w182 Pastille
Instructions
1.
4.
Page 1/3
2.
5.
Wästberg
Västergatan 38
211 21 Malmö
Sweden
wastberg.com
3.
6.
15-55mm
Mounting instructions
1.
There are five different mounting accessories to
attach the lamp to.
2. Floor
Connect the lamp contact to the extension cord.
3.
Pull the cords through the pole.
4.
Mount the base with the screws.
5. Table
Attach the lamp to the base.
6. Clamp
Secure the clamp by turning the screw.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Wästberg w182 Pastille
Summary of Contents for Wästberg w182 Pastille
- Page 1 Pastille Page 1/3 Wästberg Västergatan 38 211 21 Malmö Instructions Sweden wastberg.com Mounting instructions There are five different mounting accessories to attach the lamp to. 2. Floor Connect the lamp contact to the extension cord. Pull the cords through the pole.
- Page 2 Pastille Page 2/3 Wästberg Västergatan 38 211 21 Malmö Sweden wastberg.com Mounting instructions Attach the lamp to the clamp. 8. Pin Pull the cord through the pin. Place the pin in the hole, Ø20 mm hole size. Secure with washer & nut under table.
- Page 3 Pastille Page 3/3 Wästberg Västergatan 38 211 21 Malmö Instructions Sweden wastberg.com Mounting instructions Fasten with the screw. Attach the plug to the adapter. Connect the power cord to the adapter. Press the button to turn the light on and off.
