w 182 Pastille
Instructions
1.
4.
Page 1/3
2.
5.
15-55mm
Wästberg
Box 5085
200 71 Malmö
Sweden
wastberg.com
3.
6.
Mounting instructions
1.
There are five different adapters to attach the lamp to.
2. Floor.
Attach the lamp to the pole. Pull the cable through the
pole.
3.
Mount the base with the screws.
4. Table.
Attach the lamp to the base.
5. Clamp.
Secure the clamp by turning the screw.
6.
Attach the lamp to the clamp.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Wästberg Pastille
Summary of Contents for Wästberg Pastille
- Page 1 182 Pastille Page 1/3 Wästberg Box 5085 200 71 Malmö Instructions Sweden wastberg.com Mounting instructions There are five different adapters to attach the lamp to. 2. Floor. Attach the lamp to the pole. Pull the cable through the pole.
- Page 2 182 Pastille Page 2/3 Wästberg Box 5085 200 71 Malmö Instructions Sweden wastberg.com Mounting instructions 7. Pin. Pull the cord through the pin. Place the pin in the hole, Ø20 mm hole size. Secure with washer & nut under table.
- Page 3 182 Pastille Page 3/3 Wästberg Box 5085 200 71 Malmö Instructions Sweden wastberg.com Mounting instructions Attach the plug to the adapter. Connect the power cord to the adapter. Press the button to turn the light on and off. Press and hold to dim the light.
