE OF TEMPLATES FOR: SCREWS PLACING ON THE BACK SIDE OF THE PANEL 45° Insert Turn to Template block Fix the screws BACK SIDE OF THE PANEL: using 62NBATULL2G Place the screws at the tool to leave space for bottom of the...
Page 2 Panels assembly on 62NB0 profiles with templates USE OF TEMPLATES FOR: 62NB0 FIXING TO THE WALL 1. NB0 wall fixing 3. Fixing of the 4. Remove the panel with templates outside part of to fix the inside inserted into the second profile part of the profile outside eyelets of the profile...
