Wästberg w241 Faro Instructions

w241 Faro
Instructions
1.
4.
Adapter
5V⎓, min. 2A
(not included)
indicator
light
Cord
USB-C contact
(not included)
Page 1 / 2
2.
5.
press
indicator
light
Wästberg XAL Ltd.
Box 5085 477B & 478 The Arches,
200 71 Malmö Batemans Row
Sweden UK-London EC2A 3HH
wastberg.com wastberg.com
3.
6.
Mounting instructions
1.
Remove the battery cover.
2.
Take the battery out and connect the connectors.
3.
Put the battery back in the luminaire and then add the
connector with the narrow side down.
Attach the battery cover.
4.
Once the battery is connected, activate it by charging
it once. For optimal performance, charge it to 100%.
To charge the battery, connect a cord and adapter
(not included).
blinking constant
Indicator light
during charging:
charging fully charged
( ~4 hours)
5.
Press the button for the battery level indication.
white green yellow red
100-97% 97-50% 50-10% 10-0%
6.
Rotate the top plate to turn the light on/off and to dim.
This product contains a light source of energy
efficiency class D. The light source and control gear
are replaceable by Wästberg or by a professional with
explicit authorisation.
Contact customer service at service@wastberg.com
Our product is specifically designed for indoor
use, but it also offers limited outdoor application
possibilities. However, it is important to avoid
prolonged or extreme weather conditions to ensure
the product's longevity and performance.
Ambient temperature: 25°C.
